Summary of Contents for ClearOne CHATAttach 150
- Page 1 CHATAttach™ (150 | 160 | 170) Quick Start Guide...
-
Page 2: Table Of Contents
Table of Contents CHATATTACH: InTroduCTIon ..........3 Product Overview ................3 Service and Support................3 Unpacking ..................4 CHATATTACH: GeTTInG STArTed ........5 CHATAttach: Connecting Two CHAT Devices .........5 CHATAttach Working Modes............7 CHATAttach Troubleshooting ............8... -
Page 3: Chatattach: Introduction
1.800.933.5107 (USA) or 1.801.977.0087 E-mail: sales@ClearOne.com Product returns All product returns require a return material authorization (RMA) number. Please contact ClearOne Technical Support before attempting to return your product. Make sure you return all the items that shipped with your product. -
Page 4: Unpacking
Contact your dealer for replacement parts and accessories. > note: ClearOne is not responsible for product damage incurred during ship- ment. You must make claims directly with the carrier. Inspect your shipment carefully for obvious signs of damage. If the shipment appears damaged, retain the original boxes and packing material for inspection by the carrier. -
Page 5: Chatattach: Getting Started
CHATAttach: Getting Started Connecting Two CHAT devices The CHATAttach makes it possible to connect two CHAT devices together for larger confer- ence settings using the CHATAttach accessory kit. In order to use the CHATAttach accessory, the following criteria must be met: Both CHAT devices must be the same model number - both CHAT 150, both CHAT 160 or both CHAT 170 devices - mixing CHAT models using CHATAttach is not currently possible. - Page 6 To prevent the power cable from inadvertantly becoming unplugged be- fore, during or after meetings, it is recommended that the connector end of the cable be secured in some way. One approach is to knot the male- female connection to prevent this from occurring as shown below. Follow the instructions in the appropriate CHAT device’s User’s Manual to setup the CHAT device with a PC.
-
Page 7: Chatattach Working Modes
A recommended professional approach to setting up a conference room utilizing the CHATAttach accessory is to drill holes near where the CHAT devices will be placed, route the cabling through the holes and secure them underneath the conference table. CHATAttach Working Modes The following table outlines the CHATAttach working modes. -
Page 8: Chatattach Troubleshooting
CHATAttach Troubleshooting The following table describes issues that may occur and possible causes that may help identify and resolve problems when using the CHATAttach accessory. error # error Code Cause resolution Firmware on CHAT devices Download and install latest Blinking Red LED’s on both support CHATAttach but version of firmware for both CHAT devices... - Page 9 © 2010 ClearOne Communications, Inc. All rights reserved. Information in this document is subject to change without notice. Other product names may be registered trademarks of their respective owners who do not necessarily endorse ClearOne or ClearOne’s products in the United States and/or other countries.
