Poe Pins; Table 2-1. Standard Interface Signals; Table 2-2. Poe Interface Signals - Lantronix XPort AR Integration Manual

Signal Name
GND
VCC
_________
Reset
TXDA
RXDA
CP01
CP02
CP03
CP04
CP05
CP06
CP07
CP08
CP09
CP10
CP11
CP12
CP13
Reserved
Reserved

PoE Pins

XPort AR is PoE-ready; it allows a fully compliant PoE circuit to be implemented that uses the
Ethernet signals entering the XPort AR's RJ-45 jack. When the XPort AR's RJ-45 jack is
connected to a PoE compliant switch, pins 21, 22, 25, and 26 pass through the necessary
Ethernet signals to allow a PoE powered-device circuit to negotiate and receive power from
the switch.
Signal Name
POE12
POE36
POE45
POE78
CHSGND
XPort AR Integration Guide

Table 2-1. Standard Interface Signals

XPort AR
Pin #
4
5
8
9
12
13
16
17
3
7
2
10
1
6
20
19
11
14
15
18

Table 2-2. PoE Interface Signals

XPort
R Pin #
22
25
21
26
23
2: Description and Specifications
Primary Functions
Signal Ground
+3.3V Power In
External Reset In
Serial Data Out, Channel A
Serial Data In, Channel A
Programmable I/O or RTSA flow control
Programmable I/O or DTRA flow control
Programmable I/O or CTSA flow control
Programmable I/O or DSRA flow control
Programmable I/O or DCDA flow control
Programmable I/O or TXDB flow control
Programmable I/O or RXDB flow control
Programmable I/O or RTSB flow control
Programmable I/O or DTRB flow control
Programmable I/O or CTSB flow control
Programmable I/O or DSRB/DCDB flow control
2
I C clock
2
I C data
Reserved
Reserved
Primary Functions
Center tap from 1 & 2
Center tap from 3 & 6
Ethernet pins 4 & 5
Ethernet pins 7 & 8
Chassis Ground
10
