Running Express Setup • Managing the Switch • Installing the Switch • • Wiring the Power Source Connecting the Switch Ports • Troubleshooting • Obtaining Documentation and Submitting a Service Request • Cisco IE 3010 Switch Getting Started Guide 78-19582-02...
Cisco.com. For translations of the warnings that appear in this publication, see the Regulatory Compliance and Safety Information for the Cisco IE 3010 Switch on the documentation CD. The product warranty information is on the documentation CD.
Dual-hole ground lug 10 Console cable or USB cable Four number-8 Phillips machine screws 1. Cisco IE-3010-24TC shown. Your switch model might look different. 2. Item is orderable. Verify that you have received these items. If any item is missing or damaged, Note contact your Cisco representative or reseller for instructions.
Cisco IE 3010 Switch Getting Started Guide Running Express Setup You should use Express Setup to enter the initial IP information. You can then access the switch through the IP address for further configuration. To use the CLI-based initial setup program, see Appendix C, “Configuring the Note Switch with the CLI Setup Program,”...
Page 5
When POST is complete, the SYSTEM LED remains green, and the other LEDs turn off. Troubleshooting If the SYSTEM LED blinks green, does not turn green, or turns amber, contact your Cisco representative or reseller. The switch failed POST. Step 5 Press the recessed Express Setup button with a simple tool, such as a paper clip.
Page 6
Cisco IE 3010 Switch Getting Started Guide Step 6 Connect a Category 5 or 6 cable to the blinking 10/100 Ethernet port. Connect the other end of the cable to the Ethernet port on your PC. C i sco C...
Page 7
Cisco IE 3010 Switch Getting Started Guide Step 7 Start a browser session on the PC, open a well-known website, such as Cisco.com. The switch prompts you for the default username and password. At the prompt, enter the default username and password cisco.
Page 8
In the Confirm Switch Password field, enter your password again. You must change the password from the default password, cisco. Note Step 9 Enter the Optional Settings now, or enter them later: You can enter other administrative settings in the Express Setup window.
Switch USB Console Port If you use the USB console port, you must install the Cisco Windows USB device driver on the PC that is connected to the USB console port. See the switch hardware installation guide for installation instructions.
This section covers 19-inch rack-mounting, wiring procedures, and switch port connections. The illustrations show the Cisco IE-3010-24TC switch. You can install and connect other Cisco IE 3010 switches as shown in these examples. For alternate mounting procedures, such as installing the switch on a wall and for additional cabling information, see the switch hardware installation guide.
Cisco IE 3010 Switch Getting Started Guide For IP-30 compliance: Note - Use the 16-14 AWG wire and appropriate terminals for the AC or high-voltage DC power supply - Use the 12-10 AWG wire and appropriate terminals for the low-voltage DC power supply Crimping tool (such as Thomas &...
This section includes the basic installation warning statements. Translations of these warning statements appear in the Regulatory Compliance and Safety Information for the Cisco IE 3010 Switch document that is on the documentation This unit is intended for installation in restricted access areas. A restricted...
Cisco IE 3010 Switch Getting Started Guide To prevent airflow restriction, allow clearance around the ventilation openings Warning to be at least: 1.75 in. (4.4 cm) Statement 1076 Attaching the Brackets Use six Phillips flat-head screws to attach the long side of the brackets to the switches in one of three mounting positions.
Cisco IE 3010 Switch Getting Started Guide 3 Cable-side mounting position Mid-mounting position Number-8 Phillips flat-head 4 Power-supply-side mounting screws position Rack-Mounting the Switch Use the four number-12 Phillips machine screws to attach the brackets to the rack. Use the black Phillips machine screw to attach the cable guide to the left or right bracket.
Page 15
Cisco IE 3010 Switch Getting Started Guide C i sco I E 30 10 C i sco I E 30 10 C i sco I E 301 0 Sw i t ch Ser i es 1 Mid-mounting position 4 Number-12 Phillips machine...
Cisco IE 3010 Switch Getting Started Guide Wiring the Power Source The switches have two power supply slots to support these power supply modules: PWR-RGD-LOW-DC: low-voltage DC (24 to 60 VDC) • PWR-RGD-AC-DC: high-voltage AC (100 to 240 VAC) or high-voltage •...
Page 17
Cisco IE 3010 Switch Getting Started Guide Step 3 Insert the ground wire into the terminal lug, and crimp the terminal to the wire. Step 4 Slide the ground screw from Step 1 through the terminal lug. Step 5 Insert the ground screw into the ground-screw opening on the cable side.
Cisco IE 3010 Switch Getting Started Guide Connecting to the Power Source Prepare the power cable. Warning This unit might have more than one power supply connection. All connections must be removed to de-energize the unit. Statement 1028 Warning This product relies on the building’s installation for short-circuit (overcurrent) protection.
Page 19
Cisco IE 3010 Switch Getting Started Guide Step 3 Use a Phillips screwdriver to loosen the captive screw on the power-input terminal, and open the cover. Step 4 Use twisted-pair copper wire (14- to 18-AWG) long enough to connect from the power-input terminal to the power source.
Page 20
Cisco IE 3010 Switch Getting Started Guide Step 7 Loosen the terminal screw, and slide the spade terminal under the screw and washer. Use the appropriate terminal screws, Note depending on whether you are installing a high-voltage (AC or DC) or a low-voltage (DC) power supply.
Page 21
Cisco IE 3010 Switch Getting Started Guide DC power: Insert the positive wire into the terminal screw labeled +, and the negative wire into the terminal screw labeled –. Make sure that you cannot see any wire lead. C is c o IE...
Step 2 Connect the other cable end to an RJ-45 port on the other device. The 10/100 ports on the Cisco IE-3010-16S-8PC support Power over Ethernet (PoE) and enhanced PoE (ePoE). See the switch software configuration guide for more information.
Insert the other cable end into the other device. C i sc o IE 30 10 For a list of supported modules, see the release notes on Cisco.com. For detailed instructions on installing, removing, and connecting to SFP modules, see the SFP module documentation. Verify Port Connectivity After you connect the switch port and another device, the port LED turns amber while the switch establishes a link.
Cisco IE 3010 Switch Getting Started Guide Troubleshooting Express Setup If Express Setup does not run or if the Express Setup page does not appear in your browser: Did you verify that POST If not, make sure that only the system and...
First look for a solution in the troubleshooting section of the switch hardware installation guide or the switch software configuration guide on Cisco.com. You can also use the Cisco Technical Support and Documentation site for a list of known hardware problems and extensive troubleshooting documentation.
Cisco IE 3010 Switch System Message Guide • Cisco and the Cisco logo are trademarks or registered trademarks of Cisco and/or its affiliates in the U.S. and other countries. To view a list of Cisco trademarks, go to this URL: www.cisco.com/go/trademarks. Third-party trademarks mentioned are the property of their respective owners.
