Attach the power LED, Keylock, speaker, power and reset switch connectors to
the corresponding pins. If you enable "Suspend Mode" item in BIOS Setup, the
ACPI & Power LED will keep flashing while the system is in suspend mode.
Locate the power switch cable from your ATX housing. It is 2-pin female
connector from the housing front panel. Plug this connector to the soft-power
switch connector marked SPWR.
Power on Suspend (S2) or Suspend to RAM (S3)
Suspend to Disk (S4)
IDE LED
Speaker
Suspend Type
1
SPWR
ACPI & PWR
LED
Reset
33
O
n
l
i
n
e
M
a
n
u
a
l
O
n
l
i
n
e
M
a
n
u
a
l
ACPI LED
Flashing for every second
The LED will be turned off
1
GND
5VSB
KEYLOCK
SPWR
+5V
ACPILED-
IDE LED
GND
IDE LED
ACPILED+
+5V
NC
+5V
NC
GND
GND
NC
RESET
SPEAKER
GND
