USER GUIDE
Aleratec
DVD/CD Flash Copy Tower™
Part No. 310108

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DVD/CD Flash Copy Tower and is the answer not in the manual?

Questions and answers

Related Manuals for Aleratec DVD/CD Flash Copy Tower

Summary of Contents for Aleratec DVD/CD Flash Copy Tower

  • Page 1 USER GUIDE Aleratec DVD/CD Flash Copy Tower™ Part No. 310108...
  • Page 2 Copyright© 2013 Aleratec, Inc. 9851 Owensmouth Avenue Chatsworth, CA 91311 U.S.A. Aleratec® is a registered trademark, and DVD/CD Flash Copy Tower™ is a trademark of Aleratec, Inc Check out Aleratec Online! • Blog.Aleratec.com • Facebook.com/Aleratec • Twitter.com/Aleratec...
  • Page 3 TV reception. The user is cautioned that changes and/or modifications made to this equipment, without the approval of manufacturer, could void the user’s authority to operate this equipment. www.aleratec.com...
  • Page 4 Refer servicing to authorized personnel only. Make sure that the manually switchable power supply is set to the proper voltage for your region. CAUTION As the laser beam in these DVD/CD Flash Copy Tower is harmful to the eyes, do not attempt to disassemble the cabinet. Refer servicing to authorized personnel only. The use of optical instruments with this product will increase eye hazard.

  • Page 5: Table Of Contents

    Table of Contents Introduction ....................1 Product Features ....................1 Key Items ......................2 DVD/CD Flash Copy Tower: Display Panel and Buttons ........2 Function List ......................3 Precautions ....................5 Installation ......................5 Operation ......................5 Transportation ......................5 Overview......................6 Main Menu ......................6 Subfunctions ......................7 Using the DVD/CD Flash Copy Tower ............10 Checking the Device Information ..............10...
  • Page 6 www.aleratec.com...

  • Page 7: Introduction

    User Guide thoroughly before using this product. Product Features The DVD/CD Flash Copy Tower is a Memory Card/USB flash drive to disc copier. No PC needed, no limitation of Memory Card size, just a very simple key button, you can easily backup from Memory Cards or USB flash drive to DVD or CD disc.

  • Page 8: Key Items

    Good care will help assure maximum product life. Improper operating environment and misuse may void the warranty. DVD/CD Flash Copy Tower: Display Panel and Buttons (View may vary from picture) Function Firmware Version...

  • Page 9: Function List

    5.5 Burn Speed Set the burning speed of DVD/CD writing 5.6 Beep Sound Set “ON” or “Off” of the beep sound function 5.7 Advance Setup Set disc space that will not be used and back light time www.aleratec.com...
  • Page 10 Introduction Note: Flash media (Memory Card and USB) will be recognized by the DVD/CD Flash Copy Tower only when the format is FAT 12, 16, or 32. Note: Use only one source at a time. ONLY ONE Memory Card or ONLY ONE USB flash drive may be plugged in at a time.

  • Page 11: Precautions

    Operation Do not move the DVD/CD Flash Copy Tower during operation. This may cause it to malfunction during operations. Avoid exposing the unit to sudden changes in temperature as condensation may form inside the DVD/CD Flash Copy Tower.

  • Page 12: Overview

    Overview Main Menu There are 5 main menu items that will display in the DVD/CD Flash Copy Tower Display Panel. These are: 1. Copy 2. Compare 3. Information 4. Utility 5. Set Up www.aleratec.com...

  • Page 13: Subfunctions

    1.1 Memory Card to Disc 1. Copy 1.2 USB to Disc 1.3 Disc to Disc The main menu “Compare” function has 3 subfunctions. These are: 2.1 Memory Card to Disc 2. Compare 2.2 USB to Disc 2.3 Disc to Disc www.aleratec.com...
  • Page 14 The main menu “Information” function has 5 subfunctions. These are: 3.1 Memory Card Info 3.2 USB Info 3. Information 3.3 Disc Info 3.4 Drive Info 3.5 System Info The main menu “Utility” function has 2 subfunction. These are: 4.1 System Update 4. Utility 4.2 Demo I/O www.aleratec.com...
  • Page 15 Overview The main menu “Set Up” function has 7 subfunctions. These are: 5.1 Copy + Compare 5.2 Multi-Session 5. Set Up 5.3 Disc Spanning 5.4 Burn Multidisc 5.5 Burn Speed 5.6 Beep Sound 5.7 Advance Setup www.aleratec.com...

  • Page 16: Using The Dvd/Cd Flash Copy Tower

    Using the DVD/CD Flash Copy Tower Checking the Device Information Before copying, it is recommended that you check each Memory Card, USB, or DVD/CD’s content information. Checking Memory Card Information Select 3. Information, → Select 1. M-Card info → Press OK → The DVD/CD Flash Copy Tower will show the information of this Memory Card.
  • Page 17 Using the DVD/CD Flash Copy Tower Checking Disc Information Select 3. Information, → Select 3. Disc info → Press OK → The DVD/CD Flash Copy Tower will show the information of this Disc. Disc Spanning Disc Information: If the disc was copied from Disc Spanning you will see the disc sequence.

