Section: 8 Menu Options Set Up

8.1 Access Menu Options

(1) Press and hold down the "SETUP" button for three (3) seconds or until the green
LED above the SETUP button comes on. The LCD will display the following with a
cursor box flashing over the # 1 option. Once you are here, you can use the "UP" and
"DOWN" buttons to scroll through the menu options.
•
Menu options include 1. CF CARD, 2. ASSIGN CH., 3. P/T FADE ONLY, 4. DISPLAY MODE,
5. MIDI CH.

8.2 Save to CF Card

(1) Press and hold down the "SETUP" button for three (3) seconds or until the green
LED above the SETUP button comes on. The LCD will display the following with a
cursor box flashing over the # 1 option.
(2) Press the "RECORD" button one (1) time so to enter the CF CARD option. The LCD
will display the following with the cursor box now flashing over the # 1 option- "READ
FROM CF".
(3) Press the "DOWN" button one (1) time so the cursor is now flashing over the # 2
option, "STORE TO CF", and press "RECORD" to enter. The LCD will display the
following:
1
. CF CARD
2. ASSIGN CH.
1
. CF CARD
2. ASSIGN CH.
1
. READ FROM CF
2. STORE TO CF
SETTING
OK ESC UP DOWN
DMX OPERATOR PRO
↓
↓
