- Page 1 User Manual SIMB-M22 AMD G-Series APU with A55E Controller Hub (FCH) Mini-ITX Motherboard...
-
Page 2: Safety Information
The symbol of the crossed out wheeled bin indicates that the product (electri- cal and electronic equipment) should not be placed in municipal waste. Check local regulations for disposal of electronic products. Part No. 20060M2200 Edition 1 Printed in China September 2011 SIMB-M22 User Manual... -
Page 3: Technical Support
If a problem arises with your system and no solution can be obtained from the user’s manual, please contact your place of purchase or local distributor. Alternatively, please try the following help resources for further guidance. Visit the Advantech web- site for FAQ, technical guide, BIOS updates, driver updates, and other information: http://support.advantech.com/support/default.aspx... - Page 4 SIMB-M22 User Manual...
-
Page 5: Table Of Contents
2.8.5 LCD POWER (VDDSAFE) (JBL3) ..........23 2.8.6 Serial Port Connector (COM3, COM4) ........24 2.8.7 System Panel & Speaker (JFP1 + JFP2)........24 2.8.8 Power LED & Keylock (JFP3) ............. 25 2.8.9 Inverter PWR (JBL1)..............25 SIMB-M22 User Manual... - Page 6 Legend Box................. 32 3.1.2 List Box ..................33 3.1.3 Sub-menu ................... 33 BIOS Menu Screen ................. 33 3.2.1 BIOS Menu Screen..............34 3.2.2 Advanced..................34 3.2.3 Chipset..................41 3.2.4 Boot .................... 46 3.2.5 Save & Exit ................. 47 SIMB-M22 User Manual...
-
Page 7: Chapter 1 Product Overview
Chapter Product Overview... -
Page 8: Specifications Summary
H.264, VC-1, MPEG-2, DivX decode LVDS 1, 18bpp (Single link LVDS up to 1400 x 1050) 1, supports up to 1920 x 1200 HDMI 1,support HDMI 1.3a & 1080p up to 1920 x 1080 Dual Display VGA+LVDS, VGA+HDMI, HDMI+LVDS SIMB-M22 User Manual... - Page 9 LPC to COM 2 COM with headers Super I/O Chipset Winbond W83627DHG-P Fan speed monitor & control FAN Speed Control by Thermal Sensor Temperature Voltage +3.3V, +5V, 5Vsb, +12V, -12V Buzzer Onboard buzzer Watchdog Timer Programmable 1~255 sec/min SIMB-M22 User Manual...
-
Page 10: Bios
Power Play 380, 200MHz, configure Power to 2.7 ~ 5.7 W SATA Support SATA III (6Gbps) 1.1.5 Internal Connector Debug Port HDT header Display LVDS 1, (optional) Inverter LVDS INV 1, 3.3 V Audio Front Panel Amplifier SPDI/F SIMB-M22 User Manual... -
Page 11: Front I/O
1, co-layout with header Ethernet RJ-45 2, stack with USB 4 (USB 2.0 port) Serial port 2 RS-232 PS/2 KB/MS 2, co-lay single DIN Audio 1 Line-in 1 Line-out Phone Jack 1 MIC co-lay 1 jack connector SIMB-M22 User Manual... -
Page 12: Power
Model name in silkscreen None Revision in silkscreen PCB Color Green CE mark on PCB WEEE Advantech PCB part number Version FCC mark on PCB Cert. Compliance Pre-scan for Class B, EN-55022/24 Pre-scan for FCC PART 15, Class B IEC-60601... -
Page 13: Accessory
8 x USB 2.0 ports USB 2.0 6Gb/s 5 x SATA 3.0 ports SATA 3.0 SPI ROM Fintek Winbond 81216AD 83627DHG-P 2 x RS-232 ports, 2 x RS-232 ports 2 x PS/2 KB/MS, H/W Monitor, 8-bit GPIO Figure 1.1 Block Diagram SIMB-M22 User Manual... - Page 14 SIMB-M22 User Manual...
