Summary of Contents for Cypress CCMX-44
- Page 1 Component 4x4 Matrix Operation Manual CCMX-44...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. Introduction................1 2. Features..................1 3. Package Contents..............1 4. Operation Controls and Functions........... 2 4.1 Front Panel................2 4.2 Rear Panel................2 4.3 Remote Control..............3 4.4 RS-232 Protocol..............3 4.4.1 Pin Definition............... 3 4.4.2 Commands..............3 5. -
Page 3: Introduction
1. Introduction Cypress CCMX-44 is a high performance Component + L/R Audio Matrix with remote control. It offers you maximum convenience in HDTV audio/video signal distribution when you have multiple sources and displays to connect together. Each of the four HDTV audio/video sources can be directed to any one of the four outputs, so four displays can show 4 identical or 4 different sources at the same time. -
Page 4: Operation Controls And Functions
4. Operation Controls and Functions 4.1. Front Panel INPUT-SELECT INPUT-SELECT INPUT-SELECT INPUT-SELECT POWER CCMX-44 OUT A OUT B OUT C OUT D HD 4x4 1. Remote control sensor. 2. Power Switch & LED Indicator: The LED will illuminate when the power is turned on. -
Page 5: Remote Control
Component/Audio OUT C. 5. Input Select for Component/Audio OUT D: Press 1, 2, 3 or 4 to select the desired input source for Component/Audio OUT D. 4.4. RS-232 Protocol 4.4.1. Pin Definition CCMX-44 Remote Control Console Definition Definition ... -
Page 6: Commands
4.4.2. Commands COMMAND ACTION Power Off (standby) Power On * System Status * Firmware Version Output A select Input1 Output A select Input2 Output A select Input3 Output A select Input4 Output B select Input1 Output B select Input2 Output B select Input3 Output B select Input4 Output C select Input1 Output C select Input2... -
Page 7: Connection And Installation
6. Connection and Installation Blu-ray HD TV HD TV HD TV HD TV 2007.6.28 MPM-CCMX44... - Page 8 Cypress Matrix Series: Product Description CHMX-22 2x2 HDMI Matrix CHMX-24 2x4 HDMI Matrix CHMX-42 4x2 HDMI Matrix CHMX-44 4x4 HDMI Matrix CHMX-22AS 2x2 HDMI Matrix CCMX-42 4x2 Component Matrix w/audio CCMX-44 4x4 Component Matrix w/audio CYPRESS TECHNOLOGY CO., LTD. Home page: http://www.cypress.com.tw...
