2 X 100Watt Class D Audio Amplifier Board - TK2050

1.3 Features

1.4 Applications

It is the ideal solution for any sound reinforcement installation or application needing an
affordable compact PA system.

1.5 Benefits

1.6 Quick Start

Suggested connection is shown in figure 1-3.
AA-AB32186_Ver1.0_Page 2
A perfect "Class D" architecture
Frequency response: 20Hz to 20KHz(±3dB)
Single end audio signal input
Over/under voltage protection
Over current protection
Over temperature protection
Vending machines
Lifts
Interactive kiosks
Home DIY
Car audio
Mini/Micro Systems
Mounting holes facilitate installation and fixing
Several wiring methods facilitate connection：RCA Socket (Default),Terminal
Block(Optional)
Excellent design of the power ports which allows you to connect multiple amplifier
boards in series (Terminal Block Optional).
Excellent heat dissipation eliminates the requirement of an extra heat sink.
