8.6 Display Mode Set Up (Cont.)
(2) Press the "DOWN" button three (3) times so that the cursor is now flashing over the
# 4 "DISPLAY MODE." option. The LCD will display the following with the cursor box
now flashing over the # 4 option.
(3) Press the "Record" button to enter the DISPLAY MODE option. The LCD will display
the following:
(4) Use the "UP" or "DOWN" button to change the mode from 255 to 100 or vice versa.
(5) Once changed, press the "RECORD" button to confirm and store your new setting.
(6) Press the "ESC" button two (2) times to exit.
3. P/T FADE ONLY
4
. DISPLAY MODE
DISPLAY MODE:255
OK ESC SEL ADJ
DMX OPERATOR PRO
37
