Page 3: Congratulations
Congratulations on the purchase of your state-of-the-art remote start sys- tem with keyless entry. Reading this Owner’s Guide prior to using your system will help maximize the use of your system and its many features. For more information please visit us online at: www.directed.com/SmartStart For any additional questions please contact your authorized Directed dealer or contact Directed at 1-800-753-0600. -
Page 4: Optional Remote Kit
You can validate online at: www.prodregister.com/directed or com- plete and return the warranty registration card. This system can be used with a companion remote control which offers you additional features. This remote kit is available through your autho- rized dealer or by visiting us at www.directedstore.com to order. The remote kit part number is 9474T. -
Page 5: Table Of Contents
Congratulations ....................iii Important information ..................iii Your warranty..................iii Optional Remote Kit ................. iv Using Your System .....................2 Remote Start .....................2 Valet Take-Over ..................3 Starter Anti-Grind Circuitry .................3 Disabling the Remote Start system ...............4 Programming options ..................4 Government Regulations ..................5 Warning! Safety First ..................6 Caution ....................7 Patent Information .....................8... -
Page 6: Using Your System
This feature allows you to remotely start and run your vehicle for a programmable period of time. This makes it possible to warm up the engine, as well as adjust the interior temperature of the ve- hicle with the climate control system. If interior heating or cooling is desired, the climate controls must be preset, and the fan blower must be set to the desired level prior to remote starting the vehicle. -
Page 7: Valet Take-Over
• The brake pedal is pressed. • The hood is opened. • The shutdown toggle switch is put into the OFF position • The pre-programmed run time has elapsed. • The procedure to activate remote start is repeated. The Valet Take-Over feature allows the vehicle to remain running after the key has been removed from the ignition. -
Page 8: Disabling The Remote Start System
This feature allows your system's remote start unit to be temporarily disabled to prevent the vehicle from being remote started accidentally. This feature is useful if the vehicle is being serviced or stored in an enclosed area. To disable the remote start, move the shutdown toggle switch to the OFF position. -
Page 9: Government Regulations
This device complies with Part 15 of FCC rules. Operation is subject to the fol- lowing two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesirable operation. This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the FCC Rules. -
Page 10: Warning! Safety First
The following safety warnings must be observed at all times: Due to the complexity of this system, installation of this product must only be performed by an authorized Directed dealer. When properly installed, this system can start the vehicle via a com- mand signal from the remote control/transmitter. -
Page 11: Caution
After the remote start module has been installed, contact your autho- rized dealer to have him or her test the remote start module by perform- ing the Safety Check outlined in the product installation guide. If the vehicle starts when performing the Neutral Safety Shutdown Circuit test, the remote start unit has not been properly installed. -
Page 12: Patent Information
This product is covered by one or more of the following U.S. patents: 303,223 345,711 4,383,242 5,103,221 5,534,845 5,907,195 333,633 347,190 4,438,426 5,117,217 5,572,185 5,914,667 333,634 348,622 4,553,127 5,132,660 5,646,591 5,945,936 333,635 352,685 4,584,569 5,193,141 5,656,997 5,952,933 333,636 383,689 4,794,368 5,245,694 5,712,638 5,990,786... -
Page 13: Limited Lifetime Consumer Warranty
Directed Electronics. (“Directed”) promises to the original purchaser to repair or replace (at Directed’s election) with a comparable reconditioned model any Directed unit (hereafter the “unit”), excluding without limitation the siren, the remote transmitters, the associated sensors and accessories, which proves to be defective in workmanship or material under reason- able use during the lifetime of the vehicle provided the following conditions are met: the unit was purchased from an authorized Directed dealer, the unit was professionally installed and serviced by an authorized Directed dealer;... - Page 14 WARRANTY DOES NOT COVER LABOR COSTS FOR MAINTENANCE, REMOVAL OR REINSTALLATION OF THE UNIT OR ANY CONSEQUENTIAL DAMAGES OF ANY KIND. IN THE EVENT OF A CLAIM OR A DISPUTE INVOLVING DIRECTED OR ITS SUBSIDIARY, THE VENUE SHALL BE SAN DIEGO COUNTY IN THE STATE OF CALIFORNIA. CALIFORNIA STATE LAWS AND APPLICABLE FEDERAL LAWS SHALL APPLY AND GOVERN THE DISPUTE.
- Page 15 The company behind this system is Directed Elec tron ics Since its inception, Directed Electronics has had one purpose, to provide consumers with the finest vehicle security and car stereo products and accessories available. The recipient of nearly 100 patents and Innovations Awards in the field of advanced electronic technology, DIRECTED is ISO 9001 registered.
