Advantech SIMB-U01 Startup Manual

SIMB-U01
Intel® Q45 LGA775 socket for Intel® Core™ 2 Quad Micro ATX Motherboard
Startup Manual
Packing List
Before you begin installing your card, please make sure that
the following items have been shipped:
• 1 x Intel Q45 Micro ATX Main board
• 1 x CD ROM per carton, which contains the followings:
- User's Manual in PDF file
- Drivers
• 1 x SATA cable kit (SATA/Power)
• 1 x I/O Shield
• 1 x Startup Manual per carton
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
Note1:
Acrobat Reader is required to view any PDF file. Acrobat
Reader can be downloaded at: www. adobe.com/Prodindex/
acrobat/readstep.html (Acrobat is a trademark of Adobe).
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/eplatform
For technical support and service, please visit our
support website at:
http://www.advantech.com/support
This manual is for the SIMB-U01 series Rev. A1.
Part No. 20060U0110
Printed in China
Specifications
System
• CPU: Intel® Q45 LGA775 socket for Intel® Core™2
Quad / Core™2 Duo processors compatible with Intel®
06 processors Supports Intel® next generation 45nm
multi-core CPU
• FSB: 1333 / 1066 / 800 MHz
• BIOS: Award 32 Mb SPI BIOS
• System Chipset: Intel Q45 GMCH/ICH10DO
• I/O Chipset: Winbond W83627DHG-A
• Memory: Four 240-pin DIMM sockets support up to 8 GB
Dual Channel DDR2 800 / 667 MHz
• Watchdog Timer Reset: 1 sec.~255 min. and 1 sec. or 1
min./step
• H/W Status Monitor: Monitoring temperatures, voltages,
and cooling fan status. Auto throttling control when CPU
overheats
• Expansion Slots: 1 x PCI Express 2.0 x16, 1 x PCIe_x1 ,
2 x PCI (PCI Rev. 2.3 compliant)
• DIO: 16-bit (8 in 8 out)
• S3 / S4: Yes
• TPM: Intel Integrated TPM1.2
• Wake up on LAN or Ring: LAN (PXE / RPL)
• Smart Fan Control: Yes
Display
• Chipset: Intel® Graphics Media Accelerator 4500
integrated
• Display Memory: Intel DVMT 4.0 supports up to 352 MB
video memory
• Max. Resolution: 2048 x 1536 bpp(@ 75Hz)
• VGA: Yes , on board GMA 4500
• LVDS / DVI / HDMI: Yes , through ADD2 card
• Secondary VGA: Yes , through ADD2 card
Audio
• Audio Codec: Realtek® ALC888, 5.1 +2 with two inde-
pendent Streaming
• Audio Interface: Line-out, Line-in, Mic-in, SPDIF header
Ethernet
• LAN1: Intel® 82567-LM PCI-E Gigabit LAN
1st Edition
July 2011
SIMB-U01 Startup Manual 1
