Advantech SIMB-M01 Startup Manual

SIMB-M01
Intel® Atom D525 Mini-ITX Motherboard
Startup Manual
Packing List
Before you begin installing your card, please make sure that
the following items have been shipped:
• 1 x Intel D525 mini-ITX Main board
• 1 x CD ROM per carton, which contains the followings:
- User's Manual in PDF file
- Drivers
• 1 x SATA cable kit (SATA/Power)
• 1 x I/O Shield
• 1 x Startup Manual per carton
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
Note1:
Acrobat Reader is required to view any PDF file. Acrobat
Reader can be downloaded at: www. adobe.com/Prodindex/
acrobat/readstep.html (Acrobat is a trademark of Adobe).
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/eplatform
For technical support and service, please visit our
support website at:
http://www.advantech.com/support
This manual is for the SIMB-M01 series Rev. A1.
Part No. 20060M0110
Printed in China
Specifications
System
• CPU: Onboard Intel® Atom D525 DC 1.8GHz Processor
• BIOS: AMI 8Mb SPI
• System Chipset: Intel® NM10
• I/O Chipset: FINTEK F71869ED
• Memory: Two 204-pin SO-DIMM sockets support up to
4GB Single Channel DDR3 800 MHz SDRAM
• H/W Status Monitor: Monitoring temperature, voltage
and cooling fan status. Auto throttling control when CPU
overheats
• Expansion Slots: 1 PCI-E x 1
• Power State: S1, S3, S4, S5
• Wake up on LAN or Ring: LAN (WOL) and Ring (WO)
• Smart Fan Control: Yes
Display
• Chipset: Integrated Intel® GMA Gen3.5 DX9, 400 MHz
• Display Memory: Shared Memory Max 224MB
• Dual Display: VGA + HDMI
• VGA: Onboard, supports max resolution 2048 x 1536
(@60Hz)
• HDMI: Onboard HDMI 1.3, supports max resolution 1920
x 1080
Audio
• Audio Codec: Realtek ALC662, 5.1 CH. HD Audio
• Audio Interface: Line-in, Line-out, Mic.-in, S/PDIF, Front
Audio Header
Ethernet
• LAN1: Realtek 8111E Gigabit Ethernet
1st Edition
July 2011
SIMB-M01 Startup Manual 1
