USER'S MANUAL/INSTALLATION INSTRUCTIONS
P6 Series
Single Package Convertible Air Conditioner
These instructions are primarily intended to assist qualifi ed individuals
experienced in the proper installation of heating and/or air conditioning appli-
ances. Some local codes require licensed installation/service personnel for this
type equipment. All installations must be in accordance with these instructions
and with all applicable national and local codes and standards.
Read these instructions thoroughly before starting the installation. Follow all
precautions and warnings contained within these instructions and on the unit.
Single Package Convertible Air Conditioner
IMPORTANT
Advertisement
Table of Contents
Related Manuals for Nordyne P6 series
Summary of Contents for Nordyne P6 series
- Page 1 USER'S MANUAL/INSTALLATION INSTRUCTIONS P6 Series Single Package Convertible Air Conditioner Single Package Convertible Air Conditioner IMPORTANT These instructions are primarily intended to assist qualifi ed individuals experienced in the proper installation of heating and/or air conditioning appli- ances. Some local codes require licensed installation/service personnel for this type equipment.
-
Page 2: Table Of Contents
TABLE OF CONTENTS OWNER INFORMATION .......................3 OPERATING INSTRUCTIONS ......................3 GENERAL SPECIFICATIONS ......................4 SAFETY CONSIDERATIONS .......................4 Literature, Labels, and Tags....................4 Pressures Within The System....................4 INSTALLATION REQUIREMENTS ....................4 Equipment Check .........................4 Requirements and Codes .....................4 Unit Dimensions ........................5 Unit Location .........................6 Air Filter Requirements ......................6 Internal Air Filter Assembly Removal..................7 Condensate Drain .........................7 UNIT INSTALLATION ........................7... -
Page 3: Owner Information
OWNER INFORMATION The indoor blower will start immediately, and will run continually until the fan switch is reset to AUTO. OPERATING INSTRUCTIONS The continuous indoor blower operation can be To Operate Your Air Conditioner for Cooling — obtained with the thermostat system switch set in any position, including OFF. -
Page 4: General Specifications
SPECIFICATIONS WARNING: Packaged Air Conditioners are designed for outdoor rooftop or ground level slab installations. I m p r o p e r i n s t a l l a t i o n , s e r v i c e , The units are shipped ready for horizontal adjustment, or maintenance may duct connections and are easily converted for... -
Page 5: Unit Dimensions
Center of Gravity Height (in inches) Model No. Unit P6SD Weight with base rails without base rails 29.5 26.0 39.0 35.3 29.5 26.5 39.0 35.3 30.0 27.5 43.0 39.3 24 9/10 3/4" NPT Female Drain Connector DOWNFLOW SUPPLY DUCT OPENING 47 1/2 13 1/2 13 1/2... -
Page 6: Unit Location
72" 36" 36" 36" 0" Figure 3. Minimum Clearances NFPA publications are available by writing: National Fire Protection Association Batterymarch Park Quincy, Maine 02269 Securing Screw Unit Location — This air conditioner designed only for outdoor installations. Choosing the location of the unit should be based on minimizing the length of the supply and return ducts. -
Page 7: Internal Air Filter Assembly Removal
4.) Install a 2 inch condensate trap in the drain line of the same size and prime with water. When connecting rigid drain line, hold the female fi tting with a wrench to prevent twisting. Do not over- tighten! Refer to local codes and restrictions for proper condensate disposal requirements. -
Page 8: Rooftop
Figure 6. Roof Top Installation AIR DUCTS WARNING: This unit is designed only for use with a supply and return duct. Air ducts should be installed in To avoid the risk of property damage accordance with the standards of the National or personal injury;... -
Page 9: Acoustical Ductwork
prevent condensation. Use insulation with an Code Part 1. If any of the original wire as supplied outer vapor barrier. Refer to local codes for with the unit must be replaced, it must be insulation material requirements. replaced with material of the same gauge and temperature rating. -
Page 10: Blower Speed
unit rating plate. Connect the line-voltage leads on the appropriate motor speed tap for the to the corresponding terminals on the contactor required airfl ow point. (or the circuit breaker when the fi eld installed circuit breaker kits are used) inside the control Check all factory wiring per the unit wiring compartment. - Page 11 Brown Orange FROM BLOWER RELAY Green ACCESSORY HEAT PLUG FROM CONTACTOR ECONOMIZER PLUG Black (Optional, Check Gray Thermostat Instructions) Yellow Blue INDOOR FROM TRANSFORMER THERMOSTAT SUB-BASE Typical Wiring (Field Supplied) for 1-Stage Cool, 1-Stage Heat Optional Outdoor Thermostat (Field Supplied) Brown Orange FROM...
-
Page 12: System Check
Install the heater kits as directed by the in- System Cooling stallation instructions that come as part of the 1. Set the thermostat system switch to heater kit. Follow all cautions and warnings as “Cool” and the thermostat fan switch to directed. -
Page 13: Routine Maintenance
INSTALLING FILTERS IN THE FAC- WARNING: TORY INSTALLED FILTER RACK (3 PHASE ONLY) Single Packaged Air Conditioners are shipped fully charged with R-410A 1. Remove access panel screws from return air refrigerantand ready for installation. panel. (You may want to loosen the unit’s Top When a system is installed according Panel screws that are located near the top edge of the access panel. -
Page 14: Package A/C Blower Curves
P6 Series Blower Curves Model Number External Static Pressure Drop - inches water column P6SD- High 1610 1562 1504 1442 1365 1295 1214 1109 Medium 1367 1320 1271 1205 1138 1065 * Low 1153 1102 1043 High 2361 2278 2218... - Page 15 Cooling Charging Charts (cont.) P6SD-X48 Charging Chart - Cooling Remove refrigerant when above curve Add refrigerant when below curve Liquid Temperature (F) P6SD-X60 Charging Chart - Cooling Remove refrigerant when above curve Add refrigerant when below curve Liquid Temperature (F) Figure 9.
-
Page 16: Wiring Diagrams
GREEN GREEN BLACK FUSE ORANGE BROWN BLACK YELLOW BLACK YELLOW BLACK BLACK 7107630 Figure 10. Wiring Diagram-Standard Motor, Three Phase... - Page 17 TEST FUSE Voltage Terminals DF1 DF2 BLACK ORANGE BROWN YELLOW BLACK BLACK BLACK 7107640 Figure 11. Wiring Diagram-Fixed Torque Motor, Three Phase...
- Page 18 GREEN BLACK 240V ORANGE BROWN YELLOW YELLOW YELLOW 7107830 Figure 12. Wiring Diagram-Standard Motor, Single Phase...
-
Page 19: Wiring Diagrams
GREEN 240V YELLOW 7107840 Figure 13. Wiring Diagram-Fixed Torque Motor, Single Phase... -
Page 20: Installation Instructions
INSTALLER PLEASE LEAVE THESE INSTALLATION INSTRUCTIONS WITH THE HOMEOWNER. ¢7089339¤ 7089330 Specifi cations and illustrations subject to change without notice and 7089330 O'Fallon, MO without incurring obligations. (10/08)
