BG Series

CCD Camera

Instruction Manual

Model
B/W Camera
Color Camera
Thank you for purchasing our product.
Before using this CCD camera, Please read through this instruction manual
carefully in order to use this product correctly and safely.
After reading, keep this instruction manual handy so that you can refer to,
whenever you need it.
Information contained in this document is subject to change without prior notice.
Copyright © 2012 TOSHIBA TELI CORPORATION, All rights reserved.
: BG030 / BG031 / BG080 / BG130 / BG202
: BG030C / BG030CF / BG130C / BG130CF
D4211908E
http://www.toshiba-teli.co.jp/index.htm

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BG030 and is the answer not in the manual?

Questions and answers

Related Manuals for Toshiba teli BG030

Summary of Contents for Toshiba teli BG030

  • Page 1: Ccd Camera

    CCD Camera Instruction Manual Model B/W Camera : BG030 / BG031 / BG080 / BG130 / BG202 Color Camera : BG030C / BG030CF / BG130C / BG130CF Thank you for purchasing our product. Before using this CCD camera, Please read through this instruction manual carefully in order to use this product correctly and safely.

  • Page 2: Table Of Contents

    BlackLevel ..........................66 Gamma ............................67 LUTControl ..........................73 TransportLayerControl ........................ 74 UserSetControl ........................... 78 ALCControl ..........................80 Warranty rules ......................84 Repair .......................... 85 1 / 85 D4211908E Copyright © 2012 - 2013 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...

  • Page 3: Safety Precautions

    This sign indicates MANDATORY ACTION (You are required to do). MANDATORY The content of action is shown by a picture or words beside the symbol. 2 / 85 D4211908E Copyright © 2012 - 2013 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...

  • Page 4: General Handing

    Do not be handled roughly, damaged, fabricated, bent forcefully, pulled, twisted, bundled, placed under heavy objects or heated the power cable and the connection cable. Avoid Otherwise, fire or electric shock may result. 3 / 85 D4211908E Copyright © 2012 - 2013 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...
  • Page 5 (every approx five years). Accumulation of dust inside the equipment may result in fire or electric shock. For inspection and cleaning costs, contact your sales representative. Instruction 4 / 85 D4211908E Copyright © 2012 - 2013 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...

  • Page 6: Cases For Indemnity (Limited Warranty)

    ● The item that is not described in specifications of this product is out of the guarantee. ● The case of damages or losses which are caused by incorrect connection of the cable is out of the guarantee. 5 / 85 D4211908E Copyright © 2012 - 2013 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...

  • Page 7: Restriction For Use

    - Traffic control systems for air transportation, railways, roads, or marine transportation - Equipment for nuclear power generation - Equipment related to the above 6 / 85 D4211908E Copyright © 2012 - 2013 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...

  • Page 8: Notes On Using This Product

    Avoid intense light such as spot lights on part of the screen because it may cause blooming or smears. If intense light falls on the screen, vertical stripes may appear on the screen, but this is not a malfunction. 7 / 85 D4211908E Copyright © 2012 - 2013 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...
  • Page 9 Never use alcohol, benzene, thinner, or other chemicals because such chemicals may damage or discolor the paint and indications. If the image pickup surface becomes dusty, contaminated, or scratched, consult your sales representative. 8 / 85 D4211908E Copyright © 2012 - 2013 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...
  • Page 10 Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be require to correct the interference at his own expense. 9 / 85 D4211908E Copyright © 2012 - 2013 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...
  • Page 11 This information is applicable for People's Republic of China only. リサイクルに関する情報（包装物） 有关再利用的信息(包装物) Information on recycling of wrapping composition 内部緩衝材料・袋 内部缓冲材料·袋 箱／箱子／Box Internal buffer materials・Bag ペーパーボード 纸板 Paper board 10 / 85 D4211908E Copyright © 2012 - 2013 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...

  • Page 12: Installation

    ● TOSHIBA TELI CORPORATION Top Page http://www.toshiba-teli.co.jp/index.htm ● Service & Support https://www.toshiba-teli.co.jp/cgi/ss/en/service.cgi Please refer to the TeliGevSDK startup guide, about Operation environment, Installation, and Setup. 11 / 85 D4211908E Copyright © 2012 - 2013 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...

