Sound Devices PIX 260i User Manual page 10

PIX 260i User Guide and Technical Information
Digital Audio Input/Output (DB-25)
6)
8 channels of AES digital audio input
and 8 channels of AES digital output.
"Connector Pin Assignments", page
Ch. 1-8 Analog Audio Output (DB-25)
7)
8 channels of balanced, line-level analog
audio output.
ments", page
Ch. 1-8 Analog Audio Input (DB-25)
8)
8 channels of balanced, line-level analog
audio input.
ments", page
Analog Audio Outputs (XLR)
9)
2 channels of balanced, line-level analog
audio outputs.
Analog Audio Inputs (XLR)
10)
2 channels of balanced, line-level analog
audio inputs.
Ethernet (RJ-45)
11)
Attaches to 1G or 100M Ether networks.
Provides Dante connectivity
Audio Inputs", page
Grouping
45), web access for remote control
"Web Interface - PIXNET", page
network file service.
Management", page
RS-422 Control (DB-9)
12)
Connects to RS-422 Controllers for exter-
nal control of the PIX 260i.
page 47)
4
v. 1.50 Features and specifications are subject to change. Visit www.sounddevices.com for the latest documentation.
78)
(See "Connector Pin Assign-
78)
(See "Connector Pin Assign-
78)
(See "Dante
15), Network
(See "PIX Grouping", page
(See
47), and
(See "Storage and File
56)
(See "RS422",
External Drive Connections (eSATAp)
13)
Connector for approved 2.5-inch SATA
(See drives. Sound Devices maintains a list
of tested and approved SSD drives for
use with PIX video recorders. Visit
sounddevices.com/approved
date list of tested and approved drives.
SDI Video Input (BNC)
14)
SDI video input. Accepts 3G-SDI, HD-
SDI, or SD-SDI signal with up to 16 chan-
nels of embedded audio.
SDI Video Output (BNC)
15)
SDI video output. Provides 3G-SDI, HD-
SDI, or SD-SDI signal with up to 16 chan-
nels of embedded audio.
HDMI Video Input (HDMI)
16)
Accepts HDMI (1.4a) signal with 8
channels of embedded audio. The PIX
260i does not record or display content
encoded with HDCP.
HDMI Video Output (HDMI)
17)
Provides HDMI (1.3) signal with 8 chan-
nels of embedded audio.
GPIO Remote (Phoenix 10-pin)
18)
Logic contact points for remote control.
(See "GPIO (General Purpose Input / Out-
put)", page 54)
USB Connection
19)
Factory use only.
www.
for an up-to-