-
Page 16: Installation Points
Installation Points Reset and Deletion Quick Reference Install Guide 3000-series Remote Start with Keyless Entry Tach Learning If a feature/virtual tach needs to be reset or the remote controls need to be deleted, use the following procedure. To learn the tach signal: 1. Turn the ignition to the ON position (The heavy gauge pink wire must be con- Remote start (H2) 6-pin connector 1. Start the vehicle with the key. nected). 2. Within 5 seconds, press and hold the Valet button. Wiring Connections H2/1 PINK OUTPUT TO PRIMARY IGNITION CIRCUIT 2. Within 10 seconds, press and release the Valet button: 2 times if you want to 3. After 3 seconds the LED will light constant when the tach signal is learned. - Page 17 Programming System Features Feature Menus Optional Remote Programming (for use when adding 9474T Remote Kit) Default settings are in bold type. The System Features Learn Routine dictates how the unit operates. It is possible to access and change most of the 1. Turn key to the ON position feature settings using the Valet button. 2. Within 5 seconds, press and release Valet button one time. Menu 1 3. Within 5 seconds, press and hold the Valet button. The LED will flash one time and the horn honks to confirm 1. Turn the ignition on, then off. entry into remote programming. 2. Select a Menu. Press and hold the Valet button. The number of LED flashes and horn honks indicates the 4. Press the button on the remote control. Feature # Feature Opt. 1 Opt. 2 Opt.
- Page 18 Quick Reference Install Guide VSM200/250, DSM200/250 Installation Procedure obstructions that can affect communications and within reach of the main Directed system using the provided cables (do not extend). This product is compatible with most Directed Elec- tronics Security, Remote Start and hybrid systems that are ESP2 compatible (3 or 4-pin).
-
Page 19: Directed Electronics. All Rights Reserved
3. Install the VSM200/250 or DSM200/250 using b. Log on to: www.directechs.com, and click on the information in the wiring diagram and steps the SmartStart link. (Note CAUTIONS during installation). c. Follow the on-screen directions to activate a. Configuration Wires: Connect the loose gray and test a SmartStart device. - Page 20 Congratulations on the purchase of your state-of-the-art Directed SmartStart system. Reading this user's guide prior to using your system will get you off to a quick and smooth start. Start Here Before you can start using your system, the following steps must be performed: Download the free SmartStart application to your smartphone from the iTunes App Store, BlackBerry App World or Android Market site depending on which brand you own.
- Page 21 Menu Bar and Screens Menu Bar Description Home This screen is the default screen for direct access to all your remote commands. Select any command on the Home screen to perform it. Alerts This screen provides notifications from the system. These notifications are indicated by a red circle above the Alerts icon which also indicates the number of uncleared notifications received.
- Page 22 IMPORTANT I Read First This unit must be tested prior to activating the system online. Once the installation is complete; test that the remote start and key- less operations are functional prior to activating the system online. The remote start can be activated(deactivated by manually provid- ing a ground pulse to the White/Blue H wire.
- Page 23 DEI~ DEI~ VEHICLE EQUIPPED WITH A VEHICLE EQUIPPED WITH A REMOTE START SYSTEM REMOTE START SYSTEM II vehicle battery is disconnected, the system may attempt to start when the battery is reconnected or transmitter II vehicle battery is disconnected, the system may attempt to start when the battery is reconnected or transmitter is used.
- Page 25 U.S. U.S. This product is covered This product is covered one or more of the following one or more of the following patents: patents: 303,223 303,223 333,795 333,795 333,633 333,633 333,634 333,634 333,635 333,635 333,636 333,636 340,000 340,000 344,905 344,905 345,317 345,317 345,711...
- Page 26 PRODUCT REGISTRATION PRODUCT REGISTRATION E L E C T RON I C S, INC. E L E C T RON I C S, INC. Security Security Register your product for: Register your product for: Recall Notifications Recall Notifications We contact our customers in case of recall. We contact our customers in case of recall.
- Page 27 IMPORTANT! IMPORTANT! IMPORTANT! IMPORTANT! Please complete and return within the next Please complete and return within the next days days or register online at www.prodregister.com/directed or register online at www.prodregister.com/directed ELECTRONICS. INC. ELECTRONICS. INC. 1.1.DMr. 1.1.DMr. 2. 0 Mrs. 2. 0 Mrs. 3.0 Ms.
- Page 28 To help us understand our customers' lifestyles, please indicate the interests and activities in which you or your spouse To help us understand our customers' lifestyles, please indicate the interests and activities in which you or your spouse enjoy participating on a regular basis. enjoy participating on a regular basis.
- Page 29 Please send products and Please send products and FirSFClas$-. FirSFClas$-. I···· I···· Postage' ..Postage' ..other correspondence to: other correspondence to: I· I· Required .. Required .. r·poslOfficewill. r·poslOfficewill. Directed Electronics Inc. Directed Electronics Inc. ..not denver ..not denver 1 Viper Way...
- Page 30 model 94741 T RON I C S...