  • Page 13: Specifications

    ● High frame rate and high resolution Supported high frame rate BG030 / BG030C: 125fps / VGA (1/3 type), BG031: 125fps / VGA (1/2 type), BG080: 40fps / XGA (1/3 type), BG130 / BG130C: 30fps / SXGA (1/3 type), BG202: 20fps / UXGA (1/1.8 type).
  • Page 14 ● Compact and lightweight This camera is compact and lightweight; it is easy to integrate into industrial equipment. ● EU RoHS & Chinese ROHS 13 / 85 D4211908E Copyright © 2012 - 2013 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...

  • Page 15: Configuration

    PoE. Please use 1000BASE-T equipments, supporting Jumbo Frame is recommended. *1: Optional part. Contact your dealer / distributor for details of option units. *2: Commercial items. 14 / 85 D4211908E Copyright © 2012 - 2013 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...

  • Page 16: Connection

    Please confirm it before use. Lost packets may occur by an electrical characteristic of the transmission line of using Ethernet devices (LAN cable, Network Interface Card, Switching HUB). 15 / 85 D4211908E Copyright © 2012 - 2013 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...

  • Page 17: Connector Pin Assignment

    Signal Function +12V Power Line 0 External Trigger Input Line 1 GPIO_0 Output (LVTTL) Line 2 GPIO_1 Output (Open Collector) I/O GND I/O_Ground Ground 16 / 85 D4211908E Copyright © 2012 - 2013 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...
  • Page 18 - Supply from LAN cable (PoE) - Supply from camera cable (DC+12V ±10%) If both PoE and DC+12V are connected, power is supplied from PoE. 17 / 85 D4211908E Copyright © 2012 - 2013 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...

  • Page 19: Outline Drawing

    Outline Drawing 18 / 85 D4211908E Copyright © 2012 - 2013 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...

  • Page 20: General Specifications

    No conductive between circuit GND and camera body insulation status *1 F1.4, Gain: Maximum (+18dB), video level: 50% *2 at the all pixel readout 19 / 85 D4211908E Copyright © 2012 - 2013 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...
  • Page 21 No conductive between circuit GND and camera body insulation status (*1) with IR-cut filter (*2) F1.4, Gain: Maximum (+18dB), video level: 50% (*3) at the all pixel readout 20 / 85 D4211908E Copyright © 2012 - 2013 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...
  • Page 22 Depends on your PC or Gigabit Ethernet interface board configurations, images may not be captured properly (e.g. dropping frames). In this case, change to frame rate setting lower. 21 / 85 D4211908E Copyright © 2012 - 2013 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...

  • Page 23: I/O Specification

    : Positive / Negative bipolar (initial factory setting: Negative) Signal Source : VD TIMER0 ACTIVE EXPOSURE ACTIVE FRAME ACTIVE FRAME TRANSFER FRAME TRIGGER WAIT 22 / 85 D4211908E Copyright © 2012 - 2013 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...
  • Page 24 ● Circuit diagram - Trigger Input - GPIO Output 23 / 85 D4211908E Copyright © 2012 - 2013 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...
  • Page 25 +3.3V 2.92 26.2 +12V 2.12 31.2 +24V 2.12 31.2 * Toff and Ton are typical value. * These values are changed in operating environment. 24 / 85 D4211908E Copyright © 2012 - 2013 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...
  • Page 26 Toff [µs] Ton [µs] +3.3V 53.2 +12V 78.4 +24V 94.4 * Toff and Ton are typical value. * These values are changed in operating environment. 25 / 85 D4211908E Copyright © 2012 - 2013 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...
  • Page 27 To filter out an unstable logic value, this camera has the anti-chattering circuit. Therefore, Random Trigger Shutter operates only in the stable logic value. Fig. Anti-chattering process 26 / 85 D4211908E Copyright © 2012 - 2013 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...