-
Page 15: Chapter 2 Product Introduction
Chapter Product Introduction This chapter describes the main board features and the new tech- nologies it supports. -
Page 16: Before You Proceed
Placement Direction When installing the motherboard, make sure that you place it into the chassis in the correct orientation. The edge with external ports goes to the rear part of the chassis as indicated in the image below. SIMB-M22 User Manual... -
Page 17: Screw Holes
Place four (4) screws into the holes indicated by circles to secure the motherboard to the chassis. Warning! Do not over tighten the screws! Doing so can damage the motherboard. Place this side towards the rear of the chassis. SIMB-M22 User Manual... -
Page 18: Motherboard Layout
204-PIN SODIMM slot 1 204-PIN Table 2.2: Jumpers Label Function Note CLRTC Clear CMOS 3 x 1 header, pitch 2.54mm JCOMPWR1 COM1 RI/+5V/+12V Selection 3 x 2 header, pitch 2.0mm JCOMPWR2 COM2 RI/+5V/+12V Selection 3 x 2 header, pitch 2.0mm SIMB-M22 User Manual... -
Page 19: Table 2.3: Rear Io
Important! Do not forget to connect the CPU Fan connector! Hardware monitoring errors can occur if you fail to plug this connector. Warning! After installation, make sure to plug-in the ATX power cable to the moth- erboard. SIMB-M22 User Manual... -
Page 20: Connect The Cpu Fan Cable
These are not jumpers! DO NOT place jumper caps on the fan con- nectors. Warning! After installation, make sure to plug-in the ATX power cable to the moth- erboard. SIMB-M22 User Manual... -
Page 21: System Memory
This motherboard does not support memory modules made up of 128 Mb chips or double-sided x16 memory modules. Make sure that the memory frequency matches the CPU FSB (Front Side Bus). Refer to the Memory frequency/CPU FSB syn- chronization table. SIMB-M22 User Manual... -
Page 22: Installing A Ddr3 Dimm
A DDR3 DIMM is keyed with a notch so that it fits in only one direc- tion. DO NOT force a DIMM into a socket to avoid damaging the DIMM. The DDR3 DIMM sockets do not support DDR DIMMs. DO NOT install DDR DIMMs to the DDR3 DIMM socket. SIMB-M22 User Manual... -
Page 23: Removing A Ddr3 Dimm
Align the card connector with the slot and press firmly until the card is com- pletely seated on the slot. Secure the card to the chassis with the screw you removed earlier. Replace the system cover. SIMB-M22 User Manual... -
Page 24: Configuring An Expansion Card
3 for about 5~10 seconds, then move the cap back to pins 1-2. Re-install the battery. Plug the power cord and turn ON the computer. Hold down the <Del> key during the boot process and enter BIOS setup to re- enter data. SIMB-M22 User Manual... -
Page 25: Com3 Ri/+5V/+12V Selection (Jsetcom3)
Caution! Except when clearing the CMOS, never remove the cap on CLRTC jumper default position. Removing the cap will cause system boot fail- ure! Normal (Default) Clear CMOS 2.7.2 COM3 RI/+5V/+12V Selection (JSETCOM3) +5V (Default) +12V Ring SIMB-M22 User Manual... -
Page 26: Com4 Ri/+5V/+12V Selection (Jsetcom4)
2.7.3 COM4 RI/+5V/+12V Selection (JSETCOM4) +5V (Default) +12V Ring Connectors 2.8.1 Rear Panel Connectors Figure 2.2 Rear Panel Connectors SIMB-M22 User Manual... - Page 27 USB 2.0 connector ports are available for connecting USB 2.0 devices. HDMI This 15-pin port is for a VGA monitor or other VGA_DVI VGA port VGA-compatible devices. 10 KBMS PS/2 KB connector This port is for a PS/2 keyboard SIMB-M22 User Manual...
-
Page 28: Front Panel Audio Connector (Aafp)
ATX Power Connector (ATXPWR) These connectors are for ATX power supply plugs. The power supply plugs are designed to fit these connectors in only one orientation. Find the proper orientation and push down firmly until the connectors completely fit. SIMB-M22 User Manual... -
Page 29: At/Atx Mode Select (Pson1)
You must install a PSU with a higher power rating if you intend to install additional devices. 2.8.4 AT/ATX Mode Select (PSON1) AT Mode ATX Mode 2.8.5 LCD POWER (VDDSAFE) (JBL3) 3.3 V SIMB-M22 User Manual... -
Page 30: Serial Port Connector (Com3, Com4)
2.8.6 Serial Port Connector (COM3, COM4) COM3 COM4 2.8.7 System Panel & Speaker (JFP1 + JFP2) PIN7-10Internal SPKPIN3-6POWER BT PIN1-10External SPKPIN9-12SYS_RESET SIMB-M22 User Manual... -
Page 31: Power Led & Keylock (Jfp3)
2.8.8 Power LED & Keylock (JFP3) 2.8.9 Inverter PWR (JBL1) SIMB-M22 User Manual... -
Page 32: Spi Connector (Cn4)
2.8.10 SPI connector (CN4) 2.8.11 SPDIF OUT (SPDIF_OUT1) SIMB-M22 User Manual... -
Page 33: 18-Bit Lvds Connector (Lvds1)
2.8.12 18-bit LVDS Connector (LVDS1) 2.8.13 AMP_R+R-/AMP_L+L- (CN10) SIMB-M22 User Manual... -
Page 34: Serial Ata Connector (Sata1, Sata2)
Install the Windows® 2000 Service Pack 4 or the Windows® XP Service Pack1 before using Serial ATA. When using the connectors in Standard IDE mode, connect the pri- mary (boot) hard disk drive to the SATA1 connector. SIMB-M22 User Manual... -
Page 35: Usb 2.0 Connector (Usb56)
These USB connectors comply with USB 2.0 specification that sup- ports up to 480 Mbps connection speed. Caution! Never connect a 1394 cable to the USB connectors. Doing so will dam- age the motherboard! Note! The USB module is purchased separately. SIMB-M22 User Manual... - Page 36 SIMB-M22 User Manual...
