K R A ME R E LE CT R O N IC S L TD . USER MANUAL MODEL: VP-483 PC/Component to 3G HD-SDI Scaler P/N: 2900-000764 Rev 2... -
Page 3: Table Of Contents
Contents Introduction Getting Started Achieving the Best Performance Safety Instructions Overview Defining the VP-483 PC/Component to 3G HD-SDI Scaler Connecting the VP-483 Operating the VP-483 PC/Component to 3G HD-SDI Scaler Using the Front Panel Buttons Using the OSD Technical Specifications... -
Page 4: Introduction
Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9: Room Connectivity; GROUP 10: Accessories and Rack Adapters and GROUP 11: Sierra Products. Congratulations on purchasing your Kramer VP-483 PC/Component to 3G HD-SDI Scaler, which is ideal for the following typical applications: ... -
Page 5: Getting Started
Avoid interference from neighboring electrical appliances that may adversely influence signal quality Position your Kramer VP-483 away from moisture, excessive sunlight and dust This equipment is to be used only inside a building. It may only be connected to other equipment that is installed inside a building. -
Page 6: Overview
Overview The Kramer VP-483 PC/Component to 3G HD-SDI Scaler is a high-performance digital scaler for component video and computer graphics video signals with resolutions up to WUXGA and 1080p. It up and down-scales them to SDI, HD-SDI and 3G HD-SDI signals. The following output resolutions are supported at various refresh rates: 480i, 576i, 720p, 1080i, 1080p SF, and 1080p. -
Page 7: Defining The Vp-483 Pc/Component To 3G Hd-Sdi Scaler
Defining the VP-483 PC/Component to 3G HD-SDI Scaler This section defines the VP-483. Figure 1: VP-483 Features Feature Function ON LED Lights green when the unit is powered on COMPONENT IN LED Lights green when a component video signal is detected on the... -
Page 8: Connecting The Vp-483
6, 7, 8 Ground You can use a breakout cable, such as the Kramer C-GM/3RVF. If you have a VGA to a 5BNC cable, use the RGB connections only. 2. Connect an unbalanced stereo audio source (for example, the audio output from the PC) to the LEFT and RIGHT AUDIO IN RCA connectors. -
Page 9: Figure 2: Connecting To The Vp-483 Rear Panel
Figure 2: Connecting to the VP-483 Rear Panel VP-483 - Connecting the VP-483... -
Page 10: Operating The Vp-483 Pc/Component To 3G Hd-Sdi Scaler
Operating the VP-483 PC/Component to 3G HD-SDI Scaler The VP-483 is operated directly via the front panel buttons and via the On-screen Display (OSD) menu (see Section .2). Using the Front Panel Buttons During normal operation (without the OSD), the front panel buttons perform in the following manner: ... - Page 11 Sets the output brightness 0-100 FINE- Sets the output hue 0-100 TUNE SATURATION Sets the output saturation 0-100 SHARPNESS Sets the output sharpness 0-100 NOISE Sets the noise reduction level OFF/LOW/MID/HI REDUCTION VP-483 - Operating the VP-483 PC/Component to 3G HD-SDI Scaler...
- Page 12 For example, when the output is connected to a projector, the projector shuts down automatically when there is no input EXIT Closes the OSD and returns to normal operation VP-483 – Operating the VP-483 PC/Component to 3G HD-SDI Scaler...
-
Page 13: Technical Specifications
STORAGE TEMPERATURE: -40° to +70°C (-49° to 158°F) HUMIDITY: 10% to 90%, RHL non-condensing 18.8cmx11.4cmx2.5cm(7.4”x4.5”x1”)W,D,H DIMENSIONS: WEIGHT: 0.47kg (1.04lbs) approx. ACCESSORIES: Power supply OPTIONS: RK-T2B 19" rack adapter Specifications are subject to change without notice at http://www.kramerelectronics.com VP-483 - Technical Specifications... - Page 14 VP-483 – Technical Specifications...
- Page 15 For the latest information on our products and a list of Kramer distributors, visit our Web site where updates to this user manual may be found. We welcome your questions, comments, and feedback. Web site: www.kramerelectronics.com E-mail: info@kramerel.com SAFETY WARNING...