  • Page 28: Timing Specification

    PayloadSize is total bytes of single frame. The formula applies when SCPS (Stream Channel Packet Size) is 1500 byte / packet. (T1 varies depending on the value of SCPS) 27 / 85 D4211908E Copyright © 2012 - 2013 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...
  • Page 29 BG202 BG030C BG130C * TDLY3, TDLY4: TriggerSamplingPeriod (typical value) Max TriggerSamplingPeriod x 1.625[µs], Min TriggerSamplingPeriod x 0.625[µs] * T3 and T4 are typical value. 28 / 85 D4211908E Copyright © 2012 - 2013 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...
  • Page 30 When the interval of the input trigger signal is extremely short, or when the trigger signal is noisy, there is a possibility of causing the malfunction. In this case, please input a proper trigger signal. 29 / 85 D4211908E Copyright © 2012 - 2013 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...

  • Page 31: Typical Spectral Response

    Typical Spectral Response * The lens characteristics and light source characteristics is not reflected in table. ● BG030 ● BG031 30 / 85 D4211908E Copyright © 2012 - 2013 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...
  • Page 32 ● BG080 ● BG130 31 / 85 D4211908E Copyright © 2012 - 2013 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...
  • Page 33 ● BG202 32 / 85 D4211908E Copyright © 2012 - 2013 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...
  • Page 34 ● BG030C ● BG030CF 33 / 85 D4211908E Copyright © 2012 - 2013 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...
  • Page 35 ● BG130C ● BG130CF 34 / 85 D4211908E Copyright © 2012 - 2013 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...

  • Page 36: Operating Ambient Conditions

    - DC Cable CPCBG-03 - LAN Cable C5e(S-HFR)(K)-* (Oki Electric Cable Co., Ltd.) Please confirm the EMC adaptability when it combines with parts other than them. 35 / 85 D4211908E Copyright © 2012 - 2013 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...

  • Page 37: Functions

    Set color matrix correction LUTControl LUTControl Control LUT TransportLayerControl TransportLayerControl Control transport layer UserSetControl UserSetControl Load / Save user setting ALCControl ALCControl Control ALC operation 36 / 85 D4211908E Copyright © 2012 - 2013 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...
  • Page 38 ○ ○ ○ ○ ○ ○ ○ TransportLayerControl ○ ○ ○ ○ ○ ○ ○ UserSetControl ○ ○ ○ ○ ○ ○ ○ ALCControl 37 / 85 D4211908E Copyright © 2012 - 2013 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...

  • Page 39: Devicecontrol

    DeviceRegistersCheck Expert Executes the validation of the current register set for consistency. Returns the result that executed “DeviceRegistersCheck”. DeviceRegistersValid Expert TRUE: Consistency, FALSE: Inconsistency 38 / 85 D4211908E Copyright © 2012 - 2013 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...

  • Page 40: Scalable

    Sets horizontal offset (in pixels) from the origin to the region of interest. OffsetY Beginner Sets vertical offset (in pixels) from the origin to the region of interest. 39 / 85 D4211908E Copyright © 2012 - 2013 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...
  • Page 41 White lines may occur in the upper portions of the screen when strong light exists in a wide area during the scalable mode. This is not a malfunction. If white lines occur, adjust the amount of incident light using the lens. 40 / 85 D4211908E Copyright © 2012 - 2013 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...

  • Page 42: Binning

    This function is available only in B/W models. Fig. Binning operation (e.g. VGA) ● Registers Register Visibility Access Description BinningHorizontal Beginner Set horizontal binning. BinningVertical Beginner Set vertical binning. 41 / 85 D4211908E Copyright © 2012 - 2013 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...
  • Page 43 The range of register setting depends on camera model. Changing “BinningHorizontal”, “BinningVertical” register value effects Scalable registers. Changing “BinningHorizontal”, “BinningVertical” register value is invalid during image stream data output. 42 / 85 D4211908E Copyright © 2012 - 2013 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...

  • Page 44: Pixelformat

    Bayer Red Green 10 bit Bpp10: 10 bits per pixel * initial factory setting ● Note Changing “PixelFormat” register value is invalid during image stream data output. 43 / 85 D4211908E Copyright © 2012 - 2013 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...

