Airless Spray Gun
Operating Instruction
Model No:X-450
Please read and keep this manual, Read carefully before attempting to assemble, install, operate or maintain the
product described. Protect yourself and others by observing all safety information. Failure to comply with instructions
could result in personal injury and/or property damage! Retain instruction for future reference.
www.dpairless.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the X-450 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Dino-Power X-450

  • Page 1 Airless Spray Gun Operating Instruction Model No:X-450 Please read and keep this manual, Read carefully before attempting to assemble, install, operate or maintain the product described. Protect yourself and others by observing all safety information. Failure to comply with instructions could result in personal injury and/or property damage! Retain instruction for future reference.
  • Page 2: Safety Precautions

    Safety Precautions Be safety-conscious! All local and national regulations governing ventilation, fire prevention, and operation must be observed. HAZARD: Injection injury A high pressure stream produced by this equipment can pierce the skin and underlying tissues, leading to serious injury and possible amputation. See a physician immediately. DO NOT TREAT AN INJECTION INJURY AS A SIMPLE CUT! Injection can lead to amputation. See a physician immediately. Inform the physician of the type of coating material or cleaning agent with which the injury was caused. The maximum operating range of the spray gun is 25 MPa / 3600 PSI fluid pressure. • NEVER aim the gun at any part of the body. • NEVER allow any part of the body to touch the fluid stream. DO NOT allow body to touch a leak in the fluid hose.
  • Page 3: Residual Risks

    conditions exist. Never repair a paint hose. Replace it with another grounded high- pressure hose. 8. Pulling the trigger causes a recoil force to the hand that is holding the spray gun. The recoil force of the spray gun is particularly powerful when the tip has been removed and a high pressure has been set on the airless high-pressure pump.
  • Page 4: Operation

    Introduction 4. Perform the “Pressure Relief Procedure” This airless spray gun is to be used for the described in the sprayer’s Owner’s high pressure atomization of liquid coating Manual. materials. 5. Using the square tip(1) handle , insert the tip seal (3) and seal (4) into the back Using the Gun Trigger Lock of the tip guard (2).
  • Page 5 Cleanup Changing a Tip Tips can be removed and replaced easily Maintaining a clean gun is important to ensure without disassembling the gun. trouble-free operation. Flush the gun after each use and store in a dry location. Do not leave the gun or any of its parts in water or Never attempt to change or clean solvents.
  • Page 6: Maintenance

    Maintenance Adjusting the Packing Seal Assembly Follow all safety precautions as described Proper adjustment of the packing in the Safety Precautions section of this seal assembly is essential to manual before proceeding. ensure positive shut-off when the trigger is released. Refer to the Parts List section in this manual for part identification. 1. Tighten the lock nut until the rear housing is flush against the gun head. 2. Unscrew the lock nut 3/4 of a turn. Replacing/Servicing the Seal Assembly If your spray gun leaks or spits at the tip when To check the adjustment of the you release the trigger, the needle or seat is seal assembly:...
  • Page 7: Parts List

    Parts list...
  • Page 8 AIRLESS SPRAYING MATERIAL -TIP SIZE CHART Spraying Material From Viscosity Varnishes 0.009 - 0.011 Lacquers, clear coat 0.009 - 0.011 Shellac (clear) 0.009 - 0.013 Thin materials Stains - transparent 0.011 - 0.013 Water sealers (thin, 0.011 - 0.013 clear) Tung Oil (pure thinned) 0.011 - 0.013...
