- Page 1 CMLUX-22S 2 by 2 HDMI V1.3 Matrix Operation Manual CMLUX-22S CMLUX-22S...
- Page 2 Revision History Version No. Date Summary of Change 20090518 Preliminary Release Precaution Failure to follow the precautions described below may cause damage to HDMI 1.3 Matrix Box and void the warranty. DO NOT open the case. Doing so will void the warranty. If you find ...
-
Page 3: Table Of Contents
Table of Contents 1. Introduction..…………………………………………....... 2. Application......………………………………………..… 3. Package Contents.......……………………………….……. 4. System Requirement........………………………...…..…… 5. Features........……………………………………...……..….. 6. Operation Controls and Functions.........…...………..….. 6.1 Front Panel ..................6.2 Rear Panel ………………………………………..…..…...… 7. Remote Control.......………………………………...…..…….…. 8. RS-232 Protocal.......………………………………...…..……….. 8.1 Commands.......………………………………...…..……….. 9. Connection and Installation..............10. -
Page 4: Introduction
1. Introduction With HDMI products gaining in popularity consumers are beginning to look for a way to connect their various devices. The HDMI V1.3 Matrix is a great solution for connecting your HDMI devices and sources together, making it more convenient for you to access your content, and thanks to the remote control it ’... -
Page 5: Features
5. Features HDMI 1.3, HDCP 1.1 and DVI 1.0 compliant. Supports digital video formats in Deep Color 12bit and new lossless compressed (Dolby TrueHD, Dolby Digital Plus and DTS-HD Master Audio) digital audio. The HDMI input is compensated, clock phase adjusted, and jitter ... -
Page 6: Operation Controls And Functions
6. Operation Controls and Functions 6.1 Front Panel INPUT INPUT POWER HDCP HDMI/DVI HDCP HDMI/DVI CMLUX-22S HDMI OUT 2X2 HDMI v1.3 Matrix ① ② ③ ④ ① . Remote control sensor. ② . Power switch & LED Indicator: The green LED will turn on when the power is switched on and the red LED will turn on when powered off. -
Page 7: Rear Panel
6.2 Rear Panel ② RS-232 HDMI OUTPUT HDMI INPUT DC 5V EDID IR IN ① ③ ④ ⑤ ⑥ ① . IR IN: Place the IR receiver cable in front of the displays and then use the sources remote to the device through an IR receiver cable. ②... -
Page 8: Remote Control
HDMI OUT B. OUTPUT *Notes: Output C & D with selection 3 & 4 are not functioning for this model. CR-33 8. RS-232 Protocol Pin Definition CMLUX-22S Remote Control Console Definition Definition → ← Baud Rate: 9600bps... -
Page 9: Commands
8.1 Commands COMMAND ACTION POWER 00 Power Off (standby) POWER 01 Power On PORT 11 Output A select Input1 PORT 12 Output A select Input2 PORT 13(No Function) PORT 14(No Function) PORT 21 Output B select Input1 PORT 22 Output B select Input2... -
Page 10: Connection And Installation
9. Connection and Installation HD TV HD TV 30˚ 30˚ OWER OUT UT OUT UT OUT UT OUT UT CR-33... -
Page 11: Specifications
10. Specifications Frequency bandwidth 2.25Gbps (single link) Input ports 2 x HDMI female ports, Output ports 2 x HDMI female ports EDID Standard, TV/Moving Port 1 HDMI Audio output PCM2, PCM5.1, PCM7.1, Dolby5.1, DTS5.1, DD+, D- TrueHD, DTS-HD HDMI Cable in 1080p 8bit (15M), 1080p 12bit (15M) HDMI Cable out 1080p 8bit (15M), 1080p 12bit (15M) - Page 12 CYPRESS TECHNOLOGY CO., LTD. Home page: http://www.cypress.com.tw 20090518 MPM-CMLUX22S...