-
Page 37: Bios Setup
Chapter BIOS Setup This chapter tells how to change the system setting through the BIOS setup menus. Detailed descriptions of the BIOS parame- ters are also provided. -
Page 38: Bios Setup Program
The keys in the legend bar allow you to navigate through the various setup menus. Key(s) Function Description ← Select Screen ↑ , ↓ Select Item Change Option / Field Enter Go to Sub Screen PGDN Next Page PGUP Previous Page General Help Previous Values Optimized Defaults Save & Exit Exit SIMB-M22 User Manual... -
Page 39: List Box
To access the menu items, press the up/down/right/left arrow key on the keyboard until the desired item is highlighted, then press [Enter] to open the specific menu. SIMB-M22 User Manual... -
Page 40: Bios Menu Screen
You can display an Advanced BIOS Setup option by highlighting it using the <Arrow> keys. All Advanced BIOS Setup options are described in this section. The Advanced BIOS Setup screen is shown below. The sub menus are described on the following pages. SIMB-M22 User Manual... - Page 41 ACPI Setting System ACPI Parameters ACPI Sleep State Select the highest ACPI Sleep state the system will enter when the SUSPEND button is pressed. Only supports S3. S3 Video Repost Enable or Disable S3 Video. SIMB-M22 User Manual...
- Page 42 Enable/disable the generation of ACPI_PPC, _PSS, and _PCT objects. PSTATE Adjustment To adjust startup P-state level. PPC Adjustment To adjust _PPC object. NX Mode Enable/disable No-execute page protection Function. SVM Mode Enable/disable CPU Virtualization. C6 Mode Enable/disable C6. SIMB-M22 User Manual...
- Page 43 <Arrow> keys to select an item. Use the <Plus> and <Minus> keys to change the value of the selected option. A description of the selected item appears on the right side of the screen. The settings are described on the following pages. SIMB-M22 User Manual...
- Page 44 USB device is detected, the legacy USB support is disabled. Configuration options: [Disabled] [Enabled] [Auto]. BIOS EHCI Hand-Off [Enabled] Allows you to enable support for operating systems without an EHCI hands off feature. Configuration options: [Disabled] [Enabled]. SIMB-M22 User Manual...
- Page 45 3.2.2.5 Second Super IO Configuration Serial Port 3 Configuration Set Parameters of Serial Port 3 (COMC). Serial Port 4 Configuration Set Parameters of Serial Port 4 (COMD). 3.2.2.6 Super IO Configuration SIMB-M22 User Manual...
- Page 46 Set Parameters of Serial Port 1 (COMA). Serial Port 2 Configuration Set Parameters of Serial Port 2 (COMB). 3.2.2.7 H/W Monitor Smart Fan Function Enable or Disable Smart Fan. Smart Fan Mode Configuration Smart Fan Mode Select. SIMB-M22 User Manual...
-
Page 47: Chipset
The items in this menu allow you to change the Chipset-related features. Select North Bridge Configuration and press <Enter> for further configuration options. 3.2.3.1 North Bridge The screen displays the auto-detected DDR3 SO-DIMM specifications in more detail. SIMB-M22 User Manual... - Page 48 IOMMU is supported on LINUX based systems to convert 32bit I/O to64bit MMIO. Memory Clear Memory Clear functionality control. 3.2.3.1.1Memory Configuration This screen allows you to configure the graphics options. Integrated Graphics Enable Integrated Graphics controller. UMA Frame buffer Size Set UMA FB size. SIMB-M22 User Manual...
- Page 49 3.2.3.1.2Node 0 Information View memory Information related to Node 0. 3.2.3.2 North Bridge LVDS Config Select DP0 Output Mode NB PCIE Connect Type (Display device). DP1 Output Mode NB PCIE Connect Type (Display device). SIMB-M22 User Manual...
- Page 50 LVDS Panel Config Select 800x600 1024x768 1280x720 1280x800 1280x1024 1366x768 1440x900 1600x900 1920x1024 Brightness Control Value Input Brightness Value (Range:0 - 255). EDID Panel Option EDID Panel Option. 3.2.3.3 South Bridge SIMB-M22 User Manual...
- Page 51 3.2.3.3.1SB SATA Configuration Options for SATA Configuration. OnChip SATA Type Native IDE/ n RAID /n AHCI /n AHCI /n Legacy IDE /n IDE->AHCI /n Hyper- Flash. 3.2.3.3.2SB USB Configuration Options for SB USB Configuration. SIMB-M22 User Manual...
-
Page 52: Boot
Configuration options: [Upon Request] [Always] Option ROM Messages [Force BIOS] Set display mode for option ROM. Configuration options: [Force BIOS] [Keep Current]. Interrupt 19 Capture [Disable] Enabled: Allow option ROMs to trap Int19. Configuration options: [Disabled][Enabled]. SIMB-M22 User Manual... -
Page 53: Save & Exit
If you made changes to fields other than System Date, Sys- tem time, and Password, the BIOS asks for a confirmation before exiting. Restore Defaults Restore the user defaults to all the setup options SIMB-M22 User Manual... - Page 54 No part of this publication may be reproduced in any form or by any means, electronic, photocopying, recording or otherwise, without prior written permis- sion of the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2011...
