- Page 1 CMLUX-42S 4 by 2 HDMI V1.3 Matrix Operation Manual CMLUX-42S...
- Page 2 Revision History Version No. Date Summary of Change 20081110 Preliminary Release 20090407 HDMI Cable distance& Remote Control distance. Precaution Failure to follow the precautions described below may cause damage to HDMI 1.3 Matrix Box and void the warranty. DO NOT open the device, doing so will void the warranty. If you ...
-
Page 3: Table Of Contents
Table of Contents 1. Introduction..…………………………………………........ 2. Application......…………………………………………..… 3. Package Contents.......……………………………….……. 4. System Requirement........……………………………..…… 5. Features........………………………………………...……….. 6. Installation........…………………………………...………….. 7. Front View........…………………………………...………….. 8. Remote Control.......…………………………………...……….…. 9. RS-232 Protocal.......…………………………………...………….. 9.1 Commands .......…………………………………...………….. 10. Connection and Installation..............11. Specifications.................. -
Page 4: Introduction
1. Introduction Thank you for purchasing the HDMI V1.3 Matrix. While HDMI products are getting more and more popular people are now starting to have more than one HDMI device. The HDMI V1.3 Matrix is the ideal solution for connecting all your HDMI devices, and thanks to the included remote this system gives you complete control over your media environment. -
Page 5: Features
5. Features HDMI 1.3, HDCP 1.1 and DVI 1.0 compliant. Supports digital video formats in Deep Color 12bit and a new lossless compressed (Dolby TrueHD, Dolby Digital Plus and DTS-HD Master Audio) digital audio. The HDMI input is compensated, clock/phase adjusted, and jitter ... -
Page 6: Installation
6. Installation RS-232 DC 5V HDMI INPUT HDMI OUTPUT EDID EDID Control Switcher: The default factory setting is TV, please leave it here as long as the displays are working properly. Switch to STD to use build-in EDID Detail capability. RS-232 communication port: Connect the COM port of your PC here in order to gain control over the RS-232 channel. -
Page 7: Front View
7. Front View POWER HDCP HDMI/DVI HDCP HDMI/DVI CMLUX-42S HDMI OUT 4X2 HDMI v1.3 Matri x Remote control sensor. Power switch & LED Indicator: Green LED will turn on when the power is on and Red LED will turn on when power is turned off. -
Page 8: Remote Control
OUTPUT select the desired input source for HDMI OUT B. OUTPUT *Notes:Output C&D are not functioning for this model. CR-33 9. RS-232 Protocal Pin Definition CMLUX-42S Remote Control Console Definition Definition → ← Baud Rate: 9600bps Data bit: 8bits Parity: None... -
Page 9: Commands
9.1 Commands COMMAND ACTION POWER 00 Power Off (standby) POWER 01 Power On PORT 11 Output A select Input1 PORT 12 Output A select Input2 PORT 13 Output A select Input3 PORT 14 Output A select Input4 PORT 21 Output B select Input1 PORT 22 Output B select Input2 PORT 23... -
Page 10: Connection And Installation
10. Connection and Installation Blu-ray HD TV HD TV 30˚ 30˚ POWER OUTPUT OUTPUT OUTPUT OUTPUT CR-33... -
Page 11: Specifications
11. Specifications Frequency bandwidth 2.25Gbps (single link) Input ports 4 x HDMI female ports, Output ports 2 x HDMI female ports EDID Standard, TV/Moving Port 1 HDMI Audio output PCM2, PCM5.1, PCM7.1, Dolby5.1, DTS5.1, DD+, D- TrueHD, DTS-HD HDMI Cable in 1080p 8bit (10M), 1080p 12bit (10M) HDMI Cable out 1080p 8bit (10M), 1080p 12bit (6M)
