PIX 260i User Guide and Technical Information
Sync Output
Sync Input

Control

RS422
Ethernet
GPIO

Keyboard

USB Keyboard

Power

External

Physical

Size (H x W x D)
Weight
Operating Temperature
84
v. 1.50 Features and specifications are subject to change. Visit www.sounddevices.com for the latest documentation.
• Analog bi-, tri-level sync / Genlock
• Wordclock (Square wave, 48 kHz sampling rate, 3.3vp-p, 75 ohm)
• Analog bi-, tri-level sync / Genlock
• Wordclock (Square wave, 48 kHz sampling rate, 3.3vp-p, 75 ohm)
Machine Control
Web-based control of settings and transport
GPIO on 8 pins, Phoenix connector
Front-panel USB host. Keyboards without hubs
10–27V, 60W max, via locking 4-pin XLR connector (pin-1 = ground, pin-4 = +).
ering
3.3" x 8.6" x 10.3" (8.4 cm x 21.8 cm x 26.2 cm)
7.5 lbs
-10° C to +40° C
acceptable.
See Pow-
