K R A ME R E LE CT R O N IC S L T D .

USER MANUAL

MODEL:
FC-49
DVI / Audio to HDMI Converter
P/N: 2900-000286 Rev 5

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PC-49 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Kramer PC-49

  • Page 1: User Manual

    K R A ME R E LE CT R O N IC S L T D . USER MANUAL MODEL: FC-49 DVI / Audio to HDMI Converter P/N: 2900-000286 Rev 5...
  • Page 3: Table Of Contents

    Contents Introduction Getting Started Achieving the Best Performance Overview About HDCP Defining EDID About HDMI—General Description Defining the FC-49 DVI / Audio to HDMI Converter Connecting the FC-49 DVI / Audio to HDMI Converter Acquiring EDID Technical Specifications Default EDID Figures F igure 1: FC-49 DVI / Audio to HDMI Converter F igure 2: Connecting the FC-49 DVI / Audio to HDMI Converter...
  • Page 4: Introduction

    GROUP 7: Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9: Room Connectivity; GROUP 10: Accessories and Rack Adapters and GROUP 11: Sierra Products. Congratulations on purchasing your Kramer TOOLS FC-49 DVI / Audio to HDMI Converter, which is ideal for: •...
  • Page 5: Getting Started

    • Avoid interference from neighboring electrical appliances that may adversely influence signal quality • Position your Kramer FC-49 away from moisture, excessive sunlight and dust Caution: No operator serviceable parts inside the unit Use only the Kramer Electronics input power wall...
  • Page 6: Overview

    Overview The Kramer FC-49 DVI / Audio to HDMI Converter is a high−quality format converter and embedder for DVI and audio signals. It converts a DVI signal and embeds an unbalanced stereo, S/PDIF or TOSLINK® audio signal to an HDMI output.
  • Page 7: About Hdcp

    About HDCP The High-Bandwidth Digital Content Protection (HDCP) standard developed by Intel, protects digital video and audio signals transmitted over DVI or HDMI connections between two HDCP-enabled devices to eliminate the reproduction of copyrighted material. To protect copyright holders (such as movie studios) from having their programs copied and shared, the HDCP standard provides for the secure and encrypted transmission of digital signals.
  • Page 8: About Hdmi-General Description

    It delivers the maximum high-definition image and sound quality in use today. Note that Kramer Electronics Limited is an HDMI Adopter and an HDCP Licensee.
  • Page 9: Defining The Fc-49 Dvi / Audio To Hdmi Converter

    Defining the FC-49 DVI / Audio to HDMI Converter Figure 1: FC-49 DVI / Audio to HDMI Converter Feature Function 12V DC +12V DC connector for powering the unit AUDIO S/PDIF RCA Connects to the digital audio source INPUTS Connector OPTICAL Connects to the digital audio source TosLink®...
  • Page 10: Connecting The Fc-49 Dvi / Audio To Hdmi Converter

    Connecting the FC-49 DVI / Audio to HDMI Converter Always switch off the power to each device before connecting it to your FC-49. After connecting your FC-49, connect its power and then switch on the power to each device. To connect the FC-49, as illustrated in the example in F igure 2 do the following: 1.
  • Page 11: Acquiring Edid

    Acquiring EDID To acquire a new EDID, do the following: 1. Connect the power supply. 2. Connect the new output display (or keep it disconnected to acquire the default EDID). 3. Press and hold the EDID CAPTURE button until the green IN LED starts blinking, and then release the button.
  • Page 12: Technical Specifications

    Technical Specifications INPUTS: 1 DVI On a DVI-I connector. Note that only the digital signal (DVI-D) is available on the DVI connector, 1.2Vpp on a DVI Molex 24-pin female connector; DDC signal 5Vpp (TTL) 1 S/PDIF (digital audio) on an RCA connector 1 ANALOG on a 3.5mm mini jack connector 1 TOSLINK®...
  • Page 13: Default Edid

    Default EDID Monitor #2 [Real-time 0x0031] Model name....FC-49 Manufacturer..... KRM Plug and Play ID..KRM0000 Serial number.... 1 Manufacture date..2006, ISO week 12 Filter driver.... None ------------------------- EDID revision.... 1.3 Input signal type..Digital (DVI) Color bit depth..Undefined Display type.....
  • Page 14 Native formats... 1 Detailed timing #1..720x480p at 60Hz (4:3) Modeline...."720x480" 27.000 720 736 798 858 480 489 495 525 -hsync -vsync Detailed timing #2..1920x1080i at 60Hz (16:9) Modeline...."1920x1080" 74.250 1920 2008 2052 2200 1080 1084 1094 1124 interlace +hsync +vsync CE video identifiers (VICs) - timing/formats supported 640 x 480p at 60Hz - Default (4:3, 1:1)
  • Page 15 FC-49 - Default EDID...
  • Page 16 " " 2900- 000286 Rev:...
