Summary of Contents for NetComm NTC-3000
- Page 1 QUICK START GUIDE NetCommWirele M2M Serial Modem NetCommWireless NTC-3000...
-
Page 2: Installation
INSTALLATION - INSERTING THE SIM CARD Please ensure that the NTC-3000 is not connected to the power cable before proceeding. Push the small yellow button besides the SIM card holder with a paper clip or similar pointed object. Insert the SIM card into the holder with the SIM conductor pins facing up. - Page 3 Insert the SIM card holder with the SIM conductor pins facing down into the NTC-3000. Connect a compatible 3G antenna to the SMA connector on the NTC-3000. 3G Antennas can be purchased as an accessory from the NetComm website at www.netcommwireless.com...
-
Page 4: Connecting The Data/Power Cable
After power on, the NTC-3000 is now ready to establish a serial communication link. MOUNTING OPTIONS The NTC-3000 series modem can be mounted on the wall or a DIN rail by using the mounting bracket. The mounting bracket is made from polyamide, which is a flexible material. -
Page 5: Din Rail Mounting
DIN RAIL MOUNTING The NTC-3000 Series mounting bracket has been designed to fit a TS 35 Type-O DIN rail with a 25mm core. Bend / Flex the mounting bracket at the bend line so that the ridges are able to ‘hold’... -
Page 6: Connecting Via Usb
For example, to connect a terminal emulator, open a HyperTerminal and create a new connection to the COM port of your serial port, with the bitrate set to 115200. In the HyperTerminal type “AT” (no quotations) and press enter. If the NTC-3000 is connected the reply will be “Ok”. - Page 7 INSTALLING THE NTC-3000 USB DRIVERS For USB port communication, you must install a driver compatible with the NTC-3000’s embedded Sierra Wireless AirPrime cellular module. This can be done by downloading the Windows or MAC-OS Sierra Wireless 3G Watcher software for the NTC-3000 serial modem from www.netcommwireless.com.
- Page 8 If you are still unable to successfully install the device please contact Technical Support at NetComm Wireless Limited at http://www.netcomm-commercial.com.au/contact-us/ technical-support Once the driver has been installed, serial connectivity can be achieved via the “AT Command Port”. Alternatively, a PPP Internet Connection can be established by launching the 3G Watcher Program installed by the driver installation.
-
Page 9: Led Indicators
LED INDICATORS The NTC-3000 Series uses two LEDs to display the current system and connection status. LED Indicator Colour Definition Power The power is off The power is on 3G connection is down Slow flashing green Searching the network Green... -
Page 10: Mini Usb Connector
The mini USB connector can be connected to a USB 2.0 host port on a computer or other device to provide an alternate power input to the NTC-3000 as well as alternate serial connectivity. The mini USB port can also optionally facilitate a high speed PPP Internet connection, if required. It utilises a standard mini USB pin out configuration. -
Page 11: To Db-9 Serial/Power Adapter Cable
RJ-45 TO DB-9 SERIAL/POWER ADAPTER CABLE The NTC-3000 Series uses a RJ-45 to DB-9 serial cable to facilitate communications to an attached device. Pins 1 and 4 are used to supply power to the NTC-3000 Series. DB9 Signals RJ45 DC Power Socket... - Page 12 CONTACT Address: NetComm Wireless Limited 18-20 Orion Rd, Lane Cove NSW, 2066 Sydney, Australia ABN: 85 002 490 486 Website: www.netcommwireless.com +61 (0) 2 94242070 Phone: Fax: +61 (0) 2 94242010 sales@netcommwireless.com Email: technicalsupport@netcommwireless.com NetCommWireless...
