NAVI-1/NAVI-XT
4.2.1.3 DGPS Accuracy
Position
Velocity
4.2.1.4 Datum
WGS-84
4.2.1.5 Time to First Position
Hot start
Warm start
Cold start
4.2.1.6 Sensitivity *
Tracking
Hot Start
Warm Start
Cold Start
*
The sensitivity value is specified at the correlator. On a NAVI-1 Evaluation Receiver
using SiRFXTrac firmware with the supplied antenna, 32 dBHz is equivalent to -142
dBm or -172 dBW.
4.2.1.7 Dynamic Conditions
Altitude
Velocity
Acceleration
Jerk
4.2.1.8 DC Power
Power
Operating time
4.2.1.9 Bluetooth™ Serial Port
Connection :
Protocol messages:
Serial port settings:
This confidential document is the property of FALCOM GmbH and may not be copied or circulated without permission.
1 to 5 meters, typical
0.05 meters/second, typical
< 4 sec., average
< 35 sec., average
< 45 sec., average
16 dBHz
23 dBHz
28 dBHz
32 dBHz
18,000 meters (60,000 feet) max.
< 515 meters/second (1000 knots) max.
4 g, max.
20 meters/second³, max.
Built-in rechargeable Lithium-Ion battery
with +5V DC input charging circuit (700
mA).
Default: 5-6 hours after full charge.
Communicate with Host Platform via
Bluetooth™ (Class 2) Serial Port Profile.
SiRF binary – position, velocity, altitude,
status and control.
NMEA, Msg.: GGA, GLL, GSA, GSV,
RMC and VTG
Baud Rate: up to 115200 bps (default
setting 38400 bps)
Data bits: 8
Parity: NO
Stop bit: 1
Flow control: NO
