2 X 100Watt Class D Audio Amplifier Board - TK2050

FIGURE 1-4 CASCADING SCHEMATIC(OPTIONAL)

Note: Please observe the following steps to complete verification so as to ensure the

products are intact during transit.

AA-AB32186_Ver1.0_Page 4

Open the amplifier package and make sure the product is intact (No missing

or damaged components and no deformation.

Please observe the connection schematics when connecting the amplifier

board. Use a nearby sound source, such as MP3 or CD player to have a trial.

This amplifier board can be deemed as qualified if you can hear the sound

corresponding to that sound source
