Nokia Group of Companies. Use this document as agreed. You agree to notify Nokia of any errors you may find in this document; however, should you elect to use this document for...
Quick onboarding guide ....................13 Inserting the SIM card....................13 Using the Nokia Wireless Mobile App to find the best installation location....15 Connecting the FastMile 5G Receiver to power ............18 Finishing off installation of the FastMile 5G Receiver on a window ......20 Finishing off installation of the FastMile 5G Receiver on a desktop stand ....27...
Introduction This guide describes how to install the FastMile 5G Receiver using guidance from the Nokia Wireless Mobile App, and how to operate the FastMile 5G Receiver using its web-based graphical user interface. This guide also provides some troubleshooting information.
Using the Nokia Wireless Mobile App to find the best installation location The Nokia Wireless Mobile App can be installed on a smart phone to provide information that can help with FastMile 5G Receiver installation, such as finding the best location for installing the FastMile 5G Receiver.
Page 16
Wireless Mobile App. Note: Be prepared for the possibility of the need to move the FastMile 5G Receiver and PoE injector when using the Nokia Wireless Mobile App to find the best location for the FastMile 5G Receiver. Do not secure the FastMile 5G Receiver, PoE injector, or any cables in place yet. Do not connect the PoE injector to your gateway yet.
Page 17
Enable Bluetooth on your smart phone. The smart phone and downloaded app pair with the FastMile 5G Receiver. If you are requested by the Nokia Wireless Mobile App to enter the Bluetooth PIN number, enter the Bluetooth PIN code that is provided on the quick onboarding guide.
FastMile 5G Receiver. The Nokia Wireless Mobile App can be used to do a speed test using Ookla. Once you have finished using the Nokia Wireless Mobile App to determine the best location for the FastMile 5G Receiver, you can finish off the installation: •...
Page 22
This might not always be possible with a FastMile 5G Receiver that has the pre-mounted ultra-flat (“thin”) cable (30 cm), but it is highly recommended for devices with the pre-attached flat cable (1.5/2.5/10 m lengths provided by Nokia). • Always use the provided cable clamp to lock the FastMile 5G Receiver pre-attached PoE cable indoors (on a window frame or on the wall) •...
Page 24
Slide the FastMile 5G Receiver into the mounting sleeve. Ensure that the signal test button faces towards the inside of the room (the Nokia logo should face outside). The FastMile 5G Receiver secures into place by clipping into the metal clip that is on the bottom of the mounting sleeve.
Connecting the Ethernet cable LAN cable to the PoE injector Figure 18 Make any other connections to your gateway. You can now manage the FastMile 5G Receiver through the Nokia Wireless Mobile App or through the WebUI. See About the WebUI for information about using the WebUI.
Page 29
Figure 20 Orient the desktop stand and FastMile 5G Receiver so that the signal test button faces towards the inside of the room (the Nokia logo should face outside), and place in position. If included in your kit, attach the cable clamp to the pre-attached PoE cable of the FastMile 5G Receiver and use it to secure the pre-attached PoE cable of the receiver to the windowsill, wall, or furniture.
Page 30
Connecting the Ethernet cable LAN cable to the PoE injector Figure 21 Make any other connections to your gateway. You can now manage the FastMile 5G Receiver through the Nokia Wireless Mobile App or through the WebUI. See About the WebUI for information about using the WebUI.
FastMile 5G Receiver to power). Do the following as appropriate: • if you are using the Nokia Wireless Mobile App to determine the best location, resume use of the app • run another speed test using Ookla through the Nokia Wireless Mobile App •...
