5.5.3 Output control continued
#
Commands
13
:UVPn;
14
:UVP?;
15
:ASTn;
16
:AST?;
5.5.4
5.5.4.1 Registers structure
1. Operational Status Register:
The operational status register records signals that are part of the power supply's normal operation. In
addition to the normal operation data, the register holds an alarm bit which indicates that one of the
alarm (fault) register bits is set. The register is automatically updated and reading it does not change it's
content. Clearing the register is done by DCL command. See table 5-5 for Operational Status Register
content.
Bit Name
Bit No
cc/cv
1
2
ast
3
out
4
srf
5
srv
6
srt
7
alarm
8
Table 5-5: Operational status register content.
Note:
*1 In case of AC fail, the alarm status register 'AC fail' bit will be set but will not set the alarm bit.
Description
Sets the under-voltage protection limits in volts. Under-voltage range
settings are given in table 5-4:
Model
0.00
0.00
00.0
00.0
00.0
00.0
Table 5-4: Under-voltage programming range.
Example - ZUP20-XY :UVP07.3;
Returns the string
UP
protection value. The under-voltage range is given in table 5-4.
example- UP07.3
Sets the auto-restart mode to On or Off.
:AST1; - Auto-restart is On
:AST0; - Auto-restart is Off
Returns the string
AS
AS1 - Auto-restart is ON
AS0 - Auto-restart is Off
Meaning
'0' - Indicates constant voltage, '1' - constant current.
'1' - Indicates foldback protection is armed.
'1' - Indicates auto-restart is on, '0' - auto-restart is off.
'1' - Indicates output is on , '0' -output is off.
'0' - Indicates foldback protection SRQ is disabled , '1' - enabled.
'0' - Indicates over voltage protection SRQ is disabled , '1' - enabled.
'0' - Indicates over temp. protection SRQ is disabled , '1' - enabled.
'1' - Indicates that an alarm register bit is set. (note*1)
5.98
9.97
19.9
35.9
59.8
79.8
119.8
followed by the present programmed under-voltage
followed by the auto-restart mode status.
