Model No. GGBE29922
Serial No.
Write the serial number in the
space above for future reference.
Serial Number Decal (Under Seat)
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. If you
have questions, or if there are
missing or damaged parts, we
will guarantee complete satisfac-
tion through direct assistance
from our factory.
TO AVOID DELAYS, PLEASE
CALL DIRECT TO OUR TOLL-
FREE CUSTOMER HOT LINE.
The trained technicians on our
customer hot line will provide
immediate assistance, free of
charge.
CUSTOMER HOT LINE:
1-800-999-3756
Mon.–Fri., 6 a.m.–6 p.m. MST
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
USER'S MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GGBE29922 and is the answer not in the manual?

Questions and answers

John min
March 2, 2025

Manual XRS 30 please

User image 67c4bc627a110
1 comments:
Mr. Anderson
March 2, 2025

The manual for Gold's Gym part number GGBE29922 is referenced in the provided context. It contains ordering information, warranty details, a parts list, and assembly instructions. The manual includes an exploded drawing and part identification chart to assist with replacement parts.

This answer is automatically generated

Summary of Contents for Gold's Gym GGBE29922

  • Page 1 Model No. GGBE29922 Serial No. Write the serial number in the space above for future reference. Serial Number Decal (Under Seat) QUESTIONS? As a manufacturer, we are com- mitted to providing complete customer satisfaction. If you have questions, or if there are...
  • Page 2: Table Of Contents

    Monday through Friday, 6 a.m. until 6 p.m. Mountain Time, to order a free replacement decal. Apply the decal in the location shown. GOLD'S GYM is a registered trademark of Gold's Gym International, Inc. This product is manufactured and distributed under license from Gold's Gym International, Inc.
  • Page 3: Important Precautions

    IMPORTANT PRECAUTIONS WARNING: To reduce the risk of serious injury, read the following important precautions before using the weight bench. 1. Read all instructions in this manual before using the weight bench. Use the weight bench only as described in this manual. 2.
  • Page 4: Before You Begin

    To help us assist you, please note the product model number and serial number before calling. The model number is GGBE29922. The serial number can be found on a decal attached to the weight bench (see the front cover of this manual).
  • Page 5: Assembly

    ASSEMBLY Make Things Easier for Yourself Everything in this manual is designed to ensure that the weight bench can be assembled suc- cessfully by anyone. However, it is important to realize that the versatile weight bench has many parts and that the assembly process will take time.
  • Page 6 2. Press two 50mm Thick Square Inner Caps (53) and a 2” x 3” Inner Cap (50) into the ends of the Center Base (24). Have a second person hold the Right and Left Uprights (1, 2 [not shown]). Attach the Right and Left Bases (22, 23) to the Center Base (24) with two M10 x 97mm Bolts (90) and two M10 Nylon Locknuts (77).
  • Page 7 6. Press two 75mm Bushings (26) into the top and bottom of the Right Weight Rest (12). Pull the Knob (30) out as far as it will go. Slide the Right Weight Rest (12) onto the Right Upright (2) and engage the Knob into an adjustment hole in the Upright.
  • Page 8 10. Orient the Pull-up Bar (8) with the bend on top. Attach the Pull-up Bar to the Right Frame (5) with two M10 x 57mm Bolts (78), two M10 Washers (79), and two M10 Nylon Locknuts (77). Do not tighten the Locknuts yet. Attach the Pull-up Bar (8) to the Left Frame (not shown) in the same manner.
  • Page 9 14. Attach the Bench Frame (14) to the Back Leg (39) with an M10 x 78mm Bolt (70), two M10 x 164mm Bolts (71), an M10 Washer (79), and three M10 Nylon Locknuts (77). Do not tighten the Locknuts yet. 15.
  • Page 10 18. Press two 38mm Square Inner Caps (44) into the ends of the Seat Frame (17). Orient the Seat (37) with the wide end on the side shown. Attach the Seat to the Seat Frame (17) with four M6 x 16mm Screws (72). 19.
  • Page 11 22. Route the Bench Cable (58) under a 4 1/2” Pulley (35). Attach the Pulley to the Front Leg (18) with an M10 x 75mm Bolt (73), two 17mm Spacers (96), two M10 Washers (79), and an M10 Nylon Locknut (77). 23.
  • Page 12 26. Wrap the High Cable (61) around an 88mm Pulley (36). Attach the Pulley and a Small Cable Trap (93) to the Left Frame (6) with an M10 x 45mm Bolt (76) and an M10 Nylon Locknut (77). Note: 88mm is approximately 3 1/2”. 27.
  • Page 13 31. Wrap the Carriage Cable (60) around a 4 1/2” Pulley (35). Attach the Pulley and a Large Cable Trap (55) to the single set of holes in the pair of Pulley Plates (31) with an M10 x 45mm Bolt (76) and an M10 Nylon Locknut (77).
  • Page 14 35. Locate the Low Cable (59). Lay the Cable inside the bracket on the Center Base (24) so that the ball is on the side shown. Attach a 4 1/2” Pulley (35) inside the bracket with an M10 x 45mm Bolt (76) and an M10 Nylon Locknut (77).
  • Page 15 39. Attach the Low Cable (59) to the “U”-Bracket (33) with an M6 Washers (62) and an M6 Locknut (80). Do not completely tighten the Locknut; it should be threaded onto the end of the Cable until only two threads are showing above the Locknut, as shown in the inset drawing.
  • Page 16: Adjustments

