FPS SERIES
Front End Power Supplies
INSTRUCTION MANUAL
This Manual Cover Models:
FPS1000-12
FPS1000-32
FPS-S1U 19" Rack Single Output
FPS-T1U 19" Rack Triple Output
1000W In 1U
FPS1000-24
FPS1000-48
DWG NO: IA599-04-02-A

Advertisement

Table of Contents
loading

Related Manuals for TDK-Lambda FPS-S1U

Summary of Contents for TDK-Lambda FPS-S1U

  • Page 1 FPS SERIES Front End Power Supplies INSTRUCTION MANUAL This Manual Cover Models: FPS1000-12 FPS1000-32 FPS-S1U 19” Rack Single Output FPS-T1U 19” Rack Triple Output 1000W In 1U FPS1000-24 FPS1000-48 DWG NO: IA599-04-02-A...
  • Page 2 FPS1000 SERIES INSTRUCTION MANUAL DWG NO: IA599-04-02 A...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS Warranty ...Pg. 1 FPS1000, FPS-S1U and FPS-T1U rack Safety instructions ... Pg. 2 FPS1000 Power Supply Chapter 1: FPS1000 Series Specifications ... Pg. 4 Chapter 2: FPS1000 Series Outline drawings ...Pg. 5 Chapter 3: FPS1000 Series Installation instructions ...Pg. 7 Chapter 4: Functions and features ...Pg.

  • Page 4: Warranty

    FPS1000 Instruction Manual WARRANTY This Densei-Lambda product is warranted against defects in materials and workmanship for a period of two years from date of shipment. During the warranty period , Densei-Lambda will, at it's option, either repair or replace products which prove to be defective.

  • Page 5: Fps1000, Fps-S1U And Fps-T1U Rack Safety Instructions

    SAFETY-CLASS OF INSULATION The FPS1000, FPS-S1U and the FPS-T1U are designed for the following safety parameters: Material group IIIa, Pollution degree 2, Overvoltage category II, Class I (earthed), indoor use as part of an overall equipment such that the FPS product is accessible to service personnel only.
  • Page 6 FUSES There are no user replaceable fuses in the FPS1000, FPS-S1U and the FPS-T1U products. Internal fuses are sized for fault protection and if a fuse was opened it would indicate that service is required. Fuse replacement should be made by qualified technical personnel.

  • Page 7: Chapter 1 Fps1000 Series Specifications

    *8: Inverter shut down method. Reset by AC voltage recycle or by On/Off control. *9: Derate Maximum output power by 10% for input voltage less than 100V *10 For FPS 1000-12/P(S), when used not with FPS-S1U or FPS-T1U racks, an EMI suppressor clamp should be attached to the AC cable, as close as possible to the AC inlet, to meet class B.

  • Page 8: Chapter 2: Fps1000 Series Outline Drawings

    FPS1000 Instruction Manual CHAPTER 2 OUTLINE DRAWINGS 1.2 FPS 1000 SERIES OUTLINE DRAWINGS...
  • Page 9 2.2 FPS 1000/P SERIES OUTLINE DRAWINGS...

  • Page 10: Chapter 3: Fps1000 Series Installation Instructions

    Lambda sales or service facility nearest you. 3.4 FPS1000 MOUNTING The FPS1000 power supplies series is designed to fit in the FPS-S1U and FPS-T1U, 19" rack, or in an equivalent rack designed for the FPS1000 power supply.
  • Page 11 3.7 CONNECTING THE LOAD Turn off the AC input power before making or changing any rear panel connection. Ensure that all connections are securely tightened before applying power. There is a potential shock hazard when using a power supply with a rated output greater than 40V. 3.7.1 Load Wiring.
  • Page 12 4: AC OK green LED, on when the input voltage is higher than 85Vrms 5: Lock/Unlock lever. Automatically locks the power supply to the FPS-S1U rack chassis when the FPS1000 power supply is inserted. Push the Lock/Unlock lever toward the power supply cooling fan to withdraw the FPS1000 from the rack.
  • Page 13 3.7.7 Input/Output connector information The FPS1000 series uses male connector PCIB24W9M400A1, Positronic connector. To mate FPS1000 series to the load circuitry, use female connector PCIB24W9F400A1-S1031, Positronic connector. Refer to Table 3-4 and to the Outline drawing in chapter 2 for the connector pinout description. Pin No Function Description...

