Motherboard Map - AOpen AX4B PRO Online Manual

A X 4 B / A
A X 4 B / A
Green: AUX-IN Connector
Red: MODEM-CN Connector
Black: CD-IN Connector
Onboard AC'97 CODEC
Die Hard BIOS
(AX4B Pro only,
upgrade optional)
JP30 Die Hard BIOS
Select jumper
(AX4B Pro only,
Uprade optional)
CNR Expansion Slot
IrDA Connector
Dr. LED Connector
Front Audio Connector
JP14 CMOS Clear Jumper
Chassis Intrusion Connector
4Mbit Flash ROM
nd
2 USB Connector
JP2 Jumper (Speaker)
Front Panel Connector
JP1 Jumper (Buzzer)
ATA/33/66/100
IDE Connector x2
FAN3 Connector
JP15 & 16 Dr. Voice Language
Select Jumper (AX4B Pro only)
X 4 B P r o
X 4 B P r o

Motherboard Map

FDD Connector
GPO1 Connector
17
O n l i n e M a n u a l
O n l i n e M a n u a l
PC99 Colored Back Panel
Resettable Fuse
JP28 Keyboard/Mouse Wakeup
Enable/Disable Jumper
FAN2 Connector
32-bit PCI Expansion Slot x5
2200μF Low ESR Capacitors
4-pin 12V. ATX Power Connector
AGP 4x Expansion Slot
(for 1.5V AGP card)
478-pin CPU socket with Voltage
and Frequency Auto-detection that
® ®
support Intel Pentium
1.4~2.4GHz+ CPU
®
Intel 845 chipset (Brookdale)
CPU Fan Connector with H/W
Monitoring Function
184-pin DIMM Socket x3 supports
PC-200/266 DDR SDRAM
maximum up to 2 GB
WOM Connector
WOL Connector
ATX Power Connector
