Model No. GGBE1657.0
Serial No.
Write the serial number in the
space above for future reference.
Serial Number Decal
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. If you
have questions, or if a part is
damaged or missing, PLEASE
CONTACT OUR CUSTOMER
SERVICE DEPARTMENT
DIRECTLY.
CALL TOLL-FREE:
1-877-776-4777
Mon.–Fri., 6 a.m.–6 p.m. MST
Sat. 8 a.m.-4 p.m. MST
ON THE WEB:
www.goldsgympowerflex.com
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manu-
al for future reference.
USER'S MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GGBE1657.0 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Gold's Gym GGBE1657.0

Summary of Contents for Gold's Gym GGBE1657.0

  • Page 1 Model No. GGBE1657.0 Serial No. Write the serial number in the space above for future reference. Serial Number Decal QUESTIONS? As a manufacturer, we are com- mitted to providing complete customer satisfaction. If you have questions, or if a part is...

  • Page 2: Table Of Contents

    Apply the decals in the location shown. Note: The decals may not be shown at actual size. GOLD'S GYM is a registered trademark of Gold's Gym International, Inc. This product is manufactured and distributed under license from Gold's Gym International, Inc.

  • Page 3: Important Precautions

    IMPORTANT PRECAUTIONS WARNING: To reduce the risk of serious injury, read the following important precautions before using the weight bench. 1. Read all instructions in this manual warnings on the weight bench before using the weight bench. Use the weight bench only as described in this manual.

  • Page 4: Before You Begin

    Weight Tube ® model number and serial number before contacting us. The model number is GGBE1657.0. The serial number can be found on a decal attached to the weight bench (see the front cover of this manual). To avoid a registration fee for any service needed under warranty, you must register the weight bench at www.iconservice.com/registration.

  • Page 5: Part Identification Chart

    PART IDENTIFICATION CHART See the drawings below to identify small parts used in assembly. The number in parentheses by each drawing is the key number of the part, from the PART LIST on page 17. Note: Some small parts may have been pre- attached.

  • Page 6: Assembly

    ASSEMBLY Make Assembly Easier Everything in this manual is designed to ensure that the weight bench can be assembled suc- cessfully by almost anyone. By setting aside plenty of time, assembly will go smoothly. Before beginning assembly, carefully read the fol- lowing information and instructions: •...
  • Page 7 2. Attach the Rear Stabilizer (3) to the Frame (1) with two M10 x 90mm Carriage Bolts (40) and two M10 Nylon Locknuts (57). Do not tighten the Nylon Locknuts yet. 3. Attach the Seat (18) and the Seat Bracket (8) to the Frame (1) with two M6 x 80mm Screws (46) and two M6 Washers (53).
  • Page 8 5. Apply a portion of the included grease to an M10 x 165mm Bolt (49). Attach the Backrest Post (15) to the Backrest Frames (16) with the Bolt, two M10 Washers (52), and an M10 Nylon Locknut (57). Do not tighten the Nylon Locknut yet.
  • Page 9 8. Insert the Long Pad Tube (36) into the bracket on the Front Leg (4). Slide two Foam Pads (22) onto the Long Pad Tube, and press a Pad Cap (23) into each Foam Pad. Repeat this step with the two Short Pad Tubes (21).
  • Page 10 11. Attach a Foot (39) to the Left Upright Base (9) with an M5 x 19mm Screw (50). Insert an M10 x 90mm Carriage Bolt (40) up into the Upright Base. Attach the Left Upright Base (9) to the Base (7) with two M10 x 90mm Carriage Bolts (40), an M10 x 90mm Bolt (42), four M10 Washers (52), and three M10 Nylon Locknuts (57).

  • Page 11: Adjustments

    ADJUSTMENT This section explains how to adjust the weight bench. See the EXERCISE GUIDELINES on page 13 for impor- tant information about how to get the most benefit from your exercise program. Also, refer to the accompanying exercise guide to see the correct form for each exercise. Make sure all parts are properly tightened each time you use the weight bench.
  • Page 12 REMOVING THE CURL BAR When performing exercises that do not require the Curl Bar (17), pull the Curl Bar Pin (33) out of the Leg Lever (5) and remove the Curl Bar. When attaching the Curl Bar (17), insert the Curl Bar Pin (33) completely through the Leg Lever (5).

  • Page 13: Exercise Guidelines

    EXERCISE GUIDELINES THE FOUR BASIC TYPES OF WORKOUTS Muscle Building To increase the size and strength of your muscles, push them close to their maximum capacity. Your mus- cles will continually adapt and grow as you progres- sively increase the intensity of your exercise. You can adjust the intensity level of an individual exercise in two ways: •...

  • Page 14: Cooling Down

    Rest for a short period of time after each set. The ideal resting periods follow: • Rest for three minutes after each set for a muscle building workout. • Rest for one minute after each set for a toning work- out.
  • Page 15 EXERCISE MONDAY Date: AEROBIC EXERCISE TUESDAY Date: EXERCISE WEDNESDAY Date: AEROBIC EXERCISE THURSDAY Date: EXERCISE FRIDAY Date: Make photocopies of this page for scheduling and recording your workouts. WEIGHT WEIGHT WEIGHT SETS REPS SETS REPS SETS REPS...
  • Page 16 EXERCISE MONDAY Date: TUESDAY AEROBIC EXERCISE Date: EXERCISE WEDNESDAY Date: THURSDAY AEROBIC EXERCISE Date: EXERCISE FRIDAY Date: Make photocopies of this page for scheduling and recording your workouts. WEIGHT WEIGHT WEIGHT SETS REPS SETS REPS SETS REPS...

  • Page 17: Part List

    PART LIST—Model No. GGBE1657.0 Key No. Qty. Description Frame Front Stabilizer Rear Stabilizer Front Leg Leg Lever Curl Post Base Seat Bracket Left Upright Base Right Upright Base Upright Weight Rest Safety Spotter Storage Tube Backrest Post Backrest Frame Curl Bar...

  • Page 18: Exploded Drawing

    EXPLODED DRAWING—Model No. GGBE1657.0 R0507A...
  • Page 19 EXPLODED DRAWING—Model No. GGBE1657.0 R0507A...

  • Page 20: Ordering Replacement Parts

    ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to pro- vide the following information when contacting us: • the model number and serial number of the product (see the front cover of the manual) •...
