- Page 1 User Manual SOM-DB4700 Development Board...
- Page 2 No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. Information provided in this manual is intended to be accurate and reliable. How- ever, Advantech Co., Ltd.
-
Page 3: Connector And Jumper Setting
Chapter Connector and Jumper Setting This chapter gives you connector and jumper information on the SOM-DB4700 Evaluation Carrier Board. Sections include: Connector and Jumper Table Connector and Jumper Pin Defi- nition... -
Page 4: Location Of Connectors
J2 & J1 PCI3 LVDS1 PCI2 JSET_ COM1 PCI1 LAN1 SATA I2C1 & 3 & 4 SMB1 SATA IDE1 1 & 2 FDD1 LPT2 COM3 FDD2 DVI1 JFP1 ATX1 COM4 MPCIE1 MPCIE2 SDVO1 J4 & J5 IDE2 SOM-DB4700 User Manual... -
Page 5: Connector List
PCIe x1 Connector* (XTX only) PCI1 PCI1 Connector* PCI2 PCI2 Connector* PCI3 PCI3 Connector* SATA1 SATA1 Connector* (XTX only) SATA2 SATA2 Connector* (XTX only) SATA3 SATA3 Connector* (XTX only) SATA4 SATA4 Connector* (XTX only) SMB1 SMBus Connector SOM1A ETX Connector A* SOM-DB4700 User Manual... -
Page 6: Jumper Table
Jumper Table J1, J2 COM port 1, 2 function selection J4, J5 COM port 3, 4 function selection RTC1 RTC power and clear selection CF Master/Slave selection ISA and PCI3 function selection PSON1 AT/ATX mode selection SOM-DB4700 User Manual... - Page 7 CD Line-In Connector Pin Name CD-L_B CD-G_B CD-G_B CD-R_B HD Audio Digital I/O Connector (XTX only) Pin Name AZ_SYNC AZ_BITCLK AZ_SDOUT AZ_SDIN0 AZ_SDIN1 AZ_RST# +V12 LCD Inverter Power Connector Pin Name # : low active +12 V BLON# SOM-DB4700 User Manual...
- Page 8 COM Port 2 Connector Pin Name # : low active NDCD#2 NDSR#2 NRXD2_TXD485+ NRTS#2 NTXD2_RXD485+ NCTS#2 NDTR#2_RXD485- COMB COM3 COM Port 3 Connector Pin Name # : low active NDCD#3 NDSR#3 NRXD3_TXD485+ NRTS#3 NTXD3_RXD485+ NCTS#3 NDTR#3_RXD485- COMC SOM-DB4700 User Manual...
- Page 9 # : low active NDCD#4 NDSR#4 NRXD4_TXD485+ NRTS#4 NTXD4_RXD485+ NCTS#4 NDTR#4_RXD485- COMD CPUFAN1 CPU FAN 1 Connector Pin Name FAN_Power FAN_TACHOIN DVI1 DVI Connector Pin Name DVI1_Z_TDC-0 VCC_TMDS DVI1_Z_TDC+0 DVI1_Z_TLC- DVI1_Z_TLC+ DVI1_Z_TDC-1 DVI1_Z_TDC+1 DVI1-SC_DDC DVI1-SD_DDC DVI1_Z_TDC-2 DVI1_HPDETT DVI1_Z_TDC+2 VCC_TMDS SOM-DB4700 User Manual...
- Page 10 Front Panel Connector Pin Name PW-LED PW-LED BUZZER KBINH# SPEKER HD_LED PWRBIN# FPRST1 Pin Function Description 11 & 13 Power Button 18 & 20 Reset Button 6 & 8 Speaker to Buzzer (Default) 12 & 14 HDD LED SOM-DB4700 User Manual...
- Page 11 Pin Name # : low active COM_RXD2 RXD485 COM_RXD2 RXD422 COM_RXD2 RXD232 NDCD#2 NRXD2 NDCD#2_TXD485- NRXD2_TXD485+ TXD485- TXD485+ NTXD2 NDTR#2 NTXD2_RXD485+ NDTR#2_RXD485- RXD422+ RXD422- KBMS1 PS2 KB/MS 1 Connector Pin Name KBDAT1 VCCKB KBCLK1 MSDAT1 VCCKB MSCLK1 SOM-DB4700 User Manual...
- Page 12 LPC Connector (XTX only) Pin Name LPC_DRQ#0 LPC_AD0 LPC_DRQ#1 LPC_AD1 LPC_SERIRQ LPC_AD2 LPC_FRAME# LPC_AD3 LPC_a_RST# CLK33M_LPC2 +V3.3 LPT2 LPT 2 Connector Pin Name SSTB_A# SAFD# SSPD0 SERR# SSPD1 SINIT# SSPD2 SSLIN# SSPD3 SSPD4 SSPD5 SSPD6 SSPD7 SACK# SOM-DB4700 User Manual...
- Page 13 SBUSY SSLCT LVDS1 LVDS/TTL interface Connector Pin Name +V5_LCD +V5_LCD +V3.3_LCD +V3.3_LCD TXCLK1-/LCDB0_A TXCLK1+/LCDB1_A TX13-/LCDB2_A TX13+/LCDB3_A TXCLK0-/LCDB4_A TXCLK0+/LCDB5_A TX03-/LCDG0_A TX03+/LCDG1_A TX10-/LCDG2_A TX10+/LCDG3_A TX11-/LCDG4_A TX11+/LCDG5_A TX00-/LCDR0_A TX00+/LCDR1_A TX01-/LCDR2_A TX01+/LCDR3_A TX02-/LCDR4_A TX02+/LCDR5_A DDAT DCLK SHFCLK TX12+/FPVSYNC_A LCD_DETECT#/DE TX12-/FPHSYNC_A SOM-DB4700 User Manual...
- Page 14 System Fan 2 Connector Pin Name 12 V FAN_IO2 TV-out Connector Pin Name TV_Y TV_C TV_COMP TV_SYNC Jumper Settings: COM Port 1&2 Mode Setting Jumper Setting RING DON'T CARE 3-5/4-6 VCC5 1-3/2-4 1-3/2-4 +12 V 3-5/4-6 1-3/2-4 SOM-DB4700 User Manual...
- Page 15 ISA&PCI3 Function Setting Jumper Setting PCI3 3-5 4-6 9-11 10-12 1-3 2-4 7-9 8-10 (Default) AT/ATX mode setting Jumper Setting PSON1 AT Power MODE ATX Power MODE (Default) Note! The “#” sign indicates low-active or negative-level triggered signals. SOM-DB4700 User Manual...
- Page 16 No part of this publication may be reproduced in any form or by any means, electronic, photocopying, recording or otherwise, without prior written permis- sion of the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2011...
