- Page 1 SPORTSTER SE User’s Manual KIM ELECTRIC VEHICLES KIBBUTZ AFIKIM 15148, ISRAEL TEL: 972-4-6754814, FAX: 972-4-6751456 e-mail: mainbox@afiscooters.com websites: www.afiscooters.com P/N PR00056...
- Page 2 WARNING Read the User’s Manual carefully before operating the SPORTSTER. If you do not fully understand any part of this Manual, please contact your dealer or any of our Service Centers - as injury or damage may occur from misuse! WARNING Electromagnetic Interference (“EMI”) can cause powered vehicles to behave erratically, which could be dangerous to the user.
- Page 3 CE CERTIFICATION The Afikim Electric Vehicles Ref. Registration Number with the Competent Authority (UK) is: CA 000292. Our Authorized Representative with the Competent Authorities is: MEDES LTD. POB 231 Stanmore, Middlesex, HA7 4YA, England TEL/FAX: 0044-181-954-9964...
-
Page 4: Table Of Contents
CONTENTS CHAPTER 1 - Overview Of The Sportster SE ......1 Safety Instructions ..............2 General Description Of The Sportster SE......3 CHAPTER 2 - Adjustment & Operating Instructions.....6 CHAPTER 3 - Maintenance..........12 CHAPTER 4 - Charging............15 CHAPTER 5 - Troubleshooting and Fault Repair ....17... -
Page 5: Chapter 1 - Overview Of The Sportster Se
Under normal conditions the SPORTSTER can travel approximately 40 km (25 miles) before the batteries require recharge. The SPORTSTER SE is developed to use dry or gel batteries only. The SPORTSTER SE Series includes - Model SE - - Single Seat –... -
Page 6: Safety Instructions
SAFETY INSTRUCTIONS Please note and strictly adhere to the following Safety Instructions. Additional Warnings and Notices are printed in this User’s Manual; it is imperative that you read carefully all chapters of this Manual before operating the SPORTSTER. It is also advisable to refresh your memory by re-reading this Manual periodically. Use gel/dry batteries only. -
Page 7: General Description Of The Sportster Se
GENERAL DESCRIPTION OF THE SPORTSTER SE Note: 1. The numbers in parentheses refer to the parts illustrated on Figure 1. Handlebars (2) There are two separate and independently adjustable handlebars, one of which houses the controls for the SPORTSTER. Your SPORTSTER is delivered to you with right-hand controls. - Page 8 Single Seat Model Figure 1...
- Page 9 TECHNICAL SPECIFICATIONS MODEL No. : Single Seat XXL Seat (65 cm) Wide Seat (79 cm) Units Metric Metric Metric Length (without rear basket) 150 cm 59” 170 cm 67” 170 cm 67” Dimensions * (with rear basket) 175 cm 69” Width 72 cm 28”...
-
Page 10: Chapter 2 - Adjustment & Operating Instructions
CHAPTER 2 - ADJUSTMENT & OPERATING INSTRUCTIONS (Reference numbers refer to the figures at the bottom of each page) Adjusting the Handlebars Adjust angles and height of both handlebars as follows: • Release the Handlebars Clamp (1), which secures the handlebars in place, by turning the cam Lever outward from the vehicle. - Page 11 • The SPORTSTER has a Main Key Switch (9) - located on the Key Switch right side of the Headlight Housing. The Main Key Switch has two positions: • “OFF” - The SPORTSTER cannot be driven and the Electromagnetic Brake is locked. •...
- Page 12 Battery Status Indicator The Battery Status Indicator (1) located on top of the Headlight Housing shows you the remaining capacity of the batteries. When the indicator shows that mid-half capacity remains, recharge batteries as soon as possible. When the indicator points that to firs or second segment on the left there are only about 5 km (3 miles) to go.
- Page 13 Speed Range Selector The Speed Range Selector (16) is located on the left side of the Headlight Housing. It has two positions: • Mark “1” (lower position): Low speed - up to 6 km/h (3.1 mph). • Mark “2” (upper position): High speed - 10 km/h (6.2 mph).
- Page 14 Horn/Buzzer (in certain Push Button (20) activates a buzzer. models only) The buzzer sounds automatically under the following conditions (subject to change where prohibited by law): 1. When reversing. 2. When operating the “Turn Signal Switch” (Right or Left). 3. When the “Emergency Electromagnetic Brake Lever ” is operated.
- Page 15 Parking After stopping, turn the Main Key Switch to OFF and remove the key. The lights will turn OFF. The Electromagnetic Brake is engaged (locked). Note: The Electromagnetic Brake is automatically locked whenever the Operating Lever is released and after the SPORTSTER stops completely.
-
Page 16: Chapter 3 - Maintenance
CHAPTER 3 - MAINTENANCE Note: The numbers in parentheses refer to the parts illustrated in figure 2. Although the SPORTSTER requires minimal maintenance, do not neglect it. When servicing the SPORTSTER, make sure that it stands on a level surface and that the key is not inserted. In addition, lock the Hand Brake. - Page 17 Single Seat Model Double Seat Model Figure 2. Removing the Gray Cover for Maintenance...
- Page 18 Removing the Gray Release the lock spring (37) under the Seat and tilt Seat (36) back Cover (33) about 70 degrees until it is almost standing on the rear part of the (Double Seat Model) frame. Remove the Gray Cover (33) as described above (for Single Seat Model).
-
Page 19: Chapter 4 - Charging
CHAPTER 4 - CHARGING Read Charger’s manual before using the charger.. Warning: If you use a different charger, ask your dealer for instructions. CHARGING BATTERIES (See figure 3) 1. Insert the Charging Plug into the Charging Socket located on the front of the GRAY COVER, at the center. - Page 20 Figure 3. Charging batteries...
-
Page 21: Chapter 5 - Troubleshooting And Fault Repair
CHAPTER 5 - TROUBLESHOOTING AND FAULT REPAIR The following table provides troubleshooting and repair instructions for symptoms encountered when operating the SPORTSTER. It presents the best ways to handle the faults. The table contains three columns: The Symptom - describes the functional problem that results from the fault. Probable Cause - lists all probable causes for the relevant symptom. - Page 22 Symptom Probable Causes Remedy • Main Key Switch is in ◊ Turn the key to “ON” SPORTSTER does not move when squeezing OFF position. position. the Operating Lever . • Charging Plug is ◊ Disconnect the Charging installed in Charging Plug from the Socket.
-
Page 23: Chapter 6 - Emi Warning
CHAPTER 6 - EMI WARNING All types of electrically powered vehicles, such as powered wheelchairs and motorized scooters (in this text all types will be referred to as “powered vehicles”) may be susceptible to electromagnetic interference (EMI). This is interfering electromagnetic energy (EM) emitted from sources such as radio and TV stations, amateur radio (HAM) transmitters, two-way radios and cellular phones. - Page 24 WARNINGS Electromagnetic interference (EMI) from sources such as radio and TV stations, amateur radio (HAM) transmitters, two-way radios and cellular phones can affect powered vehicles. Following the warnings listed below should reduce the chance of unintended brake release or powered vehicle movement which could result in serious injury: Do not operate hand-held transceivers (transmitters-receivers) such as citizen band (CB) radios, or turn ON personal communication devices...
- Page 25 Distributed by AFIKIM ELECTRIC VEHICLES KIBBUTZ AFIKIM, 15148, ISRAEL, Telephones Main Office: 972 4 6754814 Sales Department: 972 4 6754180 972 4 6751456 E - Mail mainbox@afiscooters.com Websites www.afiscooters.com...
