USER'S MANUAL AND INSTALLATION
INSTRUCTIONS
P3BD Series 13 SEER
Single Package Air Conditioner
Read this owner information to become familiar with the capabilities and use
of your appliance. Keep this with literature of other appliances where you have
easy access to it in the future. If a problem occurs, check the instructions and
follow recommendations given. If these suggestions don't eliminate your problem,
call your installing contractor or distributor in your area.
INTRODUCTION
Most any air conditioner will keep you cool. Our air conditioner was designed to
do it effi ciently. Effi ciency means less cost to you while keeping you comfortable.
The P3BD Series single packaged air conditioners are self contained cooling
units that use the existing furnace to provide airfl ow and can be installed on a
slab. P3BD series equipment can only be used with the following NORDYNE
furnaces: E3EX*, M3RX* to achieve 13 SEER effi ciency levels. Units are ETL
and ETLc listed.
WHY YOUR AIR CONDITIONER WORKS SO WELL, SO QUIETLY
1. Air is cooled by a large evaporator coil. Moisture is also removed from the air by
this same coil.
2. Air is then delivered through the main duct, via registers, into your home.
3. Return air is drawn through the return grille.
4. This air enters the unit, passes through the evaporator coil, is cooled and dehumidi-
fi ed. Then the cycle begins again.