  • Page 45: Testimageselector

    TestImageSelector BG series support test pattern data output. Camera provides following Test patterns; Black White BrightGrey DarkGrey GreyHorizontalRamp Fig. Test pattern 44 / 85 D4211908E Copyright © 2012 - 2013 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...
  • Page 46 All pixel = 255 @Mono8 BrightGrey All pixel = 170 @Mono8 DarkGrey All pixel = 85 @Mono8 GreyHorizontalRamp Horizontal Ramp * initial factory setting ● Note 45 / 85 D4211908E Copyright © 2012 - 2013 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...

  • Page 47: Acquisitioncontrol

    FrameRate Minimum 0.0625[Hz] Maximum (*) Depend on register setting of "Height", "Binning", “PacketSize” and “PixelFormat” or link speed of interface. * initial factory setting 46 / 85 D4211908E Copyright © 2012 - 2013 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...
  • Page 48 Depends on your PC or Gigabit Ethernet interface board configurations, images may not be captured normally (e.g. frame drops may occur). In this case, change to frame rate setting lower. 47 / 85 D4211908E Copyright © 2012 - 2013 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...

  • Page 49: Triggercontrol

    Operation point of HardwareTrigger is at the edge of trigger signal, and active edge polarity is able to change by register setting. And you can add delay time from trigger edge to exposure start by register setting. Fig. Trigger Delay 48 / 85 D4211908E Copyright © 2012 - 2013 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...
  • Page 50 Set the following value to “TriggerMode” register. Setting value is Enumeration type. setting value Operation Mode Off (*) Normal Shutter Mode Random Trigger Shutter mode * initial factory setting 49 / 85 D4211908E Copyright © 2012 - 2013 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...
  • Page 51 Set the following value to “TriggerSamplingPeriod” register. Setting value is Float type. setting value TriggerSamplingPeriod[µs] Minimum (*) 2.00[µs] Maximum 1000.00[µs] * initial factory setting 50 / 85 D4211908E Copyright © 2012 - 2013 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...
  • Page 52 When set longer value to “TriggerSamplingPeriod” register, noise immunity of trigger input line is improved, but the delay time of receiving trigger signal become longer. 51 / 85 D4211908E Copyright © 2012 - 2013 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...

  • Page 53: Exposurecontrol

    ● Registers Register Visibility Access Description ExposureMode Beginner Selects manual exposure mode. ExposureTime Beginner Sets absolute exposure time(timed mode). ExposureAuto Beginner Sets AE operation. 52 / 85 D4211908E Copyright © 2012 - 2013 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...
  • Page 54 Off (*) Manual Exposure control Auto Exposure control * initial factory setting ● Note Changing “ExposureMode” register value is invalid during image stream data output. 53 / 85 D4211908E Copyright © 2012 - 2013 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...

  • Page 55: Digitaliocontrol

    Selects the polarity of GPIO output signal. LineSource Expert Selects the source of the output signal. LineFormat Expert Returns the type of each Line signal. 54 / 85 D4211908E Copyright © 2012 - 2013 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...
  • Page 56 The delay time and pulse width of this signal are configurable. Internal VD sync signal. * initial factory setting ● Note About the details of Timer0Active signal, refer to “TimerControl” of "Functions". 55 / 85 D4211908E Copyright © 2012 - 2013 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...

  • Page 57: Timercontrol

    Set the following value to “TimerDuration” register. Setting value is Float type. TimerDuration Pulse width Minimun (*) 0.00[µs] Maximum 2000000.00[µs] * initial factory setting 56 / 85 D4211908E Copyright © 2012 - 2013 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...
  • Page 58 Set the following value to “TimerDelay” register. Setting value is Float type. TimerDelay Dlay value Minimun (*) 0.00[µs] Maximum 2000000.00[µs] * initial factory setting ● Note 57 / 85 D4211908E Copyright © 2012 - 2013 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...

