the previous file's last Cue Marker (if applicable) or beginning. File Skip functions will work while a
clip is playing and while it is paused.
If the last file played was an individual track from a mono WAV take, skipping will occur between that
take's tracks rather than the default behavior of skipping between takes. When the first or final track is
navigated away from, file skipping will again occur between takes.
Shuttle Playback Mode
Shuttle Playback Mode is available in Video Mode only
In Shuttle Playback Mode the PIX 260i is capable of playing back at various rates in forward and in
reverse. Shuttle Playback Mode is only available when playing back Quicktime .mov files.
To immediately enter Shuttle Playback Mode from the Main View, press the Control Knob. The cued
file will begin playback at half speed (FFx1/2). Shuttle Playback Mode can also be accessed while a
file is playing back or when paused by pressing the Control Knob.
When Shuttle Playback Mode is active, the OSD items ABS Time, Timecode, and Filename are
displayed in blue. Turn the Control Knob to select among the available playback directions and rates.
The following table defines the playback directions and speeds available when turning the Control
Knob in Shuttle Playback Mode.
Reverse
32 16 8
7
6
5 4 3 2 1 1/2 1/3 1/4 1/5 1/6 1/7 1/8 1/8 1/7 1/6 1/5 1/4 1/3 1/2 1 2 3 4 5
In Shuttle Playback Mode, the playback direction and speed will be indicated on the LCD if Setup
Menu option [Display - ABS Time] is set to On. The FF (>>) and RW (<<) buttons will illuminate
independently to indicate the playback direction. Press the Control Knob while in Shuttle Mode to
pause playback. Press the PLAY () button while in Shuttle Mode to return to Playback Mode.
Cue Marker
Cue Markers are available in Video Mode only.
During Record, Playback, or Shuttle mode, press FILES button + Fast Forward (>>) button to set a
Cue Marker. To delete a Cue Marker, press FILES button + RW (<<) button. A dialog box appears
asking Delete Cue Marker? Cue (number), select OK to delete and Cancel to ignore. Cue Markers
added or deleted during record are applied to all available drives. Cue Markers added or deleted
during playback or shuttle mode are only applied to the current playback drive.
To quickly jump to the next or previous Cue Marker, press the FF (>>) or RW (<<) button respec-
tively. The previous Cue Marker is displayed in the lower left-hand corner of the OSD when
[On-Screen Display - Cue Marker] is On. The OSD field will be displayed in various colors depend-
ing on the current transport status, Red = Record, Green = Play, Blue = REW/FF/Shuttle.
Content between consecutive cue markers is referred to as a "segment". The beginning and end of a
file are effectively cue markers. A file with a single cue marker will have 2 segments (From the begin-
ning of the file to Cue 1 and from Cue 1 to the end of the file). When jumping to cue markers during
playback,
Looping Playback
PIX 260i User Guide and Technical Information
Forward
6 7 8 16 32
35
