Builder series non-programmable 2 heat / 1 cool multi-stage thermostat

Advertisement

Quick Links

MODEL
1100
USER MANUAL
Compatible with low voltage multi-stage
heat / cool systems with up to two stages of
heating and one stage of cooling.
READ ALL INSTRUCTIONS BEFORE PROCEEDING
CONTENTS

SPECIFICATIONS

1
2
INSTALLATION
3
TESTING YOUR NEW THERMOSTAT
PROGRAMMING USER SETTINGS
4
5
ADDITIONAL OPERATION FEATURES
TROUBLESHOOTING
6

WIRING DIAGRAM

7
© 2004 Braeburn Systems LLC • Patents Pending • All Rights Reserved. Pub. No. 1100-100-004
Builder Series
Non-Programmable
2 Heat / 1 Cool
Multi-Stage Thermostat
WARNING!
Important Safety Information
• Always turn off power to the air conditioning or heating system prior to installing,
removing, cleaning or servicing thermostat.
• Read this manual thoroughly prior to installing, programming or operating
this thermostat.
• This thermostat is designed for use with a 24 Volt-AC low voltage multi-stage
heat / cool system.
• Do not use this thermostat on systems with voltages higher than 30 Volt-AC.
• This thermostat requires 24 Volt AC power for normal operation and control of
the heating or cooling system.
• In the event of an AC power outage, the first and second stage temperature
differentials and the setpoint will return to their default system values. The user
can change the default settings once power is restored.
• Wiring must conform to all building codes and ordinances as required by local
and national code authorities having jurisdiction.
• Do not short (or jumper) across terminals on the gas valve or at the heating or
cooling system control board to test the thermostat installation. This could
damage the thermostat and void the warranty.
• Do not select COOL mode of operation if the outside temperature is below 50˚ F
(10˚ C). This could possibly damage the controlled cooling system and may
cause personal injury.
• This thermostat should only be used as described in this manual. Any other use
is not recommended and will void the warranty.
1
SPECIFICATIONS
• Electrical Rating: 24 Volt AC (18-30 Volt AC)
1 amp maximum load per terminal
3 amp total maximum load (all terminals)
• Control Range: 45˚ - 90˚ F (7˚ - 32˚ C)
• Accuracy: +/- 1˚ F (+/- .5˚ C)
• AC Power: 18-30 Volt AC
• Compatibility: Multi-stage heat / cool systems
with up to two stages of heating and one stage
of cooling.
• Terminations: R, O, B, C, Y, W1, G, W2
1