  • Page 59: Eventcontrol

    : ALC Information is updated - ALCConverged : ALC is converged FrameTrigger events timing are as following chart. Fig. FrameTrigger / Error / Wait Event timing 58 / 85 D4211908E Copyright © 2012 - 2013 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...
  • Page 60 Returns the average luminance at the time of Event. EventALCConvergedExposureTime Expert Returns the exposure time at the time of Event. EventALCConvergedGain Expert Returns the gain at the time of Event. 59 / 85 D4211908E Copyright © 2012 - 2013 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...
  • Page 61 Set the following value to “EventNotification” register. The setting value is Enumeration type. setting value Event notification Off (*) Inactive Active * initial factory setting ● Note This camera takes about 4 ms to event notification. 60 / 85 D4211908E Copyright © 2012 - 2013 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...

  • Page 62: Gain

    Access Description GainSelector Beginner Returns the luminance component of Gain setting. Gain Beginner Sets the absolute Gain. GainAuto Beginner Sets activation of AGC mode. 61 / 85 D4211908E Copyright © 2012 - 2013 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...
  • Page 63 Setting the gain value too high increases noises. When you adjust the brightness of the image, I ask you to have final image quality checked with your environment. 62 / 85 D4211908E Copyright © 2012 - 2013 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...
  • Page 64 Select the color component of white balance gain to control in “BalanceRatioSelector” register. Setting value is Enumeration type. BalanceRatioSelector Function R (*) BalanceRatio = R Gain BalanceRatio = B Gain * initial factory setting 63 / 85 D4211908E Copyright © 2012 - 2013 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...
  • Page 65 Too high white balance gain increases noises. After adjusting the white balance of the image, I ask you to have final image quality checked with your environment. 64 / 85 D4211908E Copyright © 2012 - 2013 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...
  • Page 66 Execute auto white balance once. * initial factory setting ● Note BalanceRatio and BalanceWhiteAuto controls are available in following PixelForamt modes. RGB8, YUV411_8, YUV422_8, Bayer*8, Bayer*10 65 / 85 D4211908E Copyright © 2012 - 2013 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...

  • Page 67: Blacklevel

    Set the following value to “BlackLevel” register. Setting value is Float type. BlackLevel setting value Minimum -5.00[%] Maximum +25.00[%] * initial factory setting = 0.00[%] ● Note 66 / 85 D4211908E Copyright © 2012 - 2013 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...

  • Page 68: Gamma

    Set the following value to “Gamma” register. Setting value is Float type. Gamma setting value Minimum 0.45 Maximum (*) 1.00 * initial factory setting ● Note 67 / 85 D4211908E Copyright © 2012 - 2013 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...
  • Page 69 - Set Hue Set the following value to “Hue” register. Setting value is Float type. Value Minimum -40[°] Maximum +35[°] * initial factory setting = 0[°] 68 / 85 D4211908E Copyright © 2012 - 2013 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...
  • Page 70 Minimum (*) Maximum x 2.5 * initial factory setting = x 1.0 ● Note Hue/Saturation control is available in following PixelForamt modes. RGB8, YUV411_8, YUV422_8 69 / 85 D4211908E Copyright © 2012 - 2013 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...
  • Page 71 Sharpness Value Minimum (*) 0 (OFF) Maximum * initial factory setting ● Note Sharpness control is available in following PixelForamt modes. RGB8, YUV411_8, YUV422_8 70 / 85 D4211908E Copyright © 2012 - 2013 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...
  • Page 72 Selects a row element of color correction matrix. ColorCorrectionMatrixSelectorJ Expert Selects a column element of color correction matrix. ColorCorrectionMatrix Expert Sets a coefficient of color correction matrix. 71 / 85 D4211908E Copyright © 2012 - 2013 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...
  • Page 73 Value Minimum -1.0 Maximum +1.0 * initial factory setting = 0.0 ● Note ColorCorrectionMatrix control is available in following PixelForamt modes. RGB8, YUV411_8, YUV422_8 72 / 85 D4211908E Copyright © 2012 - 2013 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...

