JP6
Pin #
1
3
5
7
9
11
13

JP7: Disconnect Jumper Header

This header provides jumper positions to connect the XPort AR to the RS-232 Port B
transceiver when this RS-232 serial interface is desired. Any number/combination of these
jumpers may be installed depending on which RS-232 signals are required and which XPort
AR signals are to perform functions other than RS-232 related.
JP7
Pin #
1
3
5
7
9

JP8: Disconnect Jumper Header

This header provides jumper positions to connect the XPort AR to the RS-232 Port B
transceiver when this RS-232 serial interface is desired and requires either DSR or DCD.
Since CP12 and CP13 are dedicated to an I
DSR and DCD on port B. This jumper has two positions: 1-2 or 2-3. In the 1-2 position, it
connects the XPort AR signal CP11 to the DSR output for Port B. In the 2-3 position, it
connects the XPort AR signal CP11 to the DCD output for Port B. This choice is made based
on whether the serial interface intends to use DSR or DCD.
XPort AR Integration Guide

Table 3-6. JP6 Connections

Connects To:
RS-232 XCVR, TXDA Input
RS-232 XCVR, RTSA Input
RS-232 XCVR, DTRA Input
RS-232 XCVR, RXDA Output
RS-232 XCVR, CTSA Output
RS-232 XCVR, DSRA Output
RS-232 XCVR, DCDA Output

Table 3-7. JP7 Connections

Connects To:
RS-232 XCVR, TXDB Input
RS-232 XCVR, RTSB Input
RS-232 XCVR, DTRB Input
RS-232 XCVR, RXDB Output
RS-232 XCVR, CTSB Output

Table 3-8. JP8 Connections

JP8 Pin # Connects To:
1 RS-232 XCVR, DSRB Output
2 XPort AR, CP11
3 RS-232 XCVR, DCDB Output
JP6 Connects To:
Pin #
2 XPort AR, TXDA
4 XPort AR, CP01
6 XPort AR, CP02
8 XPort AR, RXDA
10 XPort AR, CP03
12 XPort AR, CP04
14 XPort AR, CP05
JP7 Connects To:
Pin #
2 XPort AR, CP06
4 XPort AR, CP08
6 XPort AR, CP09
8 XPort AR, CP07
10 XPort AR, CP10
2
C function, only CP11 remains to serve both
