This motherboard comes with a retention module attached on the CPU socket when shipped, we strongly recommend you to
install AOpen special designed CPU Fan as shown below on the retention module for better heat dissipation. Please install the
CPU Fan correctly as the following pictures shown.
1. Gently put the CPU Fan down on the
retention
module
with
correctly to the four corners.
r
o
r
o
a
t
i
o
n
a
t
i
o
n
clips
aligning
2. Pressing down the four clips with force one by
one on the retention module.
