Core Frequency = CPU FSB
PCI Clock = CPU FSB Clock / Clock Ratio
AGP Clock = PCI Clock x 2
CPU Core
CPU
Frequenc
Pentium 4
1400MHz
1.4G
Pentium 4
1500MHz
1.5G
Pentium 4
1600MHz
1.6G
Pentium 4
1700MHz
1.7G
Pentium 4
1800MHz
1.8G
Pentium 4
1900MHz
1.9G
Pentium 4
2000MHz
2.0G
Pentium 4
2200MHz
2.2G
Pentium 4
2400MHz
2.4G
r o
r o
Clock * CPU Ratio
FSB System
Ratio
Clock Bus
100MHz 400MHz 14x
100MHz 400MHz 15x
100MHz 400MHz 16x
100MHz 400MHz 17x
100MHz 400MHz 18x
100MHz 400MHz 19x
100MHz 400MHz 20x
100MHz 400MHz 22x
100MHz 400MHz 24x
Warning: Intel
maximum 400MHz (100MHz*4) system
bus and 66MHz AGP clock; higher clock
setting may
damage.
Warning: To avoid possible CPU damage caused by
overheating, an automatic shutdown of system had been
especially designed on this motherboard. System would
be automatically power off when this motherboard with
implementation of THERMTRIP circuit detected a CPU
temperature above 135 degree for 4 seconds.
28
O n l i n e M a n
O n l i n e M a n
®
845 chipset supports
cause serious system