    ADJUSTMENTS This section explains how to adjust the weight bench. The first time you perform an exercise that uses the safety spotter, adjust the bench to the position that is best for you. Note the position of the weight rest and safety spot- ter on the BENCH ADJUSTMENT CHART, on page 20 of this manual.
  • Page 17: Attaching Weights To Weight Carriage/Barbell

    ATTACHING THE BENCH TO THE RACK To perform bench and leg lever exercises, the weight bench must be attached to the weight rack. To attach the bench to the rack, rest the Back Leg (39) over the crossbar on the Center Base (24). Make sure that the Low Cable (59) goes through the Back Leg.
  • Page 18 USING THE POWER ASSIST LEGS If you are unable to complete the repetition after per- forming a bench exercise, the Power Assist Legs (20, 21) can be used to help lift the barbell back to the Weight Rests (not shown). To use the Power Assist Legs (20, 21), attach the bench to the rack and a barbell to the high cable (see ATTACHING THE BENCH TO THE RACK and...
  • Page 19: Cable Diagram

    CABLE DIAGRAMS The cable diagrams below show the proper routing of the Bench Cable (58), the Low Cable (59), the Carriage Cable (60), and the High Cable (61). Use the diagram to make sure that the cables and the cable traps have been assembled correctly.
  • Page 20: Bench Adjustment Chart

    BENCH ADJUSTMENT CHART The chart below contains a list of exercises that require the use of the safety spotter. When preparing the weight bench for one of these exercises, follow the steps listed below. For information about each of these steps, refer to the ADJUSTMENTS section of this manual.
  • Page 21: Exercise Guidelines

    EXERCISE GUIDELINES THE FOUR BASIC TYPES OF WORKOUTS MUSCLE BUILDING To increase the size and strength of your muscles, push them close to their maximum capacity. Your mus- cles will continually adapt and grow as you progres- sively increase the intensity of your exercise. You can adjust the intensity level of an individual exercise in two ways: •...
  • Page 22: Cooling Down

    Rest for a short period of time after each set. The ideal resting periods are: • Rest for three minutes after each set for a muscle building workout. • Rest for one minute after each set for a toning work- out.
  • Page 23 EXERCISE MONDAY Date: AEROBIC EXERCISE TUESDAY Date: EXERCISE WEDNESDAY Date: THURSDAY AEROBIC EXERCISE Date: EXERCISE FRIDAY Date: Make photocopies of this page for scheduling and recording your workouts. WEIGHT WEIGHT WEIGHT SETS REPS SETS REPS SETS REPS...
  • Page 24: Part Identification Chart

    M10 x 45mm Bolt (76) M10 x 25mm Button Bolt (81) M4 x 19mm Screw (68) M6 x 16mm Screw (72) —Model No. GGBE29922 M10 Nylon Locknut (77) M6 Locknut (80) M10 x 57mm Bolt (78) M10 x 62mm Carriage Bolt (74)
  • Page 25: Part List

    PART LIST—Model No. GGBE29922 Key No. Qty. Description Left Upright Right Upright Center Upright Center Frame Right Frame Left Frame Pulley Arm Pull-up Bar Top Frame Safety Spotter Left Weight Rest Right Weight Rest Support Leg Bench Frame Sliding Seat Frame...
  • Page 26 EXPLODED DRAWING—Model No. GGBE29922 R0903A...
  • Page 27: Ordering Replacement Parts

    Friday, 6 a.m. until 6 p.m. Mountain Time (excluding holidays). To help us assist you, please be pre- pared to give the following information: • The MODEL NUMBER of the product (GGBE29922) • The NAME of the product (GOLD’S GYM •...