  • Page 74: Lutcontrol

    “LUTIndex” register value is input level of LUT process, and “LUTValue” register value is output level of LUT process. LUTIndex / LUTValue setting value Minimum (*) Maximum 1023 * initial factory setting ● Note 73 / 85 D4211908E Copyright © 2012 - 2013 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...

  • Page 75: Transportlayercontrol

    Sets Persistent IP Address. GevPersistentSubnetMask Beginner Sets Persistent IP Subnet Mask. GevPersistentDefaultGateway Beginner Sets Persistent IP Default Gateway. GevLinkSpeed Expert Returns the speed of transmission negotiated. 74 / 85 D4211908E Copyright © 2012 - 2013 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...
  • Page 76 Guru Returns the source port of the stream channel. BlockStartDelay Expert Sets the delay to insert between each image flame for the stream channel. 75 / 85 D4211908E Copyright © 2012 - 2013 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...
  • Page 77 In this case, change the packet size more than 1500[byte/packet]. And we recommend you to use network equipments (NIC, Switching HUB, etc. ) supporting Jumbo Frame. 76 / 85 D4211908E Copyright © 2012 - 2013 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...
  • Page 78 Set the following value to “GevSCPD”, “BlockStartDelay” registers. These setting values are Integer type. Fig. Packet delay GevSCPD BlockStartDelay 設定値 Minimum (*) Maximum 0xFFFFFFFF 0xFFFFE795 * initial factory setting * unit of value = 8ns ● Note 77 / 85 D4211908E Copyright © 2012 - 2013 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...

  • Page 79: Usersetcontrol

    TriggerSource ALCReferenceLuminance TriggerActivation ALCExposureValue AcquisitionControl TriggerDelay ALCTolerance ALCControl TriggerSamplingPeriod ALCThrottle ExposureMode ALCExposureTimeMin ExposureTime ALCExposureTimeMax ExposureAuto ALCGainMin LineInverter ALCGainMax DigitalIOControl LineSource TimerDuration CounterAndTimerControl TimerDelay TimerTriggerSource 78 / 85 D4211908E Copyright © 2012 - 2013 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...
  • Page 80 “UserSetDefaultSelector” register and applies them at the time of next start-up. ● Note Changing “UserSetLoad” register value is invalid during image stream data output. 79 / 85 D4211908E Copyright © 2012 - 2013 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...

  • Page 81: Alccontrol

    Sets a minimum value of the gain when ALC(AGC) feature is running. ALCGainMax Expert Sets a maximum value of the gain when ALC(AGC) feature is running. 80 / 85 D4211908E Copyright © 2012 - 2013 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...
  • Page 82 An Image luminance at ALC operation converges on a reference luminance. (at ALCExposureValue = 0 [eV]). ReferenceLuminance setting value Minimum Maximum * initial factory setting = 84 81 / 85 D4211908E Copyright © 2012 - 2013 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...
  • Page 83 Set the following value to “ALCLock” register. The setting value is Boolean type. You can lock ALC operation by using this function. setting value Activation FALSE (*) inactive TRUE active * initial factory setting 82 / 85 D4211908E Copyright © 2012 - 2013 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...
  • Page 84 GainMin Maximum less than GainMax 18.00[dB] (*) * initial factory setting ● Note ALC operation at Random Trigger Shutter mode is not guaranteed. 83 / 85 D4211908E Copyright © 2012 - 2013 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...

  • Page 85: Warranty Rules

    9. Forgery product, products which does not have proper serial number, products of which serial number is forged, damaged or deleted 10. All defects that happened after the expiration for a warranty term 84 / 85 D4211908E Copyright © 2012 - 2013 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...

  • Page 86: Repair

    10. The immunity from responsibility of the product is applied in the repair completion products. * Please refer for the inquiry about the software to our homepage or sales personnel. 85 / 85 D4211908E Copyright © 2012 - 2013 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...
  • Page 87 □ It certainly occurs. □ It sometimes occurs. □ It occurs, after time passes. （ □ Others ） <For dealer use> Reception date : Receipt No. : JOB No. : Check : D4211908E Copyright © 2012 TOSHIBA TELI CORPORATION, All rights reserved. http://www.toshiba-teli.co.jp/index.htm...
