Advantech SIMB-A01 Startup Manual

SIMB-A01
Intel® Q35 LGA775 socket for Intel® Core™ 2
Quad ATX Motherboard
Packing List
Before you begin installing your card, please make sure that
the following items have been shipped:
• 1 x Intel Q35 ATX Main board
• 1 x CD ROM per carton, which contains the followings:
- User's Manual in PDF file
- Drivers
• 1 x SATA cable kit (SATA/Power)
• 1 x I/O Shield
• 1 x Startup Manual per carton
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
Note1:
Acrobat Reader is required to view any PDF file. Acrobat
Reader can be downloaded at: www. adobe.com/Prodindex/
acrobat/readstep.html (Acrobat is a trademark of Adobe).
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/eplatform
For technical support and service, please visit our
support website at:
http://www.advantech.com/support
This manual is for the SIMB-A01 series Rev. A1.
Part No. 20060A0110
Printed in China
Startup Manual
Specifications
System
• CPU: Intel® Q35 LGA775 socket for Intel® Core™ 2
Quad / Core™2 Duo / processors compatible with Intel®
05B/05A/06 processors support Intel® next generation
45nm multi-core CPU
• FSB: 1333 / 1066 / 800 MHz
• BIOS: AMI 32 Mb SPI BIOS
• System Chipset: Intel Q35 GMCH/ICH9R
• I/O Chipset: Winbond W83627DHG-A
• Memory: Four 240-pin DIMM sockets support up to 8 GB
Dual Channel DDR2 800/667 SDRAM
• Watchdog Timer: Reset: 1 sec.~255 min. and 1 sec. or 1
min./step
• H/W Status Monitor: Monitoring temperatures, voltages,
and cooling fan status. Auto throttling control when CPU
overheats
• Expansion Slots: 1 x PCI Express x16, 1 x PCI Express
x1, 5 x PCI (PCI Rev. 2.3 compliant)
• DIO: 16 bit (8-in/8-out by PCA9555)
• S3 / S4: Yes
• TPM: TPM1.2 (Infineon® TPM chip 9635 TT 1.2 on board)
• Wake up on LAN or Ring: LAN (PME / RPL)
• Smart Fan Control: Yes , support 3 modes (Silent/Opti-
mal/Performance)
Display
• Chipset: Intel Q35 GMCH integrated Graphics Media
Accelerator 3100
• Display Memory: Intel DVMT 4.0 supports up to 384 MB
video memory
• Max. Resolution: 2048 x 1536 bpp(@ 75Hz)
• VGA: Yes , on board GMA 3100
• LVDS / DVI / HDMI: Through ADD2 LVDS Card
• Secondary VGA: Yes , through ADD2 card
Audio
• Audio Codec: Realtek® ALC888, 7.1 W/O multiple
streaming or 5.1+2 with multiple streaming HD audio
• Audio Interface: Mic in, Line in, Line out
• Audio Amplifier (W): Dual 6W Amp.(TPA3005D2 ,
Optional)
Ethernet
• LAN1: RTL8111C Gigabit LAN
• LAN2: RTL8111C Gigabit LAN
1st Edition
July 2011
SIMB-A01 Startup Manual 1
