- Page 1 HDMI 4x4 Matrix Operation Manual CHMX-44...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. Introduction................1 2. Features..................1 3. Package Contents..............1 4. Operation Controls and Functions........... 1 4.1 Front Panel................1 4.2 Rear Panel................2 4.3 Remote Control..............3 4.4 RS-232 Protocol..............3 4.4.1 Pin Definition..............3 4.4.2 Commands..............4 5. -
Page 3: Introduction
HDMI sources and displays to connect together. Each of the four HDMI sources can be directed to any one of the four outputs, so four displays can show 4 identical or 4 different sources at the same time. CHMX-44 provides a maximum of 16 possible connection scenarios between sources and displays. -
Page 4: Rear Panel
3. Input Select/Indicators (A): Press the "HDMI OUT A" button repeatedly to switch to your desired source, and the LED will illuminate to indicate which input source is being selected, and routed to HDMI A display. 4. Input Select/Indicators (B): Press the "HDMI OUT B"... -
Page 5: Remote Control
5. Input Select for HDMI OUT D: Press 1, 2, 3 or 4 to select the desired input source for HDMI OUT D. 4.4 RS-232 Protocol 4.4.1 Pin Definition Remote Control Console CHMX-44 Definition Definition *RS-232 transmission format: Baud Rate: 9600 bps... -
Page 6: Commands
4.4.2 Commands COMMAND ACTION Power Off (standby) Power On * System Status * Firmware Version Output A select Input1 Output A select Input2 Output A select Input3 Output A select Input4 Output B select Input1 Output B select Input2 Output B select Input3 Output B select Input4 Output C select Input1 Output C select Input2... -
Page 7: Support Resolution
5.2 Support Resolution INTPUT VGA, SVGA, XGA, SXGA, UXGA 480i, 480p, 576i, 576p, 720p, 1080i, 1080p OUTPUT VGA, SVGA, XGA, SXGA, UXGA 480i, 480p, 576i, 576p, 720p, 1080i, 1080p 6. Connection and Installation LCD TV LCD TV LCD TV LCD TV Blu-ray... - Page 8 Cypress Matrix Series: Product Description CHMX-22 2x2 HDMI Matrix CHMX-24 2x4 HDMI Matrix CHMX-42 4x2 HDMI Matrix CHMX-44 4x4 HDMI Matrix CHMX-22AS 2x2 HDMI Matrix CCMX-42 4x2 Component Matrix w/audio CCMX-44 4x4 Component Matrix w/audio CYPRESS TECHNOLOGY CO., LTD. Home page: http://www.cypress.com.tw...