  • Page 18: Disc Spanning

    Total size to be copied When a disc is finished copying, it will be ejected. If the Disc Spanning process is not complete, the DVD/CD Flash Copy Tower will prompt you for a new blank disc to continue the copying.

  • Page 19: Multi-Session Backup

    Note: Keep disc type consistent when using Disc Spanning. For example, if you place a CD-R as the first disc for copying, do not place a DVD-R or DVD+R to continue copying. The DVD/CD Flash Copy Tower will show an error message and ask for another blank CD-R.

  • Page 20: Function Overview: 1. Copy

    Total size to be copied When a disc is finished copying, it will be ejected. If the Disc Spanning process is not complete, the DVD/CD Flash Copy Tower will prompt you for a new blank disc to continue the copying.
  • Page 21 Total size to be copied When a disc is finished copying, it will be ejected. If the Disc Spanning process is not complete, the DVD/CD Flash Copy Tower will prompt you for a new blank disc to continue the copying.
  • Page 22 Using the DVD/CD Flash Copy Tower Disc to Disc This function allows you to copy DVD to DVD(s) and CD to CD(s). Note: CD will copy only to CD. DVD will only copy to DVD. Place your source disc into a Reader, and blank discs into Writers.

  • Page 23: Function Overview: 2. Compare

    Memory Card to Disc Compare Insert a Memory Card (e.g. SD, MS) and place a completed written DVD or CD disc into the DVD/CD Flash Copy Tower. Select 2. Compare, → Select 1. M-Card to Disc → Press OK → The DVD/CD Flash Copy Tower will begin comparison.
  • Page 24 Using the DVD/CD Flash Copy Tower USB to Disc Compare Insert a USB flash drive and place a finish burner DVD or CD disc into the DVD/CD Flash Copy Tower. Select 2. Compare, → Select 2. USB to Disc → Press OK → The DVD/CD Flash Copy Tower will begin comparison.
  • Page 25 Compare Result Pass 1 Fail 0 Note: The DVD/CD Flash Copy Tower “Compare” function is to do file by file comparison. Therefore, Copy and Compare speeds will be affected by some factors such as the number of files, and the disc reading speed.

  • Page 26: Function Overview: 3. Information

    Total file number on the Memory Card USB Information Insert a USB flash drive into the DVD/CD Flash Copy Tower. Select 3. Information, → Select 2. USB info → Press OK → The DVD/CD Flash Copy Tower will show the information of this USB flash drive.

  • Page 27: System Information

    Using the DVD/CD Flash Copy Tower Disc Information Insert a disc into the DVD/CD Flash Copy Tower. Select 3. Information, → Select 3. Disc info → Press OK → The DVD/CD Flash Copy Tower will show the information of this Disc.  [1] 1 Session...

  • Page 28: Function Overview: 4. Utility

    Using the DVD/CD Flash Copy Tower Function Overview: 4. Utility System Update The DVD/CD Flash Copy Tower can use a USB flash drive drive to update the system firmware. Download / Copy the updated System Firmware to a USB flash drive.

  • Page 29: Function Overview: 5. Setup

    Using the DVD/CD Flash Copy Tower Function Overview: 5. Setup Copy+Compare You can change the COPY function in the main menu to COPY+COMPARE by enabling this function. Select 5. Setup → Select 41. Copy+Compare → Select Enable → Press OK → Copy mode will now be changed to Copy+Compare.

  • Page 30: Advanced Setup

    This function is used to set the time the LCD screen will enter a screen saving mode. Language This function is used to set the language of the DVD/CD Flash Copy Tower. Factory Default This function returns the DVD/CD Flash Copy Tower back to its original default settings.

  • Page 31: Specifications

    Specifications Model DVD/CD Flash Copy Tower Operation Stand Alone Function • DVD copy to DVD • CD copy to CD • Memory Card copy to DVD/CD disc • USB flash drive copy to DVD/CD disc • Data comparison of backup Memory Card or USB Backup •...

  • Page 32: Technical Support Addresses And Phone Numbers

    After reading this User Guide, if you need additional assistance with this product, please contact Aleratec Technical Support. Our technical staff will be happy to assist you, but they may need your help to better assist you. Calling Aleratec Technical Support without all the necessary information can be both time consuming and frustrating.

  • Page 33: Service And Support

    www.aleratec.com...
  • Page 34 www.aleratec.com...
  • Page 35 www.aleratec.com...

  • Page 36: Technical Support Fax Back Form

    Place of Purchase: _____________________________________________________ To: Technical Support Group FAX: 1-818-678-0483 FROM: ________________________ FAX: _______________________________ E-MAIL ____________________________ RE: ___________________________ TEL: _______________________________ DATE: __________________ # OF PAGES: _______________________________ I am experiencing the following problems with my DVD/CD Flash Copy Tower: ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ By answering these questions, your problem will be solved more rapidly. Make copies as necessary.
  • Page 37 Notes: www.aleratec.com...
  • Page 38 Document Number: 9399056_ENG_Rev. F Copyright © 2013 Specifications subject to change without notice. Aleratec, Inc. 9851 Owensmouth Avenue Chatsworth, CA 91311 U.S.A. www.aleratec.com...
