Polycom SoundPoint IP 670 User Manual page 17

Item
11 Speaker
12 Soft Keys
13 Graphic Display
14 Line/Speed Dial Key
15 Line Indicators
16 Hookswitch
Getting Started with Your Phone
Description
For ringer and hands-free audio
output.
These keys are automatically labeled
to identify their context-sensitive
functions.
Shows information about calls,
messages, soft keys, time, date, and
other relevant data.
• Caller display information—first
party, second party, number of
calls
• Information status line
• Popup text (for example,
network errors)
• Do Not Disturb text
• Missed call text or second
incoming caller display
• Prompt text (for example, "Enter
number")
• Time and date text (if idle
display is not used for time/date
display)
Associated line icons are described in
the following table.
Use these keys to activate up to four
lines or speed dials that can be
assigned to your phone.
Individual multi-color LEDs display
the dynamic call state and remote
user status (busy lamp field (BLF)
and presence). The mapping is:
• Solid green—An active call is in
progress.
• Fast flashing green—There is an
incoming (ringing) call.
• Flashing green—The call is held
by the other party.
• Flashing red—The call is on hold.
• Solid red—The line is busy
remotely (shared lines)
1 - 11
