- Page 1 Model Number: DP6391 High-pressure Pneumatic Airless paint sprayer Instruction Manual (Please read carefully before using) http://www.airlesspaintsprayer-pump.com...
-
Page 3: Safety Warning
● This equipment must only be operated by trained personnel. ● Every equipment has a specific use. Please consult the agent of Dino-power if you have any questions. ● Never attempt to modify the equipment, nor exceed the maximum working pressure of the system. - Page 4 All modifications due to error correction or product improvement will be explained by Dino-Power Industry & Trade Co., Ltd. at any time without notice. The revised parts will be included in the second edition of the instruction manual.
-
Page 5: Product Characteristics
38: 1 13.50 0.3~0.6 650-1400 87.00 DP6391B 46: 1 10.40 0.3~0.6 650-1400 84.00 DP6391B 69: 1 7.00 0.3~0.6 650-1400 84.00 DP6391C 45: 1 13.50 0.3~0.6 900-1650 99.00 DP6391C 60: 1 11.00 0.3~0.6 900-1650 96.00 DP6391C 76: 1 8.00 0.3~0.6 900-1650... - Page 6 3 outline drawing of Dino-Power Airless Sprayer (See Figure) Air intake The main working part of the sprayer is the double-acting air-driven high pressure painting pump. The reversing mechanism is the pilot all pneumatic control air-distributing reversing device with special form.
- Page 7 capacity of the equipped air compressor must be large enough. The length of the used air pipe must not exceed 5m. 4.2 Plug both the coating suction pipe and the discharge valve into the tank containing diluted coating, put through the air source, and adjust the air intake pressure according to the type of coating. To ensure safe use, the maximum air intake pressure must not exceed 0.6MPa, and is better to be kept at a value as low as possible as long as the atomization of the coating is good.
- Page 8 5 Common Faults and Trouble-shooting Method Generally, the faults of airless sprayer can be divided into two types: faults in air system and faults in coating system. If a fault occurs, it's prohibited to dismantle blindly. The fault should be analyzed and eliminated step by step as shown in the following table.
-
Page 9: Equipment Maintenance
After the discharge 1) The V-shape sealing ring on 1) Replace the V-shape ring on the plunger valve valve and the spray the plunger valve body has body. have been been abraded. Caution: The V-shape sealing ring should be closed, 2) The high-pressure valve ports replaced in group and as per its quantity and air-driven motor still... -
Page 10: Packing List
Model DP6391C 45 : 1 Name Specification Quantity Assembling part ￠60 X￠40X 8 Kraft V-shape sealing ring Plunger valve body ￠60 X￠40X 7.5 PTFE V-shape sealing ring Plunger valve body ￠64 X￠42.6X 9 Kraft V-shape sealing ring Pump base ￠64 X￠42.6X 8... -
Page 11: Exploded Drawing
9 Exploded Drawing... -
Page 12: Parts List
10 Parts List Name Name Name Name Plain washer Retaining ring Needle valve One-way valve Bolt Steel ball Inner hexagon cover cheese head screw Rectangular Panel Suction valve Upper cover of spring washer air-distributing cylinder Sliding bush Air intake joint Suction valve body O-shape sealing ring... - Page 13 5、 Thanks to the trust and cooperation of our customers over the long term, series products of “Dino-Power” spraying equipment have excelled in the field of coating technology in all industrial departments. We sincerely hope that you order complete sets or parts of “Dino-Power” spraying...
