Model No. GGBE1067.0
Serial No.
Write the serial number in the
space above for future reference.
Serial Number Decal (under seat)
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete cus-
tomer satisfaction. If you have
questions, or if parts are missing,
PLEASE DO NOT CONTACT
THE STORE; please contact
Customer Care.
IMPORTANT: You must note the
product model number and
serial number (see the drawing
above) before contacting us:
CUSTOMER HOT LINE:
1-877-776-4777
Mon.–Fri. 6 a.m.–6 p.m. MST
Sat. 8 a.m.–4 p.m. MST
ON THE WEB:
www.goldsgympowerflex.com
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manu-
al for future reference.
USER'S MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GGBE1067.0 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Gold's Gym GGBE1067.0

  • Page 1 Model No. GGBE1067.0 Serial No. Write the serial number in the space above for future reference. Serial Number Decal (under seat) QUESTIONS? As a manufacturer, we are com- mitted to providing complete cus- tomer satisfaction. If you have questions, or if parts are missing, PLEASE DO NOT CONTACT THE STORE;...
  • Page 2: Table Of Contents

    Note: The decals may not be shown at actual size. GOLD'S GYM is a registered trademark of Gold's Gym International, Inc. This product is manufactured and distributed under license from Gold's Gym International, Inc.
  • Page 3: Important Precautions

    IMPORTANT PRECAUTIONS WARNING: To reduce the risk of serious injury, read all important precautions and instructions in this manual and all warnings on the weight bench before using the weight bench. ICON assumes no responsibility for personal injury or property damage sustained by or through the use of the weight bench.
  • Page 4: Before You Begin

    BEFORE YOU BEGIN Thank you for selecting the versatile GOLD’S GYM XR 17 weight bench. The weight bench offers an impressive array of weight stations designed to devel- op every major muscle group of the body. Whether your goal is to tone your body, build dramatic muscle size and strength, or improve your cardiovascular sys- tem, the weight bench will help you to achieve the specific results you want.
  • Page 5: Part Identification Chart

    PART IDENTIFICATION CHART Refer to the drawings below to identify small parts used in assembly. The number in parentheses by each draw- ing is the key number of the part, from the PART LIST near the end of this manual. Note: Some small parts may have been preattached.
  • Page 6: Assembly

    ASSEMBLY Make Assembly Easier Everything in this manual is designed to ensure that the weight bench can be assembled suc- cessfully by almost anyone. By setting aside plenty of time, assembly will go smoothly. Before beginning assembly, carefully read the following information and instructions: •...
  • Page 7 2. Attach the Bench Frame (1) to the Front Leg (2) with two M10 x 65mm Bolts (40), two M10 Washers (44), and two M10 Nylon Locknuts (43). Do not tighten the Locknuts. 3. Attach the Bench Frame (1) to the Crossbar (4) with two M10 x 85mm Bolts (41) and two M10 Nylon Locknuts (43).
  • Page 8 5. Orient the Backrest Bracket (10) and the Backrest Frames (12) as shown. Attach the Backrest Bracket to the Backrest Frames with four M8 x 40mm Bolts (37), four M8 Washers (35), and four M8 Nylon Locknuts (47). Do not tighten the Nylon Locknuts yet.
  • Page 9 8. Next, orient the Seat (14) as shown. Attach the Seat to the Bench Frame (1) with four M6 x 20mm Screws (39). 9. Insert a Pad Tube (19) into the Leg Lever (3). Slide two Foam Pads (20) onto the Pad Tube. Then, press two 19mm Round Inner Caps (46) into the Foam Pads.
  • Page 10: Adjustment

    ADJUSTMENT This section explains how to adjust the weight bench. See the EXERCISE GUIDELINES on page 12 for impor- tant information about how to get the most benefit from your exercise program. Also, refer to the accompanying exercise guide to see the correct form for each exercise. Make sure all parts are properly tightened each time the weight bench is used.
  • Page 11 USING THE WEIGHT RESTS To change the height of the Weight Rests (7), remove the Weight Rest Knobs (23). Position the Weight Rests to the desired height in the Uprights (5, 6) and secure them with the Weight Rest Knobs. WARNING: Always set both Weight Rests (7) at the same height.
  • Page 12: Exercise Guidelines

    EXERCISE GUIDELINES THE FOUR BASIC TYPES OF WORKOUTS Muscle Building To increase the size and strength of your muscles, push them close to their maximum capacity. Your mus- cles will continually adapt and grow as you progres- sively increase the intensity of your exercise. You can adjust the intensity level of an individual exercise in two ways: •...
  • Page 13: Cooling Down

    The repetitions in each set should be performed smoothly and without pausing. The exertion stage of each repetition should last about half as long as the return stage. Proper breathing is important. Exhale during the exertion stage of each repetition and inhale during the return stroke.
  • Page 14: Part List

    PART LIST—Model No. GGBE1067.0 Key No. Qty. Description Bench Frame Front Leg Leg Lever Crossbar Right Upright Left Upright Weight Rest Curl Bar Tether Backrest Bracket Curl Post Backrest Frame Backrest Seat Curl Pad Weight Tube Bumper Joint Plate Pad Tube...
  • Page 15: Exploded Drawing

    EXPLODED DRAWING—Model No. GGBE1067.0 R0707A...
  • Page 16: Ordering Replacement Parts

    ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to pro- vide the following information when contacting us: • the model number and serial number of the product (see the front cover of the manual) •...