  • Page 14: Chapter 4 Functions And Features

    CHAPTER 4 FUNCTIONS AND FEATURES 4.1 Input Voltage Range Input voltage is single phase 85~265Vac (47~63Hz). The power supply can be operated also with a DC input voltage, 120~330VDC but the safety approvals apply to the AC voltage only. Input voltage which is out of the specifications might cause damage to the unit.
  • Page 15 4.8 DC_OK signal An open collector output provides a low output voltage detection signal. The open collector output is on when the output voltage is higher than 80%+/-5% of the rated output voltage of the power supply. The open collector output is referenced to the Signals_Return potential and is isolated from the power supply +V and -V terminals The maximum sink current is 10mA and the maximum external voltage is 15V.
  • Page 16 4.11 Remote Sensing The Remote sensing compensates voltage drop on the load wiring. The maximum voltage drop on each wire is 1V, however, it is recommended to minimize the voltage drop on the load wires to improve the response to load current changes.

  • Page 17: Chapter 5 Basic Connections For Operation

    CHAPTER 5 BASIC CONNECTIONS FOR OPERATION 5.1 Connecting single load, Local sensing Local sensing is suitable for applications where load regulation is not critical. Fig 5-1 shows recommended load and sensing connections for applications with a single load. 1,2,4 FPS1000 SIGNAL 3,5,6 Fig 5-1: single load connection, local sensing...
  • Page 18 5.4 Multiple loads connection with distribution terminals If remotely located output distribution terminals are used, the power supply output terminals should be connected to the distribution terminals by a pair of twisted or shielded wires. Each load should be separately connected to the remote distribution terminals (see Fig 5-4).

  • Page 19: Chapter 6 Parallel And Series Operation

    CHAPTER 6 PARALLEL AND SERIES OPERATION 6.1 Parallel operation Up to 8 FPS1000 units of the same output voltage rating can be connected in parallel. By connecting the CS signal between the paralleled units, automatic current balance is achieved, with +/-10% accuracy. Derate the total output current by 10% when using parallel operation to prevent overload condition.
  • Page 20 6.1.3 Signal Return bus at parallel operation The Signal Return of each paralleled unit can be connected together to form a common Signal Return bus. By this way, the control and monitoring signals of the paralleled units can be connected to the same control and monitoring circuitry.
  • Page 21 6.2 Series operation Two units can be seriesly connected to increase the output voltage or to create a bipolar voltage source. It is recommended to connect diodes in parallel with each output to prevent reverse voltage in case of failure in one of the power supplies.

  • Page 22: Chapter 7: I 2 C Bus Interface Option

    CHAPTER 7 C BUS INTERFACE OPTION 7.1 Introduction The I C interface option includes facilities to monitor operating parameters of the power supply. The parameters are then transferred to the host PC if demanded, over a standard I The following data can be monitored for the individual units connected to the I 1.
  • Page 23 7.3 Block diagram of the I C option Refer to Fig 7-1 for description of the I Fig 7-1: I C option bloack diagram 7.4 Operation and functions 7.4.1. Digital status Digital status functions are provided by a PCF8574, 8-bit Register. It provides a single 8-bit word when read by the C controller.
  • Page 24 7.4.3 Analog functions Analog functions are provided by a single PCF8591, 4-channel 8-bit A/D converter. When this device is read by the serial buscontroller it provides an 8-bit word with the following information: Channel 1: Output voltage, channel 2: Output current, The PCF8591 slave address is: Value The PCF8591 device initially requires a control byte to be written to the configuration register.
  • Page 25 7.5.3 Internal temperature measurement The internal ambient temperature is measured to provide information of the safe operation of the power supply. The internal ambient temperature is usually higher than the power supply air intake temperature due to internal power dissipation. As the power dissipation varies with the load, the internal ambient temperature increases with the load. Refer to Fig 7-2 for typical internal temperature rise above the air intake temperature versus the load.

  • Page 26: Chapter 8 Fps1000 Maintenance

    FPS1000 Instruction Manual CHAPTER 8 FPS1000 MAINTENANCE 8.1 Introduction This chapter contains information about maintenance, calibration and troubleshooting of the FPS1000 power supply. 8.2 Units under warranty Units requiring repairs during the warranty period should be returned to Densei-Lambda authorized service office. Unauthorized repairs performed by other than the authorized service facilities may void the warranty.
  • Page 27 FPS-S1U 19” Rack Single Output...

  • Page 28: Chapter 9: Fps-S1U Rack Specifications

    (*3) 85~265Vac continuous, 47~63Hz, Single phase 12.0/6.0 for each FPS1000 unit installed FPS-S1U :IEC inlet for each power supply module . FPS-S1U/P :None Bus-bars.Refer to outline drawing. (*4) Possible. Up to 3 racks with max 8 FPS 1000 units of the same voltage and current rating.

