- Page 1 CMLUX-44E 4 by 4 HDMI V1.3 Matrix Operation Manual CMLUX-44E...
- Page 2 Revision History Version No. Date Summary of Change 20090521 Preliminary Release 20100805 Adding RS-232 Setting 20100923 HDMI Cable Distance Precautions Failure to follow the precautions described below may cause damage to HDMI 1.3 Matrix Box and void the warranty. DO NOT open the device, doing so will void the warranty. If you ...
-
Page 3: Table Of Contents
Table of Contents 1. Introduction..……………………..…………………........ 2. Applications......…..….…………………………………..… 3. Package Contents......……………………………….……. 4. System Requirements......……………………………..…… 5. Features........…..…………………………………...……….. 6. Specifications..................7. Installation......…………………………………...………….. 7.1. Front Panel......…………………………………...………….. 7.2. Rear Panel.......…………………………………...………….. 8. Remote Control.......…..……………………………...………….. 9. RS-232 Protocal.......…………..……………………...………….. 9.1 RS-232 Setting .....…….…………….……………...………….. 9.2 Commands .....…………………….……………...………….. 10. Connection and Installation.............. -
Page 4: Introduction
1. Introduction While HDMI products are getting more and more popular people are now starting to have more than one HDMI device. The HDMI V1.3 Matrix is the ideal solution for connecting all your HDMI devices, and thanks to the included remote this system gives you complete control over your media environment. -
Page 5: Features
5. Features HDMI 1.3, HDCP 1.1 and DVI 1.0 compliant. Supports digital video formats in Deep Color Mode at up to 36 bits (12bits/ color) and a new lossless compressed (Dolby TrueHD, Dolby Digital Plus and DTS-HD Master Audio) digital audio and LPCM7.1. Has LED input source indicators for each output option. -
Page 6: Specifications
6. Specifications Frequency bandwidth 2.25Gbps (single link) Input ports 4 x HDMI female ports, Output ports 4 x HDMI female ports EDID Standard, TV/Moving Port 1 PCM2, PCM5.1, PCM7.1, Dolby5.1, DTS5.1, DD+ HDMI Audio output TrueHD, DTS-HD HDMI Cable in 1080p 8bit (15M), 1080p 12bit (15M) HDMI Cable out 1080p 8bit (15M), 1080p 12bit (15M) -
Page 7: Installation
7.1 Front Panel HDMI OUTPUT HDMI INPUT POWER SYNC SYNC SYNC SYNC CMLUX-44E 4X4 HDMI v1.3 Matrix ① ② ③ ④ ⑤ ⑥ ① . Remote control sensor. ② . Input Select/Indicators (A): Press the HDMI out “A” button repeatedly to switch to your desired source and the LED will illuminate to indicate which input source is being selected and routed to HDMI A output. -
Page 8: Rear Panel
7.2 Rear Panel RS-232 DC 5V HDMI OUTPUT IR IN 8 Bit 12 Bit ① ② ③ ④ ⑤ ⑥ ① . RS-232 communication port: Connect the COM port of your PC here in order to gain control over the RS-232 channel. Detail Specifications in section 8. -
Page 9: Remote Control
HDMI OUT C. 5. Input Select for HDMI OUT D: Press 1, 2, 3 or 4 to select the desired input source for HDMI OUT D. 9. RS-232 Protocal Pin Definition CMLUX-44E Remote Control Console Definition Definition →... -
Page 10: Rs-232 Setting
9.1 RS-232 Setting Enter into HyperTerminal from Window Start. Click the Properties from File . Press the Settings and click on ASCII Setup... -
Page 11: Commands
9.1 RS-232 Setting 1. Please ensure the HyperTerminal's ASCII setup is following to the setting as to below diagram. 9.2 Commands COMMAND ACTION POWER 00 Power Off (standby) POWER 01 Power On PORT 11 Output A select Input1 PORT 12 Output A select Input2 PORT 13 Output A select Input3... -
Page 12: Connection And Installation
10. Connection and Installation Blu-ray HD TV HD TV HD TV HD TV... - Page 16 CYPRESS TECHNOLOGY CO., LTD. Home page: http://www.cypress.com.tw 20090521 MPM-CMLUX44E...
