Page 1: User Manual
Kramer Electronics, Ltd. USER MANUAL Models: PT-1SPDIF, Digital Audio Converter PT-2SPDIF, Digital Audio Converter... -
Page 2: Table Of Contents
Figure 3: Connecting the PT-1SPDIF Digital Audio Converter Figure 4: Connecting the PT-2SPDIF Digital Audio Converter Tables Table 1: PT-1SPDIF Features Table 2: PT-2SPDIF Features Table 3: Technical Specifications of the PT-1SPDIF Digital Audio Converter Table 4: Technical Specifications of the PT-2SPDIF Digital Audio Converter... -
Page 3: Introduction
Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9: Room Connectivity; GROUP 10: Accessories and Rack Adapters; GROUP 11: Sierra Products 2 Download up-to-date Kramer user manuals from the Internet at this URL: http://www.kramerelectronics.com 3 The complete list of Kramer cables is on our Web site at http://www.kramerelectronics.com... - Page 4 Getting Started KRAMER: SIMPLE CREATIVE TECHNOLOGY...
-
Page 5: Overview
Overview Overview The PT-1SPDIF is a high quality digital audio converter that accepts a digital audio S/PDIF input and converts it to an optical TosLink® audio output. The PT-2SPDIF is a high quality digital audio converter that accepts an optical TosLink®... -
Page 6: Your Pt-1Spdif Digital Audio Converter
Your PT-1SPDIF / PT-2SPDIF 4.1 Your PT-1SPDIF Digital Audio Converter Figure 1 and Table 1 define the PT-1SPDIF Digital Audio Converter: Table 1: PT-1SPDIF Features Feature Function 12V DC +12V DC connector for powering the unit OPTICAL TosLink® Connect to the digital... -
Page 7: Connecting The Pt-1Spdif / Pt-2Spdif
Figure 3: Connecting the PT-1SPDIF Digital Audio Converter 1 Switch OFF the power on each device before connecting it to your PT-1SPDIF. After connecting your PT-1SPDIF, switch on its power and then switch on the power on each device... -
Page 8: Connecting The Pt-2Spdif Digital Audio Converter
Connecting the PT-1SPDIF / PT-2SPDIF 5.2 Connecting the PT-2SPDIF Digital Audio Converter To connect the PT-2SPDIF Digital Audio Converter, as the example in Figure illustrates, do the following 1. Connect the digital audio source (for example, the digital audio from a DVD player) to the OPTICAL TosLink®... -
Page 9: Technical Specifications
Technical Specifications Technical Specifications Table 3 Table 4 define the technical specifications Table 3: Technical Specifications of the PT-1SPDIF Digital Audio Converter INPUT: 1 S/PDIF (digital audio) on an RCA connector OUTPUT: 1 Optical (digital audio) on a Toslink® connector... - Page 10 EXCLUSION OF DAMAGES The liability of Kramer for any effective products is limited to the repair or replacement of the product at our option. Kramer shall not be liable for: 1. Damage to other property caused by defects in this product, damages based upon inconvenience, loss of use of the product, loss of time, commercial loss;...
- Page 11 For the latest information on our products and a list of Kramer distributors, visit our Web site: www.kramerelectronics.com, where updates to this user manual may be found. We welcome your questions, comments and feedback. Safety Warning: Disconnect the unit from the power supply before opening/servicing.