  • Page 29: Chapter 10: Fps-S1U Rack Installation Instructions

    10.4 FPS-S1U RACK MOUNTING The FPS-S1U is designed to be mounted in a 19" rack. Use a support bars or surface to provide adequate support for the rear of the power supply. Secure the FPS-S1U to its location using the front panel using M6x12 screws via the mounting holes at its front side (Refer to the outline drawings in Chapter 11).
  • Page 30 4. DIP switch for I C option address setting. Refer to Chapter 14 for details. 5. IEC320 AC inlets, shown for FPS-S1U rack. For FPS-S1U/P, there are no IEC320 inlets on the rack. 10.7.5 Control and monitoring signals connector Pin No Function...
  • Page 31 10.7.5 Control and monitoring signals connector Current sharing signal. When FPS-S1U racks are connected in parallel, the CS pins of the units should be connected to allow current balance between units. V_TRIM_C Connection for output voltage trimming of FPS1000 unit "C". The voltage can be trimmed within its range specifications.
  • Page 32 10.7.7 Blank panels Each FPS-S1U rack is supplied with two blank panels in the package. Use the blank panels to close the front panel opening in places where FPS1000 power supplies are not installed. Use M3x6 screws to fix the blank panel to the chassis.

  • Page 33: Chapter 11 Fps-S1U And Fps-S1U/P Outline Drawings

    CHAPTER 11 FPS-S1U AND FPS-S1U/P OUTLINE DRAWINGS 11.1 FPS-S1U Outline Drawing...
  • Page 34 FPS-S1U Instruction Manual 11.2 FPS-S1U/P Outline Drawing...

  • Page 35: Chapter 12: Basic Connections For Operation

    Fig 12-1: single load connection, local sensing In Local sense applications, the +/- sense have to be connected to the +/-V terminals of the FPS-S1U prior to operating the FPS1000 units plugged in. 12.2 Connecting Single Load, Remote Sensing Remote sensing is used in cases where the load regulation is important at the load terminals. Use twisted or shielded wires to minimize noise pick-up.
  • Page 36 FPS-S1U ON/OFF_B ON/OFF_C SIGNAL_RET UNIT ‘A’ Fig 12-5: Single On/Off control FPS-S1U with FPS1000-12 installed: R2=0.0324*V R1(K Ω )=5(K Ω )-R2(K Ω ) FPS-S1U with FPS1000-24 installed: R2=0.0785*V R1(K Ω )=20(K Ω )-R2(K Ω ) FPS-S1U with FPS1000-32 installed: R2=0.0463*V R1(K Ω...

  • Page 37: Chapter 13 Parallel And Series Operation

    13.1 Parallel operation Up to 3 FPS-S1U racks with up to 8 FPS1000 installed units of the same output voltage rating can be connected in parallel. The built-in Oring diodes on the main output and on the +12V auxiliary voltage in each FPS1000 unit allow N+1 operation.
  • Page 38 13.1.3 Signal Return bus at parallel operation The Signal Return of each paralleled FPS-S1U rack can be connected together to form a common Signal Return bus. By this way, the control and monitoring signals of the paralleled racks can be connected to the same control and monitoring circuitry.
  • Page 39 13.2 Series operation Two FPS-S1U racks with the same output voltage rating can be connected in series to increase the output voltage or to create a bipolar voltage source. It is recommended to connect diodes in parallel with each output to prevent reverse voltage in case of failure in one of the power supplies.

  • Page 40: Chapter 14: Fps-S1U I C Bus Interface Option

    The rear panel 9 positions DIP switch is used to select the I unit inside the rack. Each unit should have its own I Each address is made of three DIP switch positions, thus a single power supply in the FPS-S1U can be addressed with one of 8 different addresses.

  • Page 41: Chapter 15: Fps-S1U Rack Maintenance

    No routine maintenance of the FPS-S1U rack is required except for periodic cleaning. To clean, disconnect the unit from the AC supply and allow 30sec. for discharging internal voltage. The FPS-S1U should be cleaned using mild solution of detergent and water. The solution should be applied onto a soft cloth, and not directly to the surface of the unit.
  • Page 42 FPS-T1U 19” Rack Triple Output...

  • Page 43: Chapter 16: Fps-T1U Rack Specifications

    CHAPTER 16 FPS-T1U RACK SPECIFICATIONS Number of power supply modules Maximum output power Input voltage / frequency range Maximum input current (at 100/200Vac) AC input connector Output terminals Remote sensing Parallel operation Series operation Remote On/Off control DC_OK signal AC fail signal Over Temperature alarm signal Vout voltage trimming Auxiliary power supply...

