TROUBLESHOOTING
SYMPTOM
Thermostat will not The Keypad is locked. Press both the
same time for one second to unlock (see section 5.5).
allow me to change
the setpoint.
Fan continues to run Check that the fan control switch is in the AUTO position. This
will allow the fan to run only when the heating or cooling system
all the time whether
is turned on and running.
the system is on
or off. Check thermostat wiring to make sure that the fan control
wiring is connected to the correct terminals on the wiring
terminal block. See Installation and Wiring Diagram sections of
this manual.
Fan continues to run The Residual Cooling Fan Control Feature can allow up to a 90
second fan delay after cooling system shutdown for energy
in cooling mode
efficiency gains. The default setting is 60 seconds. This can be
when the system has
changed to disable this feature or shorten the time period if
turned off.
desired. See Setting Residual Cooling Fan Feature section of
this manual.
The thermostat does
Change from Weekday-Weekend to 7 Day Mode
(see section 4.4).
not allow me to
program each day
separately.
System turns on prior
Thermostat is in Adaptive Recovery Mode – see section 5.6.
to the end of a
setback period.
7

WIRING DIAGRAM

Wiring Diagram for 2 Stage Heat, 2 Stage Cool Heat Pump Systems
R Y1 Y2 W2 E
Auxiliary
1st Stage
Compressor Heat Relay Fan Relay
Contact (stage 2)
2nd Stage
Emergency
Compressor
Heat Relay
Contact
(if equipped)
(if equipped)
NOTES:
1. User installed Jumper is required to use Auxiliary heat for both
second stage and emergency heat on units without separate
emergency heat and auxiliary heat terminals. DO NOT install jumper
if both terminals are present.
2. Eliminate connection to Y2 for units with single stage cooling.
3. Make O or B connections as required by unit.
cont.
POTENTIAL SOLUTION
or key together at the
G O B L C
Changeover
Relay-Heat
(see note 3)
Changeover System
Relay-Cool Monitor
(if equipped)
(See note 3)
24 VAC
16
Store this
booklet for
future reference
