  • Page 1 User Guide...
  • Page 2 DTMF (Dual Tone Multiple Frequency). Telephone Networks (PSTNs)), hvor netværks- adressering - hvis det udbydes - foregår vha. DTMF- Nokia toteaa, että sen Mediamaster 220 S - signalering (Dual Tone Multiple Frequency). digitaalivastaanotin täyttää direktiivin 1999/5/EY olennaiset vaatimukset ja laitteeseen sovellettavat määräykset.

  • Page 3: Quick Guide

    Quick guide Satellite dish The satellite dish must have a clear view to the satellites. Mount the satellite dish according to the fitting instructions. In case you already have a satellite dish mounted, note that you need a Universal LNB which works on the frequencies 10.70- 12.75 GHz to be able to handle digital signals.

  • Page 4: Time Adjustment

    Quick guide Use predefined Thor + Sirius Select this alternative if you have two (2) LNB:s, adjusted to- wards Thor and Sirius, mounted on the antenna. Check Satellite Select one of the preprogrammed satellites. Test Channel Select one of the predefined channels and adjust the antenna until you have a TV picture from the predefined channel visible in the background.

  • Page 5: Table Of Contents

    Nokia operates a policy of continuous development. Therefore we reserve the right to make changes and improvements to any of the products described in this manual without any prior notice.

  • Page 6: Software End-User License

    Nokia Corporation, Nokia Home Communications (“Nokia”). The Agreement authorises You to use the Software specified in Clause 1 below and which is included in this Nokia digital TV receiver. This is an agreement on end-user rights and not an agreement concerning sale.
  • Page 7 NOKIA MEDIAMASTER SOFTWARE END-USER LICENSE rights automatically and immediately terminate cluding governmental research institutions, govern- without notice from Nokia if You fail to comply with mental corporations, or their separate business any provision of this Agreement. In such an event,...

  • Page 8: General Information

    Problem Solving, or alterna- tively call your dealer or a customer service adviser. Nokia Mediamaster 220 S is adapted to Viasat requirements for digital satellite TV re- ceivers. The receiver is intended for reception of Viasat’s bouquet of channels and in- teractive services, and for reception of free-to-air and encrypted channels from the Thor, Sirius, Hotbird and Astra satellites.

  • Page 9: Remote Control

    REMOTE CONTROL This section describes how to operate the Mediamaster using the buttons on the remote control. Some of the functions can also be carried out using the buttons on the front panel. Press once to turn the sound off/on (mute). Press and hold for a few seconds to switch the Mediamaster in and out of standby mode.

  • Page 10: Front And Rear Panel

    FRONT AND REAR PANEL Front panel to change channels open the lid in order and to move in menus to insert the CA module and the smart card Slot Slot for a CA module for inserting of a with a smart card Viaccess smart card Button Indica-...

  • Page 11: About The Smart Card And Ca Module

    Service Provider. Note: CA modules and smart cards are only distributed by serv- ice providers and special distributors, not by Nokia. After inserting a card, leave it in the slot permanently. Do not re- move it again, unless you will be asked to do so. This is impor-...

  • Page 12: Installation Of The Mediamaster

    INSTALLATION OF THE MEDIAMASTER The box for your Mediamaster should contain the following items: Remote control • the Mediamaster • remote control with 2 AAA batteries • SCART cable (fully connected 1.0 metre) • mains cable • phone cable with connectors •...

  • Page 13: Connecting To The Tv

    • Connect the TV aerial to the RF input socket on the analogue receiver. In order to switch the signal from the dish between the ana- logue and digital receivers, you need a Nokia smart switch (at Analogue A B in the diagram) or a Universal Twin LNB.

  • Page 14: Connecting A Hifi System

    INSTALLATION OF THE MEDIAMASTER Connecting a HiFi system • Connect an RCA stereo cable from the AUDIO L R sockets on the Mediamaster to the LINE, AUX, SPARE or EXTRA in- put sockets on your HiFi system. • If available you can connect an RCA single cable from the DIG- HiFi system ITAL AUDIO socket on the Mediamaster to a HiFi system equipped with digital audio input.

  • Page 15: First Time Installation

    FIRST TIME INSTALLATION General information Once you have correctly connected the Mediamaster, you also have to perform a “First time installation”. During this procedure, helpful information is displayed at the bottom of the menus. Please note! The OK button always confirms a selection within these menus, and pressing it will take you to the next step in the installation process.

  • Page 16: Use Predefined Thor + Sirius

    FIRST TIME INSTALLATION Use predefined Thor + Sirius Select this alternative if you have two (2) LNB:s, adjusted to- wards Thor and Sirius, mounted on the antenna. See page 17 for instructions. Check Satellite Select one of the preprogrammed satellites. Test Channel Select one of the predefined channels and adjust the antenna until you have a TV picture from the predefined channel visible...

  • Page 17: One Antenna/One Lnb Configuration

    FIRST TIME INSTALLATION One antenna/One LNB Configuration Select this alternative if you have one (1) LNB mounted on the antenna. LNB offset voltage If the cable down from the antenna is very long, the voltage at the LNB could be too low to change the polarisation. You can in- crease the voltage to the LNB by 0.5 V.