  • Page 44: Chapter 17: Fps-T1U Rack Installation Instructions

    CHAPTER 17 FPS-T1U RACK INSTALLATION 17.1 GENERAL This chapter contains instructions for initial inspection, preparation for use and repackaging for shipment. In some sections in this chapter, where the instructions for the FPS-T1U and the FPS1000 are identical, a reference to a section describing the FPS1000 will be given. 17.2 PREPARATION FOR USE Table 10-1 below describes the basic setup procedure.
  • Page 45 17.7.3 Making the load connections Hazardous voltages may exist at the outputs and the load connections when using a power supply with a rated output greater than 40V. To protect personnel against accidental contact with hazardous voltages, ensure that the load and it's connections has no accessible live parts. Ensure that the load wiring insulation rating is greater than or equal to the maximum output voltage of the power supply.
  • Page 46 17.7.5 Rear Panel In/Out Connector Pins Function Description Pin No Function Description Serial Data used in the I SDA (I FPS1000 Instruction Manual. Serial Clock used in the I SCL (I FPS1000 Instruction Manual. SIGNAL_RETURN Return for the following control and supervisory signals: On/Off, DC_OK, Over_temperature Alarm, AC_Fail, Auxiliary 12V supply.
  • Page 47 17.7.6 Modules location Up to three FPS1000 modules can be plugged into an FPS-T1U rack. Refer to Fig 17-2 for the modules location. PS MODULE “A” PS MODULE “B” Air flow direction Front side PS MODULE “C” see note 1 Fig 17-2: FPS1000 modules location Note 1: Forced air cooling allow minimum 50mm of unrestricted air space at the rear of the unit.

  • Page 48: Chapter 18: Fps-T1U And Fps-T1U/P Outline Drawings

    FPS-T1U Instruction Manual CHAPTER 18 FPS-T1U AND FPS-T1U/P OUTLINE DRAWINGS 18.1 FPS-T1U Outline Drawing...
  • Page 49 18.2 FPS-T1U/P Outline Drawing 11.1 FPS-T1U Outline Drawing...

  • Page 50: Chapter 19: Basic Connections For Operation

    CHAPTER 19 BASIC CONNECTIONS FOR OPERATION FPS-T1U RACK 19.1 Connecting Single Load, Remote Sensing Remote sensing is used in cases where the load regulation is important at the load terminals. Use twisted or shielded wires to minimize noise pick-up. If shielded wires are used, the shield should be connected to the ground at one point, either the power supply side or the load.
  • Page 51 19.3 Output Voltag Trimming Fig 19-4 shows typical output voltage trimming connection for FPS1000 unit ‘A’ inside the rack Units ‘B’ and ‘C’ connections - Refer to 17.7.5 J1(A) FPS-T1U J1(A)-8 FPS1000 Module A J1(A)-6 V_TRIM J1(A)-7 FPS-1000 Module B J2(B) FPS-1000 Module C J3(C)

  • Page 52: Chapter 20 Parallel And Series Operation

    CHAPTER 20 PARALLEL AND SERIES OPERATION 20.1 Parallel operation Up to 3 x FPS-T1U racks with up to 8 x FPS1000 installed units of the same output voltage rating can be connected in parallel. The built-in Oring diodes on the main output and on the +12V auxiliary voltage in each FPS1000 unit allow N+1 operation.
  • Page 53 20.2 Series operation Up to three FPS1000 with the same output voltage rating can be connected in series to increase the output voltage or to create a bipolar voltage source. It is recommended to connect diodes in parallel with each output to prevent reverse voltage in case of failure in one of the power supplies.

  • Page 54: Chapter 21: Fps-T1U I 2 C Bus Interface Option

    CHAPTER 21 FPS-T1U I 21.1 Introduction The FPS-T1U rack provides access to the I panel MOLEX female connector located at the rear panel. The Clock is connected to pin 2 and the Data is connected to pin 1. The specifications of the I are installed in the FPS-T1U rack.

  • Page 55: Chapter 22: Fps-T1U Rack Maintenance

    CHAPTER 22 FPS-T1U MAINTENANCE 22.1 Introduction This chapter contains information about maintenance, calibration and troubleshooting of the FPS-T1U rack. 22.2 Units under warranty Units requiring repairs during the warranty period should be returned to Densei-Lambda authorized service office. Unauthorized repairs performed by other than the authorized service facilities may void the warranty. 22.3 Periodic maintenance No routine maintenance of the FPS-T1U rack is required except for periodic cleaning.
  • Page 56 Notes...
  • Page 57 Notes...
