Gefen EXT-DIGAUD-141 User Manual
Digital audio extender
Hide thumbs
Also See for EXT-DIGAUD-141:
- User manual (12 pages) ,
- User manual (10 pages) ,
- User manual (22 pages)
Related Manuals for Gefen EXT-DIGAUD-141
Summary of Contents for Gefen EXT-DIGAUD-141
-
Page 1: Digital Audio
® Digital Audio Extender EXT-DIGAUD-141 User Manual www.gefen.com... - Page 3 Chatsworth, CA 91311 www.gefen.com support@gefen.com Notice Gefen, LLC reserves the right to make changes in the hardware, packaging, and any accompanying documentation without prior written notice. Digital Audio Extender is a trademark of Gefen, LLC © 2012 Gefen, LLC. All rights reserved.
-
Page 4: Table Of Contents
TABLE OF CONTENTS Introduction Box Contents and Operation Notes Connecting the Digital Audio Extender Panel Layouts Link Cable Wiring Diagram Specifications Warranty... -
Page 5: Introduction
The Gefen Digital Audio Extender Place your digital audio components anywhere you want with Gefen’s Digital Audio Extender. It supports either S/PDIF or TOSLINK digital audio signals, which are commonly used to transmit stereo and multichannel digital audio like Dolby®... -
Page 6: Operation Notes
BOX CONTENTS The Digital Audio Extender system consists of: (1) Digital Audio Extender - Sender Unit (1) Digital Audio Extender - Receiver Unit (1) 6 ft. TOSLINK Cable (1) 5V DC power supply (1) Quick-Start Guide OPERATION NOTES READ THESE NOTES BEFORE INSTALLING OR OPERATING THE DIGITAL AUDIO EXTENDER SYSTEM Industry standard Category-5 (CAT-5 or CAT-5e) cables are used to link the Digital Audio Extender Sender and Receiver units together. -
Page 7: Connecting The Digital Audio Extender
CONNECTING THE DIGITAL AUDIO EXTENDER How to Connect the Digital Audio Extender System: 1- Connect your digital audio source’s outputs to the Sender unit’s digital input using either the TOSLINK or the S/PDIF input. Please see “Panel Layout” on page 4 for a list of connectors on the units. -
Page 8: Panel Layouts
PANEL LAYOUTS Receiver (CAT5 link side) Sender (CAT5 link side) Receiver (output side) Sender (input side) Connections -- Digital Audio Extender Sender & Receiver units 1. RJ45 Jack -- CAT5 cable connection from Sender unit plugs in here 2. Power LED on Receiver -- indicates successful hookup between units 3. -
Page 9: Link Cable Wiring Diagram
LINK CABLE WIRING DIAGRAM... -
Page 10: Specifications
SPECIFICATIONS Input/Output ..................S/PDIF, TOSLINK Link Connector ................... RJ-45 Shielded Power Supply ....................5V DC Power Consumption: ............5W (max) per power supply. Dimensions (W x H x D)......3.8” x 1.2” x 1.4” (96mm x 30mm x 35mm) Shipping Weight ..................5 lbs. (2.3 kg) -
Page 11: Warranty
If equipment fails because of such defects and Gefen is notified within two (2) years from the date of shipment, Gefen will, at its option, repair or replace the equipment, provided that the equipment has not been subjected to mechanical, electrical, or other abuse or modifications. - Page 12 Rev A3 This product uses UL or CE listed power supplies.
