Assembly; Hardware View - ProForm 780 Cse Elliptical Manual

M8.5 x 16mm x
M6 Split Washer M8 Split M10 x 25mm M10 Curved Link Arm
1.5mm Washer
(102)–8 Washer (87)–2 Washer (99)–4
Spacer (74)–4
Washer (101)–4
(103)–6
M4 x 16mm
M6 x 35mm Patch M6 x 62mm
Screw (97)–16 Screw (109)–4 Patch Screw (108)–4
Wave Washer
(100)–2
M8 x 15mm Patch M8 x 20mm Patch M8 x 25mm Patch M10 x 20mm Patch
Screw (106)–10 Screw (107)–4 Screw (110)–2 Screw (111)–2
M10 x 93mm Patch Screw (82)–4