  • Page 18: Diseqc 4 Input Switch

    FIRST TIME INSTALLATION Switch port Here you select the input for each LNB that will be connected. In this specific example, the DiSEqC 1 input will be selected first. LNB Offset Voltage If the cable from any of the LNB’s is very long, it might be nec- essary to increase the voltage to these LNB’s by 0.5 V.

  • Page 19: Mini Diseqc Switch

    FIRST TIME INSTALLATION Mini DiSEqC Switch Select this alternative if your antenna system has two LNB:s and a Mini DiSEqC Switch (Tone burst). The procedure is the same as for two port DiSEqC as described on page 17-18. Channel search The Channel search procedure can be performed in different ways.

  • Page 20: Time Adjustment

    FIRST TIME INSTALLATION Time adjustment The time is adjusted by using the buttons, ± 1/2 an hour at a time. You can also adjust the minutes by using the buttons. • Press OK to finish the first time installation, see below. Finishing the first time installation The channels found at the search procedure will now be saved.

  • Page 21: Viewing Mode

    VIEWING MODE General information The following describes the basic functions of your Mediamaster while watching satellite TV or listening to satellite radio. Some of the functions described here are dependent on the Service Provider and can only be used if they are included in the transmitted programme information.

  • Page 22: Extended Programme Information

    VIEWING MODE Extended programme information The Mediamaster can display information about programmes cur- rently being broadcast as well as those that will be broadcast next. This procedure is the same for both TV and radio mode. By pressing info while watching TV you will get the “Programme information”...
  • Page 23 VIEWING MODE Channel Information You can get more information about the channel by choosing this alternative. Set Timer This alternative will take you to the timer menu. Please refer to page 27. Bookmark Move/Copy This alternative lets you either move or copy bookmarks to other folders.

  • Page 24: The Options Menu

    VIEWING MODE • Press OK when you are finished with the folder name. • Move the folder to where you want it to be, using the buttons, and press OK. This is how you move an existing folder: • Press navi to open the NaviBars. •...

  • Page 25: Tv Release (0)

    VIEWING MODE TV release (0) With the 0 button you can toggle between analogue TV, video, analogue and digital satellite TV signals. Teletext Pressing txt will open a teletext page (if teletext is transmitted.) Select teletext pages with the numeric buttons on the remote control.

  • Page 26: Navibars

    NAVIBARS General information Bookmark Bookmark • Press OK to open the NaviBars. name In order to select TV/Radio channels and to change system set- tings you will use the NaviBars. The horizontal row contains folders, e.g. All TV, Settings and so on.

  • Page 27: Timers

    NAVIBARS Timer General You can program the Mediamaster to start and stop at a predefined time. The timer function is very useful when you want to record a pro- gramme and you are unable to start/stop the recording event yourself, or when you just want to be reminded of the start of a programme you do not want to miss.

  • Page 28: Tv Settings

    There will be different information for each smart card regard- ing e.g. subscription status and expiry dates. In Mediamaster 220S,Viasat the embedded smart card slot must contain a Viasat smart card and the CA slot can handle other encryption systems.

  • Page 29: Appearance

    NAVIBARS Appearance Info Banner Time-out When you switch channels, an information banner will be shown for a few seconds. You can select how long the banner will be shown. Volume bar Select whether or not you want the volume bar to appear on the screen when you change the volume.

  • Page 30: Parental Ctrl

    NAVIBARS Parental Ctrl To open this menu you will be asked to enter your access code. From the factory the access code is set to 1234. The following settings can be altered from this menu. Access Control Select “Yes” or “No” to turn the access control in all menus on or off.

  • Page 31: Antenna

    NAVIBARS Information about the modem This equipment has been approved pursuant to Council Decision 98/482/EC [CTR 21] for pan-European single terminal connection to the Public Switched telephone Network (PSTN). However, due to differences between the individual PSTNs provided in differ- ent countries, the approval does not, of itself, give an uncondi- tional assurance of successful operation on every PSTN termina- tion point.

  • Page 32: Upgrade

    NAVIBARS Upgrade In order to keep the Mediamaster up-to-date, it will be possible to download new versions of the system software via satellite. New software may include new or improved features for exist- ing menus. The upgrade will be handled automatically by Viasat but it is also possible to enter this menu to check if a new software version is available.

  • Page 33: Glossary Of Terms

    GLOSSARY OF TERMS AC-3 Multichannel digital audio encoding system. Pulse Code Modulation. Non-compressed digital audio format. Access control A feature that allows parents to ”lock” programmes that they consider unsuitable for children. A ”locked” chan- Program Clock Reference. nel or programme can only be ”unlocked” with the spe- cial access code.

  • Page 34: Troubleshooting

    TROUBLESHOOTING Problem Possible causes What to do The LED on the front panel does Mains cable is not connected. Check that the mains cable is plugged not light up/is not lit. into the power socket. The left LED is shining red The Mediamaster is in standby Press the standby button to bring the mode.

  • Page 35: Technical Specifications

    TECHNICAL SPECIFICATIONS Transmission standards Front panel DVB, MPEG 2 2 LEDs, Buttons: (standby, progr. number up and down) LNB / Tuner input Conditional Access system Connector 1x F-type (LNB) Embedded Viacccess. One PCMCIA Interface for a RF input frequency 950-2150 MHz Common Interface CA-module.
  • Page 36 Nokia is a registered trademark of Nokia Corporation www.nokia.com 667698521.01...
